Summary of Contents for Hot Max 50200
- Page 1 MODEL 50200 500,000 BTU ECONOMY PROPANE TORCH...
- Page 2 MODEL 50200 PROPANE TORCH ASSEMBLY, TESTING, AND OPERATING INSTRUCTIONS PLEASE READ AND RETAIN THIS INFORMATION FOR FUTURE REFERENCE DO NOT OPERATE this torch unless you have been properly trained or are under the supervi- sion of someone in its proper use. Read and understand all instructions before attempting to...
- Page 3 PROPANE TORCH COMPONENTS Molded Grip For Comfort Boost Valve Handle Flame Adjusting Valve 6.5’ UL/CSA Listed Propane Hose, 350 PSI Rated, 1/4” Brass Fitting CGA-510 Fitting to connect to propane cylinder Barrel...
- Page 4 ASSEMBLY INSTRUCTIONS 1. Unpack and inspect for damage. DO NOT use torch if damaged. 2. Attach CGA-510 fitting to LP gas cylinder valve (remember this is a left hand fitting) using the standard internal threads found on industry standard tanks with OPD approved valves. DO NOT USE THREAD COMPOUND! Remember, LP gas cylinder is to be no less than 10 LB.
- Page 5 LIGHTING INSTRUCTIONS 1. Check all connections for leaks with leak detection fluid or soapy water. Leaks will be indicated by bubbles forming around the source. Repair all leaks and test again before lighting the torch. 2. Open the flame adjusting valve 1/4 to 1 full turn until the sound of propane gas escaping is heard.
- Page 6 TORCH DISCONNECTION AND STORAGE 1. Be sure the LP gas cylinder valve is turned completely off (clockwise). 2. Disconnect the CGA-510 fitting from the LP gas cylinder (again, these are left handed threads) with a wrench. 3. Replace the plastic cover on the LP gas cylinder valve outlet. 4.
- Page 7 Do you wish the hose was longer? Hot Max carries three extension hoses that will work with this torch! Model 24201 is a 25 foot extension hose (and the most popular). Model 24200 is a 10 foot extension hose.
- Page 8 Thank you for your purchase! We hope you enjoy your torch! Need a longer hose for your torch? Looking for other great Hot Max accessories for your torch or our other products? Check out our website for our current product offering.
