6FT TRAMPOLINE
WITH ENCLOSURE
Assembly & User Instructions -
Important
Age: 3 - 6 years
Maximum user
weight: 45kg
Important -
Please read these instructions fully before assembly or use.
These instructions contain important information which will help you get the best from your
product and ensure safe and correct assembly, use and maintenance.
If you need help or have damaged or missing parts, call the Customer Helpline: 0843-5034455
Please keep for future reference
367/5511
Tips: It will take around 30
minutes to assemble it.
2 people may be required
Issue 1 - 13/10/11

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 367/5511 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Chad Valley 367/5511

Summary of Contents for Chad Valley 367/5511

  • Page 1 6FT TRAMPOLINE WITH ENCLOSURE Assembly & User Instructions - Please keep for future reference 367/5511 Important Tips: It will take around 30 Age: 3 - 6 years minutes to assemble it. Maximum user 2 people may be required weight: 45kg Important - Please read these instructions fully before assembly or use.

  • Page 2: Table Of Contents

    Contents Safety Information Parts 4-21 Assembly Instructions Attach Support Attach frame Attach the Corner Top Rail with Socket Attach lower tubes Attach the Top Rail Attach mat Attach frame pad Attach Safety Instruction Attach upper tubes 10-12 13-15 Fit enclosure net Tie the elastic straps Attach hook User Instructions...

  • Page 3: Safety Information

    Safety Information Important –Please read these instructions fully before assembly or use. ● Read all instructions before using the WARNING trampoline, warnings and instructions for the ● Max. weight limit : 45kg care, maintenance, and use of this trampoline ● Warning! Not suitable for children under are included to promote safe, enjoyable use of the age of 36 months as small part(s) may...

  • Page 4: Parts

    ,I \RX KDYH GDPDJHG RU PLVVLQJ SDUWV Parts call the Customer Helpline: 0843-5034455 3OHDVH &KHFN \RX KDYH DOO WKH SDUWV ¿WWLQJV OLVWHG EHORZ TUDPSROLQH 0DW VWLWFKHG ZLWK 8SSHU )UDPH TXEH ZLWK )RDP [  TULDQJOH5LQJV [ /RZHU )UDPH TXEH ZLWK )RDP [  )UDPH 3DG [  &DEOH :LUH [  TRS 5DLO ZLWK /HJ 6RFNHWV [ ...

  • Page 5: Assembly Instructions

    Assembly Instructions Step 1 There are a total of 9 pieces of tubing parts that are needed to assemble the frame. All parts with the same part number are interchangeable. To connect the parts, simply slide a section (male) of tubing that is smaller on one end into the adjacent section (female) that has a larger opening.

  • Page 6: Attach Mat

    Assembly Instructions Step 3 Trampoline Mat Assembly Lay out the Trampoline Mat (# 1) inside the frame with warning labels facing up as shown in FIGURE 4. There are total of 36 Triangle- Rings sewn on the mat and 36 holes on the Top Rail Frame.
  • Page 7 Assembly Instructions Step 5 Hold the spring loading tool underhand and pull spring hook towards the point “ZERO” on the Top Rail Frame as shown in FIGURE 6. Drop hook into frame hole until it latches on completely and tap it down if hook is not completely in the hole.
  • Page 8 Assembly Instructions Step 7 F r o m p o i n t 3 6 , c o u n t b a c k ZERO 9 holes on the Top Rail and Triangle-Rings, you should be at point 9. Attach a spring at this point, as shown in FIGURE 8.
  • Page 9 Assembly Instructions Step 9 Attach a spring at every 3 holes ZERO and corresponding Triangle- rings. For even distribution of tension and ease of assembly, s p r i n g s s h o u l d p l a c e d o n opposite sides of the mat/frame.

