INSYS EDGE 5.0 Series Manual

Hide thumbs Also See for EDGE 5.0 Series:
Table of Contents

Advertisement

Quick Links

Download this manual
INSYS GPRS/EDGE 5.0
serial
Sep-10

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EDGE 5.0 Series and is the answer not in the manual?

Questions and answers

Related Manuals for INSYS EDGE 5.0 Series

Summary of Contents for INSYS EDGE 5.0 Series

  • Page 1 INSYS GPRS/EDGE 5.0 serial Sep-10...
  • Page 3 MNP is a registered trademark of Microcom Inc. IBM PC, AT, XT are registered trademarks of International Business Machine Corporation. INSYS ® is a registered trademark of INSYS MICROELECTRONICS GmbH. Windows™ is a registered trademark of Microsoft Corporation. Linux is a registered trademark of Linus Torvalds.

  • Page 4: Table Of Contents

    Contents Scope of Delivery ....................7 General ........................ 8 Function Overview......................8 Application Example......................9 History..........................10 Utilization Notes ....................11 Mounting ......................12 Front Panel ........................12 Top.............................13 Bottom ..........................13 HSComm GPRS ........................14 Initial Operation........................15 4.5.1 Installation ........................15 4.5.2 Driver Installation ......................16 4.5.3 Entering the SIM PIN into the Device.................
  • Page 5 6.7.1 Automatic SMS Dispatch Via Switch Input .............. 62 6.7.2 Connection Setup via Switch Input ................65 6.7.3 Transmitting Input States to Another INSYS GPRS/EDGE 5.0 serial (IO Tunnelling)........................66 Remote Configuration ......................71 Firmware Update ......................71 6.10 Virtual COM Port.......................72 Short Description INSYS AT Commands ............
  • Page 6 Contents GPRS Dial-In Parameters................... 91 FAQ ........................92 Technical Data....................97 12.1 General 97 12.2 Mechanical Features......................97 12.3 Power Supply ........................98 Connections, Display and Control Elements ............ 99 13.1 Serial Interface........................100 13.2 SIM Card 100 13.3 Internal Design........................101 Standards and Directives ................102 Declaration of Conformity................

  • Page 7: Scope Of Delivery

    Scope of Delivery Before you begin with the initial operation, please check if all accessories are in- cluded in the box.  INSYS GPRS/EDGE 5.0 serial  PC connection cable 9/9-pin (RS232 cable)  User Guide Please contact your supplier if the content is not complete. Please also check the modem for shipping damage.

  • Page 8: General

     INSYS GPRS 5.0 serial  INSYS EDGE 5.0 serial These two devices are referred to as INSYS GPRS/EDGE 5.0 serial in this manual. The EDGE version also supports EDGE functions in addition to all GSM, SMS and GPRS functions. Both DIN rail devices for industrial applications have the follow- ing characteristics in common: 2.1 Function Overview...

  • Page 9: Application Example

     Integrated SIM reader and external SIM interface for 3V / 1.8 V SIM cards  Hardware watchdog  Extended data formats for the serial interface  Hardware and software handshake at the serial interface  Field strength of the GSM network, status display of the INSYS GPRS/EDGE 5.0 serial Application Example GPRS...

  • Page 10: History

    General INSYS GPRS/EDGE 5.0 serial History Version Additional functions  Redesign 1.00  Further development:  Accepts incoming TCP connections ("TCP Listen"), replacement destinations for AutoDial  Substitute access for TCP Leased Line 2.001  Termination of GPRS connections for in- coming CSD calls ("CSDPRIO")

  • Page 11: Utilization Notes

    INSYS GPRS/EDGE 5.0 serial Utilization Notes 3 Utilization Notes  This manual uses the symbol for especially important notes. Further notes will be marked accordingly.  All factory settings are marked “default”.  In Chapters 4.6 to 7 the description consists of two columns. Individual functions are described on the left side.

