- Page 1 Ver. 2.0 Spray Booth MODEL NUMBER: BD-512 USER GUIDE After Sales Support UK/N.IRELAND HELPLINE N 01270 508530 YEAR WEBSITE: www.airbrushheaven.co.uk EMAIL: enquiries@airbrushheaven.co.uk WARRANTY...
-
Page 2: Table Of Contents
Contents Welcome Section General Information & Safety Instructions Contents & Features Parts 4-7. Setup Turntable Storing the Booth Changing the Filter Specifications After Sales Support 01270 508530 UK/N.IRELAND HELPLINE N WEBSITE: www.airbrushheaven.co.uk EMAIL: enquiries@airbrushheaven.co.uk... - Page 3 Airbrush Heaven. We want you to be completely satisfied with your purchase so this AIRBRUSH HEAVEN product is backed by a comprehensive manufacturer’s 1 year warranty and outstanding after sales service through our helpline.
-
Page 4: General Information & Safety Instructions
General Information & Safety Instructions WARNING! The warnings, precautions, and instructions discussed in this manual cannot cover all possible conditions and situations that may occur. The operator must understand that common sense and caution are factors, which cannot be built into this product. Contents &... -
Page 5: Parts
Parts Carry Handle Upper panel Filter Filter Frame Lower Panel Turntable 3-Way Switch Retract Button Extractor Extractor Hose Port Spring Clip Extraction End Piece After Sales Support UK/N.IRELAND HELPLINE N 01270 508530 WEBSITE: www.airbrushheaven.co.uk EMAIL: enquiries@airbrushheaven.co.uk... -
Page 6: Setup
Setup Setting Up You Spray Booth First you will need to attach the extractor hose. Place the spring clip over the end of the extractor hose. Then place the hose over the extractor port on the back of the spray booth and release the spring clip to hold the hose in place. After Sales Support UK/N.IRELAND HELPLINE N 01270 508530... - Page 7 Setup To fit the extraction end piece, pinch at least three loops together and stretch the next few loops taught. Slide the hose over the end of the extractor end piece. After Sales Support UK/N.IRELAND HELPLINE N 01270 508530 WEBSITE: www.airbrushheaven.co.uk EMAIL: enquiries@airbrushheaven.co.uk...
- Page 8 Setup Once the hose is securely fitted into place you will need to open the the spray area. To do this lower the bottom panel into position first. Next raise the upper panel into position and lock it into position. Make sure the clips lock fully into place to hold the upper panel up.
- Page 9 Setup Now the panels are securely in place you can now access the mains lead stored in the bottom right side panel. Pull the plug to extend the mains cable (up to 1.3m) and connect it to the mains outlet point. You have two option when using the spray booth, ‘fan only’...
-
Page 10: Turntable
The Turntable The turntable supplied with the spray booth is independent from the booth itself. you can use it in conjunction with the spray booth or as a workstation. The turntable a is 360 free rotating platform. You can secure the position of the turntable with the sucker feet to most surfaces. -
Page 11: Storing The Booth
Storing the Booth After you have finished with the unit press the switch located on the back to the ‘Off’ position. Disconnect the mains lead from the mains outlet. Press the cable retraction button located on the back of the unit. Retract Cable Please Note: The retraction mechanism is spring loaded, watch your fingers and surroundings. -
Page 12: Changing The Filter
Changing the Filter The spray booth is provided with a filter already installed but you will need to change this later on through a fair amount of use. To do this press down on the filter housing inside the booth, unclip the tabs and pull it towards you. -
Page 13: Specifications
Specifications • Power: 25W • Airflow: 3m /min • Noise: 45dB • Deployed Dimensions: 405mm x 475mm x 335mm • Stored Dimensions: 405mm x 215mm x 290mm • Net Weight: 5Kg • Hose Length: 2.5m After Sales Support UK/N.IRELAND HELPLINE N 01270 508530 WEBSITE: www.airbrushheaven.co.uk EMAIL: enquiries@airbrushheaven.co.uk... - Page 14 Warranty Certificate Warranty This product is guaranteed to be free from defects in workmanship and parts for a period of 12 months from the date of purchase. Defects that occur within this warranty period, under normal use and care, will be repaired, replaced or refunded at our discretion, solely at our option with no charge for parts and labour.
- Page 15 Warranty Card Spray Booth Model Number: BD-512 Please keep your purchase receipt/invoice together with your warranty card Name: Address: Date of purchase: Location of purchase: Fault Description: We recommend that you attach a photocopy of your receipt/invoice, showing the date of purchase, to this warranty card and keep it for your reference.
- Page 16 For further help, advice and video demonstrations please visit: www.airbrushheaven.co.uk...
