Operating instructions and warnings
124RR
Control board 24V for gate automation operating
Instructions and warnings
OVERVIEW ................................................................................................................................12
1 PRODUCT CONFORMITY .....................................................................................................12
2 WARNINGS ..........................................................................................................................12
3 MODELS AND CONTENTS OF THE PACKAGE .......................................................................13
4 PRODUCT DESCRIPTION ......................................................................................................13
5 TECHNICAL DATA.................................................................................................................14
6 OPERATING CONDITIONS ...................................................................................................14
7 ASSEMBLY AND WIRING INSTRUCTIONS ..............................................................................14
8 USE INSTRUCTIONS .............................................................................................................15
8.1 Visualization of inputs status .......................................................................................15
8.2 Set-up and memorization of the motor stroke ..............................................................16
8.3 Built-in radio receiver ..................................................................................................16
8.4 Personalization of working parameters ........................................................................18
8.5 Reset of default parameters (p.007) .............................................................................18
8.6 Safety devices .............................................................................................................18
8.7 Messages shown on the display ...................................................................................19
9 MAINTENANCE ....................................................................................................................20
10 PRODUCT DISPOSAL ............................................................................................................20
11 COMPLETE CLOSING ASSEMBLY...........................................................................................20
OVERVIEW
These instructions were prepared by the manufacturer and are an integral part of the product. The
operations described are designed for adequately trained and qualified personnel and must be carefully
read and kept for future reference.
1 PRODUCT CONFORMITY
The 124RR programmable control board bears the EC label. DEA SYSTEM guarantees the conformity
of the product to European Directives 89/336/CE and subsequent amendments (concerning electroma-
gnetic compatibility), 73/23/CE and subsequent amendments (low voltage electrical equipment)
2 WARNINGS
Read these warnings carefully. Failure to respect the following warnings may cause risk si-
12
tuations.
WARNING DEA System reminds all users that the selection, positioning and installation of all materials
and devices which make up the complete automation system, must comply with the European Directives
98/37/CE (Machinery Directive), 89/336/CE and subsequent amendments (electromagnetic compati-
bility), 73/23/CE and subsequent amendments (low voltage electrical equipment). In order to ensure a
suitable level of safety, besides complying with local regulations, it is advisable to comply also with the
above mentioned Directives in all non-European countries.
WARNING Using the product under unusual conditions not foreseen by the manufacturer may cause
dangerous situations; this is the reason why all the conditions prescribed in these instructions must be
followed.
WARNING Under no circumstance must the product be used in an explosive environment or surroun-
dings that may prove corrosive and damage parts of the product.
R
ENGLISH
A1
A2
A3
Advertisement
Table of Contents
Related Manuals for Dea 124RR
Summary of Contents for Dea 124RR
-
Page 1: Table Of Contents
1 PRODUCT CONFORMITY The 124RR programmable control board bears the EC label. DEA SYSTEM guarantees the conformity of the product to European Directives 89/336/CE and subsequent amendments (concerning electroma- gnetic compatibility), 73/23/CE and subsequent amendments (low voltage electrical equipment) 2 WARNINGS Read these warnings carefully. -
Page 2: Warnings
WARNING Install and wire the control board according to the instructions given in the instruction booklet of each gate operator DEA System (such as hole drilling to allow for wires passage, use of wire clamps, etc.) Failure to comply with these instructions may jeopardize the level of electrical safety. -
Page 3: Technical Data
WARNING Install and wire the control board according to the instructions given in the instruction booklet of each gate operator DEA System (such as hole drilling to allow for wires passage, use of wire clamps, etc.) Failure to comply with these instructions may jeopardize the level of electrical safety. -
Page 4: Use Instructions
Operating instructions and warnings Table 1 Terminal board connection 24 V a.c. transformer power supply input 24 V a.c. 24 V d.c. battery power supply input (Follow carefully polarity indications) 24 V Batt Free contact max. capacity 5 A : this contact can be used to control an open gate warning light (P27=0) or a courtesy lamp (P27≠0) LC/SCA Flashing light output 24 V d.c. -
Page 5: Set-Up And Memorization Of The Motor Stroke
Built-in radio receiver DEA 124RR control board includes a 433,92MHz built-in radio receiver accepting both transmitters with HCS coding (complete rolling code or just fixed part), and HT12E dip-switch coding. •The type of coding is selected by programming the working parameter n° 8 “type of coding” (see Table 2 Parameters) •The receiver memory capacity can contain up to 100 different transmitters. - Page 6 Operating instructions and warnings Display Instructions Function The control board is ready to receive instructions Deletion of all transmitters Scroll down the parameters until you visualize P004 Confirm! The control board awaits a further confirmation Confirm by pressing on the OK key for a few seconds! The procedure starts Done! The transmitters memory has been deleted Scroll down the parameters until you visualize “----”.
-
Page 7: Personalization Of Working Parameters
Resetting of default parameters (p.007) DEA 124RR control board software includes a reset procedure to restore default values (the one set by the maker) of all settable parameters. The value originally set for each parameter is shown in the “working parameters table”. -
Page 8: Messages Shown On The Display
If you power external safety devices through 24VSIC output (terminal no. 22), their pro- per working is tested before each manoeuvre. Messages shown on the display 124RR control board allows you to visualize on the display several messages concerning its working status and any malfunction: Message... -
Page 9: Maintenance
WARNING DEA System reminds all users that the selection, positioning and installation of all materials and devices which make up the complete automation system, must comply with the European Directives 98/37/CE (Machinery Directive), 89/336/CE and subsequent amendments (electromagnetic compati- bility), 73/23/CE and subsequent amendments (low voltage electrical equipment). - Page 10 Operating instructions and warnings 1 2 4 R R...
- Page 11 Operating instructions and warnings...