  • Page 12: Mounting

    Mounting Front Panel INSYS Power Status Connect RX/TX Signal Reset GPRS The INSYS GPRS/EDGE 5.0 serial has five LEDs for the operating state: Name Colour LED off LED on LED blinks LED flashes No supply volt- Supply voltage Power Green...

  • Page 13: Top

    INSYS GPRS/EDGE 5.0 serial Mounting Name Colour LED off LED on LED blinks LED flashes RX/TX Date is exchanged No data ex- (Receive / Green via the modem change Transmit) Blinking interval depending on GSM signal (field strength): 25 .. 31...

  • Page 14: Hscomm Gprs

    INSYS GPRS/EDGE 5.0 serial HSComm GPRS The configuration of the INSYS GPRS/EDGE 5.0 serial takes place via AT commands which are entered by a terminal program or a control program in the form of char- acter sequences. For a simpler set-up, all basic functions of the INSYS GPRS/EDGE 5.0 serial can be entered without knowing the individual AT commands and their...

  • Page 15: Initial Operation

    INSYS GPRS/EDGE 5.0 serial Mounting Initial Operation 4.5.1 Installation Caution - Electric shock hazard Do not touch live parts when connecting the device. Make sure that the power supply of the switch board or the system where the device will be installed is switched off during installation, and that it is secured against being switched on accidentally.

  • Page 16: Driver Installation

    Install the configuration software HSComm GPRS and/or your terminal program. 10. Start the program HSComm GPRS on the PC. 11. Synchronize the serial interfaces of the PC and the INSYS GPRS/EDGE 5.0 serial  At delivery, the serial interface settings of the INSYS GPRS/EDGE 5.0 serial are as follows: 8 data bits, no parity, 1 stop bit, data...

  • Page 17: Entering The Sim Pin Into The Device

    4.5.3 Entering the SIM PIN into the Device Start the program HSComm GPRS. Read out the settings. Enter the PIN of the SIM card you are using. Transmit the value to the INSYS GPRS/EDGE 5.0 serial.  Use the button "Send settings".

  • Page 18: Inserting The Sim Card

    Disconnect the power supply.  The LEDs of the INSYS GPRS/EDGE 5.0 serial will go out. Remove the SIM card holder.  Press the sunken button (see image) above the SIM card holder...

  • Page 19: Checking The Settings

    4.5.5 Checking the Settings Read out the settings.  Click on the button "Read settings" in the software HSComm GPRS.  A symbol next the entry field of the PIN will show, if the INSYS GPRS/EDGE 5.0 serial has been registered.

  • Page 20: Checking The Field Strength Of The Gsm Signal

    Mounting INSYS GPRS/EDGE 5.0 serial 4.5.6 Checking the Field Strength of the GSM Signal Read out the GSM field strength.  Use the button "GSM signal" in HSComm GPRS.  The field strength is displayed.  The response should be a field strength of at least 12 – other- wise the antenna location needs to be changed to ensure fault- less communication.

  • Page 21: Setting The Gprs Apn (Access Point Name) Dial-In Parameters

    INSYS GPRS/EDGE 5.0 serial Mounting 4.5.7 Setting the GPRS APN (Access Point Name) Dial-In Parameters Click on the tab "GSM/GPRS" in the program HSComm GPRS.  see also Chapter 11 - GPRS Dial-in Parameters - Enter the GPRS Access Point Name in the software HSComm GPRS or se- lect it from the list.

  • Page 22: Connection To The Application

    Use the reset key at the front of the device or disconnect the de- vice from the power supply for a short time. 4.5.8 Connection to the Application For the operation, the application settings and the settings of the INSYS GPRS/EDGE 5.0 serial for baud rate, data format and handshake must be identical.

  • Page 23: Operating Modes

    INSYS GPRS/EDGE 5.0 serial Mounting Operating Modes 4.6.1 Command Mode 4.6.1.1 Offline The offline command mode is the state after the GSM/GPRS engine was booted and initialized, or after a reset of the {{{PRODUCT DESCRIPTION}}}. During the offline command mode the {{{PRODUCT DESCRIPTION}}} can be addressed via AT commands.

