BIG MAX
®
MODEL 500G
and
JR MAX
®
MODEL 100G
INSTRUCTION MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BIG MAX 500G and is the answer not in the manual?

Questions and answers

Related Manuals for Hot Max BIG MAX 500G

Summary of Contents for Hot Max BIG MAX 500G

  • Page 1 BIG MAX ® MODEL 500G JR MAX ® MODEL 100G INSTRUCTION MANUAL...
  • Page 2 BIG MAX® AND JR MAX® PROPANE TORCHES ASSEMBLY, TESTING, AND OPERATING INSTRUCTIONS PLEASE READ AND RETAIN THIS INFORMATION FOR FUTURE REFERENCE DO NOT OPERATE this torch unless you have been properly trained or are under the supervi- sion of someone in its proper use. Read and understand all instructions before attempting to use! FOR YOUR SAFETY! ...
  • Page 3 PROPANE TORCH COMPONENTS Idle Boost/Fuel Saver Valve Flame Adjusting Valve Trademarked Molded Handle for more Comfort and Control US Trademark 3,700,964 10’ UL/CSA Listed Propane Hose, 350 PSI Rated POL Safety Valve Barrel Single Flint Striker...
  • Page 4 ASSEMBLY INSTRUCTIONS 1. Unpack and inspect for damage. DO NOT use torch if damaged. 2. Attach POL fitting to LP gas cylinder valve (remember this is a left hand fit- ting) using the standard internal threads found on industry standard tanks with OPD approved valves.
  • Page 5 LIGHTING INSTRUCTIONS 1. IMPORTANT NOTE!!! The POL safety valve contains an integral flow- check valve. Opening the LP gas cylinder valve rapidly can cause the valve to check and restrict the flow of gas. If the POL flow valve checks, close the LP gas cylinder valve, open the flame adjusting valve on the handle to release any pressure in the hose, reclose the flame adjusting valve on the torch handle, wait 20 seconds, and then slowly open the LP Gas cylinder...
  • Page 6 TORCH DISCONNECTION AND STORAGE 1. Be sure the LP gas cylinder valve is turned completely off (clockwise). 2. Disconnect the POL safety valve from the LP gas cylinder (again, these are left handed threads) with a wrench. 3. Replace the plastic cover on the LP gas cylinder valve outlet. 4.
  • Page 7 TROUBLE SHOOTING Problem #3 - The Idle Boost valve is not working. Possible Solutions: 1. If you can not get full flow out of the torch with the flame adjusting valve all the way open or the Idle Boost valve handle depressed, then the POL safety valve has probably detected too much gas flow and restricted the gas flow.
  • Page 8 Thank you for your purchase! We hope you enjoy your torch! Need a longer hose for your torch? Looking for other great Hot Max accessories for your torch or our other products? Check out our website for our current product offering.
