OPERATOR'S MANUAL
A Division of Snow Joe
, LLC
®
IMPORTANT!
Safety Instructions
All Operators Must Read These
Instructions Before Use
Always follow these safety guidelines. Failure to do so may
result in serious bodily injury or death.
General Safety WARNINGS!
When using this cordless lawn mower, basic safety
precautions should always be followed to reduce the risk of
fire, electric shock and personal injury. These precautions
include:
m
WARNING!
Do not operate without the entire grass
catcher, discharge guard, rear guard or other safety protective
devices in place and in proper working order.
m
WARNING!
The use of any other accessory or
attachment might increase the risk of injury.
m
WARNING!
To reduce the risk of injury, inspect the
catcher assembly frequently and replace with recommended
replacement if there are signs of wear or deterioration.
Before using the mower, take the time to familiarize yourself
with the controls, especially how to stop the mower in
an emergency. The only individuals who should use the
mower are those who have a thorough understanding of the
instructions and who know how to operate the machine.
Children should never be allowed access to the mower.
Retain this manual for future reference and reread it at the start
of each mowing season.
m
WARNING!
Contact with moving parts may cause
entanglement, dismemberment or other serious bodily
injury. Always keep body parts (i.e. hands, feet) a safe
distance away from moving parts. Ensure all covers and
guards are securely in place before use.
Hot surfaces (i.e. the motor) may ignite flammable or
combustible items and cause a fire or explosion, which
can result in serious bodily injury. Keep the mower a safe
© 2018 by Snow Joe
, LLC
®
All rights reserved. Original instructions.
CORDLESS LAWN MOWER
R
24-V | 5.0-Ah | 14-INCH
Model MJ24C-14-XR
distance away from flammable or combustible items until
surfaces that are hot have completely cooled. Do not store
the mower near flammable or combustible items.
A damaged blade or worn blade nut may break off the
mower assembly and cause serious injury. Replace the
damaged blade or blade nut before using the mower.
1. Avoid dangerous conditions – Do not use the mower in
the rain or when the grass is damp or wet.
2. Keep children, bystanders and pets away – Always
keep children and spectators a safe distance away from
the mower during operation and as the machine cools.
3. Dress properly – Always wear personal safety gear (i.e.
glasses, rubber gloves, protective footwear and dust
masks) and proper clothing when using the mower. Loose
clothing, long hair or jewelry may get caught in the moving
parts.
4. Use the right appliance – Do not use the lawn mower
for any applications other than those for which it was
intended.
5. Do not force the lawn mower – It will perform better with
less likelihood of personal or mechanical injury if it is used
at the rate for which it was designed.
6. Do not overreach – Keep proper footing and balance at
all times.
7. Stay alert – Always be alert and watch what you are
doing. Use common sense. Do not operate the lawn
mower when you are tired or under the influence of
alcohol or drugs.
8. Disconnect the lawn mower – Turn OFF and remove
safety key when the mower is not in use, before servicing
it, when changing accessories and when performing any
other maintenance task.
9. Store idle lawn mower indoors – When not in use, the
lawn mower should be stored indoors in a dry, locked
place out of the reach of children.
10. Maintain the lawn mower with care – Keep cutting
edges sharp and clean for best and safest performance.
11. Use personal protective equipment. Always wear eye
protection – Protective equipment such as safety glasses,
a dusk mask, non-skid safety shoes, a hard hat, and
hearing protection, when used for appropriate conditions,
will reduce the possibility of personal injuries.
SAVE THESE INSTRUCTIONS
1
Form No. SJ-MJ24C-14-XR-880E-M

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SunJoe MJ24C-14-XR and is the answer not in the manual?

Questions and answers

Summary of Contents for SNOWJOE SunJoe MJ24C-14-XR

  • Page 1 CORDLESS LAWN MOWER 24-V | 5.0-Ah | 14-INCH OPERATOR’S MANUAL Model MJ24C-14-XR A Division of Snow Joe , LLC ® Form No. SJ-MJ24C-14-XR-880E-M IMPORTANT! distance away from flammable or combustible items until surfaces that are hot have completely cooled. Do not store Safety Instructions the mower near flammable or combustible items.
  • Page 2: Electrical Safety

    ® ® Have your battery pack serviced by a qualified repair person 1-866-SNOWJOE (1-866-766-9563). using only identical replacement parts. This will ensure that the 2. If charging the power tool in a damp location is safety of the battery pack is maintained.
  • Page 3 ® ® shocks, even if the housing of the battery pack appears to 1-866-SNOWJOE (1-866-766-9563) for assistance. be undamaged. The battery cells inside the battery may • Battery chemicals cause serious burns – Never let a have suffered serious damage. In such instances, please damaged battery pack contact the skin, eyes or mouth.
  • Page 4: Information About The Charger And The Charging Process