  • Page 24: Connection

    Connection INSYS GPRS/EDGE 5.0 serial Connection Connection Target Bearer Trigger Chap. TCP transparent (mo- TCP/IP GPRS  AT command dem emulation) EDGE  Incoming con- nection request  SMS  Callback  Leased Line  Switch input Modem  AT command ISDN ...
  • Page 25 INSYS GPRS/EDGE 5.0 serial Connection Note As default, the INSYS GPRS/EDGE 5.0 serial will login to the strong- est available GSM network. In regions close to borders, registering into the desired network is not always suc- cessful. Manually selecting the exclusively preferred network will correct this problem.
  • Page 26 INSYS GPRS/EDGE 5.0 serial Transfer the current settings to the INSYS GPRS/EDGE 5.0 serial. Afterwards, the device must be reset. After the current settings have been read out, the INSYS GPRS/EDGE 5.0 serial is registered. If the device is preconfigured for another country, a search for the desired net- work provider will be useful.

  • Page 27: Tcp Transparent (Gprs/Edge Modem Emulation)

    5.2.1 General In this mode, user data is transmitted transparently via the serial interface and in TCP/IP packets via the GSM/GPRS/EDGE network. The INSYS GPRS/EDGE 5.0 serial will act like a conventional modem at the serial interface. The remote terminal for this connection type receives the TCP/IP data and evalu- ates them directly, or has a virtual COM port driver (see Chap.

  • Page 28: Defaults

    5.2.1.2 Incoming TCP Connections The INSYS GPRS/EDGE 5.0 serial is addressed via its IP address. Its IP address must be routable. The IP address may be static or dynamic. For dynamic IP addresses, the INSYS GPRS/EDGE 5.0 serial supports the function to communicate the IP ad- dress it received during the dial-up into the GPRS/EDGE network to a remote ter- minal (see Chapter VCOM).
  • Page 29 INSYS GPRS/EDGE 5.0 serial Connection  user:<username> or pw:<password> PAP authentification, user name or password is required as stated.  user: or pw: No authentication, user name or password is required.  user:[any] or pw:[any] PAP authentification, any user name or any password is required.

  • Page 30: Settings For Leased Line

    Connection INSYS GPRS/EDGE 5.0 serial 5.2.3 Settings for Leased Line The INSYS GPRS/EDGE 5.0 serial will automatically establish a leased line after the device is switched on, or after a reset. The connection is monitored and re- established after interruptions.
  • Page 31 It is based on the following mechanism: If the INSYS GPRS/EDGE 5.0 serial is restarted in leased line operation, the pre- defined AutoDial default destination is dialed after 20 seconds. If the connection setup fails, the device will attempt to dial the AutoDial alternative destination.

  • Page 32: Settings For Tcp Listen (Incoming Tcp Connections)

    Connection INSYS GPRS/EDGE 5.0 serial The alternative destination is specified with the following settings: Connection to an IP address as alternative access Setting for leased line function AT**LL2=2 Remote terminal IP address AT**AUTOIP2=<ip> Remote terminal TCP port AT**AUTOPORTIP2=<port> Save settings...
  • Page 33 The successful dial-up into the GPRS/EDGE network is displayed after the startup with the message +PPP-IP SETUP; the INSYS INSYS GPRS/EDGE 5.0 serial can now be reached via its IP address. If the connection can not be established (network failure, etc.) or if the connection is terminated, the INSYS GPRS/EDGE 5.0 serial will automatically start reconnect-...

  • Page 34: Manual Connection Setup

    The connection setup and the connection itself are monitored. If the connection can not be established (network failure, remote system does not respond) or if the connection is terminated, the INSYS GPRS/EDGE 5.0 serial will automatically start reconnecting. To limit the connection costs for inaccessible remote terminals (for each connec- tion setup data packets are created and billed), the delay time will increase for every new repeated attempt.