  • Page 10: Attach Frame Pad

    Assembly Instructions Step 11 Safety Placard Attachment Using the tie wrap, attach the Safety Instruction Placard (# 7) to the trampoline as shown in FIGURE 12. The tie wrap should go around the Vertical Frame Joint and the Top Rail to ensure that is doesn’t slide off the trampoline.

  • Page 11: Attach Upper Tubes

    Assembly Instructions Step 13 Frame Pad Assembly Tie straps around leg socket as shown below in FIGURE 14. IMPORTANT NOTICE: Make sure the safety pad is securely attached to the frame and completely covers the frame and all springs before using this trampoline.
  • Page 12 Assembly Instructions Step 15 Pull the foam downward a little bit to locate the hole at the edge of the curved end of Upper Frame Tube with Foam (#7). Attach Plastic Cap (#13) to Upper rame Tube with Foam secure by using Self- (#7), Locking Screw (#E) and Allen Wrench (#J) as shown in...
  • Page 13 Assembly Instructions Step 17 Connect the thread to the nut of Thread Cable Wire (#9) by using Wrench (#C) as shown in FIGURE 18. HINT: Please make sure every Cable Wire is securely and completely fasten to each other. FIGURE 18...

  • Page 14: Fit Enclosure Net

    Assembly Instructions Step 18 Sleeve Opening CAUTION: TWO ADULTS ARE REQUIRED. A. Insert the assembled CABLE WIRES into sleeve on the top part of the 11 Enclosure Netting Sleeve as shown in FIGURE 19. FIGURE 19 Sleeve B . Connect the two end of CABLE WIRES together by Thread connecting the thread to the...
  • Page 15 Assembly Instructions Step 19 Cable Wire CAUTION: TWO ADULTS ARE REQUIRED. Place the CABLE WIRE with Plastic Cap ENCLOSURE NETTING to the PLASTIC CAP assembled on the UPPER FRAME Tube with Foam ( # A ) to make a “RING” as shown in FIGURE 21.
  • Page 16 Assembly Instructions Step 20 Attach the assembled “RING” (together with 7, 9 and 11) to the Lower Frame Tube with Foam (#B) as shown in FIGURE IMPORTANT NOTICE: Please squeeze the foam of Upper Frame Tube with Foam (#7) and Lower Frame Tube with Foam (#8) a little bit to locate the hole.

  • Page 17: Tie The Elastic Straps

    Assembly Instructions Step 21 Tie one end of one CORD (#10) to trampoline mat ring first, pull the CORD through net edge and trampoline mat ring until the end. Tie new CORD to the same trampoline mat ring where the previous CORD finished.

  • Page 18: Attach Hook

    Assembly Instructions Step 22 Pull the zipper of Enclosure Netting at the door which should be located within one leg base of the trampoline as shown in FIGURE 25. Attach buckle sewn on the enclosure netting as shown in FIGURE 25 (one may be hidden under the pad of the trampoline).
  • Page 19 Assembly Instructions Step 23 Use the included plastic tie to attach 6 Safety Placard to the netting near the door as shown in FIGURE 26. R e a d t h i s e n t i r e m a n u a l and make sure all jumpers completely understand all of the safety rules printed in the...

  • Page 20: User Instructions

    User Instruction Rules of using the trampoline Important: Ensure all bolts and 3. Follow the age recommendation. retaining fixings are tight and correctly 4. ALWAYS supervise children. located prior to using the trampoline and enclosure. 5. Do not perform somersaults of any type. 1.
  • Page 21 User Instruction The Front bounce 1. Start with a low bounce. 2. Land in the prone position (face down) and keep hands and arms extended forward on the mat. 3. Push off the mat with arms to return to the standing position.

  • Page 22: Care And Maintenance

    3 years due to small parts, chocking hazard. If you need help or have damaged or missing parts,call the Customer Helpline:0843-5034455. Produced for Chad Valley Toys. Country of origin: China Address: 488 - 499 Avebury Boulevard, Central Milton Keynes, MK9 2NW.