    ® ® 5. Do not keep the battery charger in places where the customer service center at 1-866-SNOWJOE temperature is liable to reach over 104°F (40°C). In (1-866-766-9563). particular, do not leave the battery charger in a car that is 3.
  • Page 5 ® ® ® mow it. Sun Joe customer service center at 1-866-SNOWJOE ® (1-866-766-9563). Only identical replacement parts should • Mow across the face of slopes; never mow slopes be utilized for repairs. This will ensure that the safety of following an up and down traverse.
  • Page 6: Safety Symbols

    Safety Symbols The following table depicts and describes safety symbols that may appear on this product. Read, understand and follow all instructions on the machine before attempting to assemble and operate. Symbols Descriptions Symbols Descriptions DANGER! Rotating blades. Keep Keep bystanders and children a safe hands and feet away.
  • Page 7: Technical Data

    Know Your Cordless Lawn Mower Read the owner’s manual and safety instructions carefully before operating the mower. Compare the illustration below to the mower in order to become familiar with the location of the various controls and adjustments. Save this manual for future reference.
  • Page 8: Carton Contents

    Unpacking Handle Assembly 1. Fit the lower handle frame into the two holes in the Carton Contents machine body and fasten the handle on both sides with the screws provided (Fig. 1). • Cordless lawn mower • Grass collection bag Fig.
  • Page 9: Battery Pack Operation

    3. Lift the ejector flap with one hand. With the other hand, hold the grass collection bag by the handle and hook it in Fig. 3 from above (Fig. 6). Ejector flap Fig. 6 Upper handle frame Shorter handle setting Longer handle setting Grass collection...
  • Page 10: Charger Operation

    Fig. 8 Battery compartment Lights Light Indicators cover Push lock Charge level button button The battery is at 30% capacity and requires charging The battery is at 60% capacity and requires charging soon The battery is at full capacity NOTE: If the charge level button does not appear to be working, insert the charger and charge as needed.
  • Page 11: Operation

    Fig. 10 Fig. 11 Charging green Battery Safety key Fully charged 5. The battery will take approximately 2.5 hours to charge. 2. Before starting the lawn mower, hold the handle assembly The charge indicator LED will become green when the battery is fully charged, unplug the charger immediately with both hands and tilt the handle downward to slightly when the green light is on.
  • Page 12: Adjusting The Cutting Height

    WARNING! Before making these adjustments, disconnect the power supply to the mower by plugging Fig. 13 out the safety key from the slot, and wait until the rotating blade has come to a complete standstill. Wearing gloves is recommended due to the close proximity of the cutting blade. ALWAYS FOLLOW ALL SAFETY PRECAUTIONS AND RECOMMENDATIONS LISTED PREVIOUSLY IN THIS MANUAL.
  • Page 13: Mowing Tips

    Maintenance + Care Mowing Tips WARNING! Inspect the area prior to mowing and WARNING! Before cleaning, repairing or inspecting remove all the stones, sticks, wires and other foreign objects the mower, disconnect the power supply by plugging out the that could be picked up and thrown by the rotating blade. safety key and verify that all moving parts have come to a Failure to comply not only will damage the mower blade, but complete stop.
  • Page 14: Blade Replacement

    WARNING! An excessively vibrating mower indicates Fig. 17 that the blade is not properly balanced or has become deformed from striking an object. In this case, the blade must be repaired or replaced. Please follow the proper maintenance procedures for blade care. Bolt Blade Blade Replacement...
  • Page 15: Recycling + Disposal

    Service + Support If your Sun Joe MJ24C-14-XR cordless lawn mower requires ® service or maintenance, please call 1-866-SNOWJOE (1-866-766-9563) for assistance. Model + Serial Numbers When contacting the company or reordering parts, you will Disposal need to provide the model and serial numbers of your product.
  • Page 16: Federal Communications Commission (Fcc)

    iCHRG24-QC Federal Communications Commission (FCC) WARNING! Any changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. Class B device: NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules.
  • Page 17: Troubleshooting

    Troubleshooting • Remove the safety key before carrying out maintenance on the machine or when checking that its parts are in proper working order. • To avoid unnecessary hassles, consult the following table before contacting a qualified repair person with any mechanical issues.
  • Page 18 NOTE: Accessories are subject to change without any obligation on the part of Snow Joe + Sun Joe to provide notice of such ® ® changes. Accessories can be ordered online at snowjoe.com or via phone by contacting the Snow Joe + Sun Joe customer ® ®...
  • Page 19 NOTES...
  • Page 20 NOTES...
  • Page 21 NOTES...
  • Page 22 WHO CAN SEEK WARRANTY COVERAGE? Wearing parts like belts, augers, chains and tines are not covered under this warranty, and can be purchased at snowjoe.com or This Warranty is extended by Snow Joe + Sun Joe to the owner ®...
  • Page 23 snowjoe.com...