  • Page 35: Connection Acceptance

    The connection was accepted. CONNECT As soon as the INSYS GPRS/EDGE 5.0 serial has displayed the message PPP-IP SETUP, it can be reached by incoming TCP connections, i.e. it is in Listen mode at the TCP port which has been set with the command AT**TCPLISTENPORT.
  • Page 36 INSYS GPRS/EDGE 5.0 serial Please find an overview in the Chapter "7. AT commands". The INSYS GPRS/EDGE 5.0 serial is able to independently and periodically check its status in the GPRS/EDGE network and thus its availability. Use the command AT**PPPIPCHECK.

  • Page 37: During The Connection

    If three successive monitoring packets are not responded to, the connection is re- garded as terminated, and the INSYS GPRS/EDGE 5.0 serial returns to offline mode. If the device is configured as a leased line device, the connection will then be re-established.

  • Page 38: Termination

    TCP packets in the integrated TCP/IP stack helps prevent un- necessary high costs for the data transmis- sion. The INSYS GPRS/EDGE 5.0 serial sends a data packet to the remote terminal when: AT**TCPBLOCK=  The maximum set value (default: 512 <block-size>...

  • Page 39: Gsm Data Connection (Csd Call)

    GPRS/EDGE service. Remote terminals for the connection can be analogue modems, ISDN adapter, or GSM devices. With the help of HSComm GPRS/EDGE, the INSYS GPRS/EDGE 5.0 serial can auto- matically accept the CSD call. Click on the tab “GSM/GPRS”.

  • Page 40: Termination

    Connection INSYS GPRS/EDGE 5.0 serial Incoming connections are indicated in the RING terminal program. The connection acceptance takes place ei- ATS0=<n> ther automatically, or after a set number <n> of ring signals, or manually with the command ATA. The indicator for incoming connections can in addition display also the connection type (data, voice) (AT+CRC=1) and the phone number of the caller (AT+CLIP=1) as an option.

  • Page 41: Connection To Analogue Modems

    PPP data after dial-up into the GPRS/EDGE network. In this case, the application must perform the required protocol stacks (PPP, TCP/IP) for the application. In this mode, the TCP/IP stack of the INSYS GPRS/EDGE 5.0 serial is not active.

  • Page 42: Gprs/Edge Apn (Pdp Context)

    5.4.2 PPP Authentication Type To adjust the authentification type to the one used by the PPP client of the appli- cation, the INSYS GPRS/EDGE 5.0 serial offers two possibilities:  No authentication AT^SGAUTH=0 ...

  • Page 43: Gprs/Edge Connection Termination

    INSYS GPRS/EDGE 5.0 serial Connection 5.4.4 GPRS/EDGE Connection Termination Connections can be terminated as follows:  Manual termination using the ATH command in online command mode  By DTR drop (for the setting AT&D2) After switching from data mode to online mode, the connection will remain estab- lished.

  • Page 44: Setup And Disconnetction Of A Tcp Connection

    Connection INSYS GPRS/EDGE 5.0 serial Setup and Disconnetction of a TCP Connection 5.5.1 Overview A connection with the APN (access point to the GPRS/EDGE network) is required for a TCP communication in the GPRS/EDGE network (only the GPRS network is mentioned in the following for reasons of simplicity) first;...

  • Page 45: Connection Setup Possibilities

    INSYS GPRS/EDGE 5.0 serial Connection 5.5.2 Connection Setup Possibilities Manual connection setup In case of a manual connection setup (command ATD<IP address>:<port> or ATD<“domain name“>:<port>), a connection to the GPRS network (GPRS At- tach) is performed first. After the connection with the GPRS network has been es- tablished, a TCP connection to the specified IP address or domain will be estab- lished via the specified port.

