Saw Chain Sharpening


CAUTION: Sharp chain. Always wear protective
gloves when handling the chain. The chain is sharp
and can cut you when it is not running.

WARNING: Sharp moving chain. To prevent
accidental operation, ensure that battery is removed
from the tool before performing the following
operations. Failure to do this could result in serious
personal injury.
nOTE: The cutters will dull immediately if they touch the
ground or a nail while cutting.
To get the best possible performance from your chain saw
it is important to keep the teeth of the saw chain sharp.
Follow these helpful tips for proper saw chain sharpening:
1. For best results use a 4.5 mm file and a file holder or
filing guide to sharpen your saw chain. This will ensure
you always get the correct sharpening angles.
2. Place the file holder flat on the top plate and depth
gauge of the cutter.
3. Figure T- Keep the correct top plate
of 30° on your file guide parallel with your chain (file at
60° from chain viewed from the side).
4. Sharpen cutters on one side of the chain first. File from
the inside of each cutter to the outside. Then turn your
saw around and repeat the processes (2, 3, 4) for cutters
on the other side of the chain.
nOTE: Use a flat file to file the tops of the rakers (portion
of chain link in front of the cutter) so they are about
.025" (.635 mm) below the tips of the cutters as shown
in Figure U.
5. Figure V- Keep all cutter lengths equal.
6. If damage is present on the chrome surface of the
top plates or side plates, file back until such damage
is removed.

CAUTION: After filing, the cutter will be sharp, use
extra caution during this process.
nOTE: Each time the chain is sharpened, it loses some of
the low kickback qualities and extra caution should be used.
It is recommended that a saw chain be sharpened no more
than four times.
Fig. T
21
Fig. U
Fig. V
Cleaning


21 filing angle line
Saw Chain and Guide Bar
After every few hours of use, remove the sprocket cover,
guide bar and chain and clean thoroughly using a soft
bristle brush. Ensure oiling hole on bar is clear of debris.
When replacing dull chains with sharp chains it is good
practice to flip the chain bar from bottom to top.

Register Online

Thank you for your purchase. Register your product now for:
•
•
•
Register online at www.craftsman.com/registration

Three Year Limited Warranty

60°
CRAFTSMAN will repair or replace, without charge, any
defects due to faulty materials or workmanship for three
years from the date of purchase (two years for batteries).
This warranty does not cover part failure due to normal
wear or tool abuse. For further detail of warranty coverage
and warranty repair information, visit www.craftsman.com
or call 1-888-331-4569. This warranty does not apply to
.025"
accessories or damage caused where repairs have been
(0.635 mm)
made or attempted by others. THIS LIMITED WARRANTY
IS GIVEN IN LIEU OF ALL OTHERS, INCLUDING THE IMPLIED
WARRANTY OF MERCHANTABILITY AND FITNESS FOR A
PARTICULAR PURPOSE, AND EXCLUDES ALL INCIDENTAL
OR CONSEQUENTIAL DAMAGES. Some states do not allow
WARNING: Blow dirt and dust out of all air vents with
clean, dry air at least once a week. To minimize the risk
of eye injury, always wear ANSI Z87.1 approved eye
protection when performing this procedure.
WARNING: Never use solvents or other harsh
chemicals for cleaning the non-metallic parts of
the tool. These chemicals may weaken the plastic
materials used in these parts. Use a cloth dampened
only with water and mild soap. Never let any liquid
get inside the tool; never immerse any part of the tool
into a liquid.
WARRAnTY sERViCE: Registering your product will
help you obtain more efficient warranty service in case
there is a problem with your product.
COnFiRMATiOn OF OWnERshiP: In case of an
insurance loss, such as fire, flood or theft, your
registration of ownership will serve as your proof
of purchase.
FOR YOUR sAFETY: Registering your product will
allow us to contact you in the unlikely event a safety
notification is required under the Federal Consumer
Safety Act.