  • Page 46: Functions

    Functions INSYS GPRS/EDGE 5.0 serial Functions Access Control Password protection and selective call acceptance can be set us- ing HSComm. 6.1.1 Password Protection The password consists of a maximum of 16 characters and pro- tects  switching into remote configuration during a data connec- tion (CSD or “TCP transparent”)

  • Page 47: Selective Call Answer

    INSYS GPRS/EDGE 5.0 serial Functions Alternatively, a new password can be set or an old password can be changed or deleted using the terminal program. Setup new password AT**PASSC=<newPW>,<newPW> Change password AT**PASSC=<old PW>,<newPW>, <newPW> Delete password AT**PASSC=<old PW> 6.1.2 Selective Call Answer If this function is activated, only connections which originate from the released phone numbers (1 to 3) are accepted.
  • Page 48 Functions INSYS GPRS/EDGE 5.0 serial Alternatively, the access control can be set using the terminal program: Activating selective call acceptance AT**CLIP=1 Deactivating selective call acceptance AT**CLIP=0 Note: The settings are only changed after they were AT**SAVE saved and the device has been reset.

  • Page 49: Establishing A Connection By Callback

    In connection with the function CSDPRIO (see Chapter 4.3), it is also possible to trigger a callback if the called INSYS GPRS/EDGE 5.0 serial has a TCP connection or is dialed into the GPRS network in the operating mode TCP Listen during the call.
  • Page 50 Functions INSYS GPRS/EDGE 5.0 serial Alternatively, the access control can be set using the terminal program: Default: For the operation within the GPRS network, an Access Point and the GPRS access data must be selected. Activate selective call acceptance AT**CLIP=1 Enter allowed phone number 1 AT**CLIP1=<nr1>...
  • Page 51 01711253456 exists. Furthermore, the service center has a fixed internet connection with the IP address: 200.12.0.120; the TCP port 10000 was en- abled for connections to the INSYS GPRS/EDGE 5.0 se- rial. Click on the "Connections” tab.
  • Page 52 Functions INSYS GPRS/EDGE 5.0 serial In a second step, the IP target for the callback must be entered. Afterwards, the automatic call acceptance after 2 ring tones is required. Alternatively, our example can be set using the terminal program: In general, activate selective call acceptance...

  • Page 53: Defined Termination Of Gprs Connections For Incoming Csd Calls ("Csdprio")

    The reasons may be as follows:  To perform time-critical applications (e.g. software updates from controllers).  To enable service technicians to access the application or the INSYS GPRS/EDGE 5.0 serial, which are not integrated in the communication system based on TCP connections.

  • Page 54: Csd Priority With Caller Authentication

    Example: If the INSYS GPRS/EDGE 5.0 serial is set using ATS0=2 for accepting CSD connections after two ring tones, in general actually 5 to 6 ring tones (RINGs) are required.

  • Page 55: Csd Priority Without Caller Authentication

    Alternatively, the function can be set using the terminal program: In general, activate selective call acceptance AT**CLIP=1 (To activate the call signals or enable them to be processed by the INSYS GPRS/EDGE 5.0 se- rial, this setting must be entered.) Activate CSDPRIO without phone number au- AT**CSDPRIO=2...

  • Page 56: Automatic Login At Restart

    Functions INSYS GPRS/EDGE 5.0 serial 6.4.1 Automatic Login at Restart The INSYS GPRS/EDGE 5.0 serial can store the SIM card PIN AT**PIN=<pin> internally, which enables it to log into the GSM network after each restart and reset, without user intervention.
  • Page 57 INSYS GPRS/EDGE 5.0 serial Functions Examples: In our example 1, the INSYS GPRS/EDGE 5.0 serial will be logged out and back in every 3 hours. Alternatively, the scheduled logout/login AT**LOGOUT=<n>[,<mode>] can be set, changed or deleted using the terminal program.

  • Page 58: Automatic Sms Processing

    Activation in HSComm is done by clicking the automatic SMS processing. Each incoming SMS is deleted after it has been processed. Each SMS with an INSYS AT command is processed. Any other SMS is immediately deleted. If other SMS messages are required for processing with the appli- cation, the field “Leave remote SMS in SIM buffer”...

  • Page 59: Reading Interval

    GPRS calls and “TCP transparent” calls via GPRS). Experience shows that an SMS is only sent during data transmission breaks longer than 30 seconds. 6.5.3 Syntax SMS intended for the INSYS GPRS/EDGE 5.0 serial must have the following syntax: [<password>,]<command>[,CN: [<callbacknumber>]]...

  • Page 60: Access Protection

    Note: Between CN: <phonenumber> a space must be entered. If no phone number is entered after CN: the response returns automatically to the sender. Configuration via SMS, if the INSYS GPRS/EDGE 5.0 serial is <password>, protected by a password. <command>...

  • Page 61: Sms Storage Locations

    ERROR as response. The applica- tion should therefore execute the command once more, if necessary. The INSYS GPRS/EDGE 5.0 serial evaluates all SMS storage locations made available by the GSM/GPRS engine (storage locations of the SIM card and storage locations in the engine itself).

  • Page 62: Digital Inputs And Potential-Free Outputs

    AT commands to control external functions. The inputs can be used to trig- ger an action of the INSYS GPRS/EDGE 5.0 serial. The inputs can be used to dial a connec- tion to an AutoDial destination or to send an SMS. The action is triggered through a change of the input from HIGH (inactive) to LOW/GND (active).
  • Page 63 INSYS GPRS/EDGE 5.0 serial Functions...
  • Page 64 Functions INSYS GPRS/EDGE 5.0 serial Alternatively, our example can be set using the terminal program: In this example, you must note the order of the AT commands! AT**INPUT1=1 Automatic activation of SMS dispatch AT**INPUT1=2 AT**INPUT1=1 for input 1; if you want to use only 1 switch input, use input 1.

  • Page 65: Connection Setup Via Switch Input

    INSYS GPRS/EDGE 5.0 serial Functions Save settings for advanced functions AT**SAVE Save settings for SMS commands AT&W Perform RESET, accept all parameters AT**RESET 6.7.2 Connection Setup via Switch Input By changing the input states, connections can be established to the predefined AutoDial destinations automatically.

  • Page 66: Transmitting Input States To Another Insys Gprs/Edge 5.0 Serial (Io Tunnelling)

    The "Leased Line" function must be active at the INSYS GPRS/EDGE 5.0 serial so it can estab- lish a permanent connection to the other INSYS GPRS/EDGE 5.0 serial. The second device uses the TCP Listen function to accept the connection of the first device.
  • Page 67 INSYS GPRS/EDGE 5.0 serial Functions Configuration of the first device:...
  • Page 68 Functions INSYS GPRS/EDGE 5.0 serial Configuration of the second device:...
  • Page 69 INSYS GPRS/EDGE 5.0 serial Functions Alternatively, this function can be set using the terminal program: Configuration of the first device: Enter the output device as AutoDial address: AT**LL=2 Activate the leased line operation to the IP address of AT**AUTOIP=100.1 the other device 20.32.5...
  • Page 70 Functions INSYS GPRS/EDGE 5.0 serial Values for <n>: 1-255 (minutes) AT**INPUTTIMEOUT =<n> The option AT**INPUTTIMEOUT Option can be used si- multaneously with AT**INPUTCHANGE. AT**INPUTTIMEOUT prevents the provider from termi- nating the unused, open connection. Save the settings. AT**SAVE Save the standard settings.

  • Page 71: Remote Configuration

    INSYS GPRS/EDGE 5.0 serial Functions Remote Configuration During a CSD or “TCP transparent” data connection, the INSYS <pause> GPRS/EDGE 5.0 serial can be switched to remote command mode **** by entering the escape sequence via the data connection from <pause>...

  • Page 72: Virtual Com Port

    COM port to the operating system avail- able on the other side. Click on the “Serial/VCom” tab. INSYS MICROELECTRONICS GmbH offers a free virtual COM port for the operating systems Windows XP/2000. The virtual COM port provides the following functions: 6.10.1.1 Authentication for Outgoing TCP Connection:...
  • Page 73 UDP packet in advance. This function is also used to terminate a "hanging" TCP connection for the INSYS GPRS/EDGE 5.0 serial (e.g. due to a network failure or a crash of the remote terminal). When a valid UDP packet is re- ceived, the existing TCP connection is terminated to be able to accept the new connection.

  • Page 74: Short Description Insys At Commands

    Short Description INSYS AT Commands INSYS GPRS/EDGE 5.0 serial Short Description INSYS AT Commands Overview Implementation possible Offline local for Command Short description Offline active PPP con- Online Remote SMS local nection (TCP local Listen) Establish CSD or “TCP transparent” connec- tions Terminate CSD or “TCP...
  • Page 75 INSYS GPRS/EDGE 5.0 serial Short Description INSYS AT Commands Implementation possible Offline local for Command Short description Offline active PPP con- Online Remote SMS local nection (TCP local Listen) Display of SIM-IMSI AT**IMSI Query of the switch AT**IN inputs Determine event han-...
  • Page 76 Short Description INSYS AT Commands INSYS GPRS/EDGE 5.0 serial Implementation possible Offline local for Command Short description Offline active PPP con- Online Remote SMS local nection (TCP local Listen) TCP block formation timer of the integrated AT**TCPAGG TCP/IP stack: TCP block size of the...

  • Page 77: Availability/Storage

    INSYS GPRS/EDGE 5.0 serial Short Description INSYS AT Commands Availability/Storage The following INSYS AT commands are saved immediately after they are entered without AT**SAVE, but only activated after a restart.  AT**PROVIDER  AT**PIN  AT**GPRSAPN  AT**PPPAUTH The following settings are immediately saved when entered, and active: ...

  • Page 78: Gsm, Gprs, And Edge General

    GSM, GPRS, and EDGE General INSYS GPRS/EDGE 5.0 serial GSM, GPRS, and EDGE General Application Notes 8.1.1 GSM The provider enables the requested services. A SIM card can be enabled for voice and data services at the same time. The following table lists the usually available cards and contracts.

  • Page 79: Network Design

    Internet Protocol (IP). The following figure shows the basic design, where the application has to provide the TCP/IP/PPP stacks. This is required when using the standard GPRS functional- ity of the INSYS GPRS/EDGE 5.0 serial. Application Remote...

  • Page 80: Tcp Transparent

    There is no need for the application to process any additional protocol stacks. To establish TCP connections to the INSYS GPRS/EDGE 5.0 serial, it is necessary to ac- cess the IP address of the GPRS device. This function must be supported by the net- work operator or the provider.

  • Page 81: Ip Addresses/Accessibility

    INSYS GPRS/EDGE 5.0 serial GSM, GPRS, and EDGE General IP Addresses/Accessibility The IP address of the GPRS terminal is dynamically allocated by the provider and therefore only temporary. During the next dial-in at the provider, a new IP ad- dress is allocated.

  • Page 82: Fixed Ip Address And Vpn Connection

    The service fixed.IP from mdex will enable GPRS devices to communicate with each other as well as with computers in the Internet via a VPN connection. Data Rates The INSYS GPRS/EDGE 5.0 serial has the following characteristics:  GPRS Multislot class 12, Coding Scheme 1 to 4 ...
  • Page 83 INSYS GPRS/EDGE 5.0 serial GSM, GPRS, and EDGE General Multislot class Downlink slots Uplink slots Active slots 4 TS 1 TS 5 TS 3 TS 2 TS 5 TS 4 TS 2 TS 5 TS 4 TS 3 TS 5 TS...

  • Page 84: Quality Of Service (Qos)

    GSM, GPRS, and EDGE General INSYS GPRS/EDGE 5.0 serial In the device class B, the INSYS GPRS/EDGE 5.0 serial supports the GSM services EDGE (optional), GPRS, CSD and voice. However, only one service can be executed at a time. Quality of Service (QoS) The above mentioned characteristics data rates (in the form of values such as “data amount per hour”...

  • Page 85: Calculation Examples For Data Transmission Via Gprs

    GPRS modem. This is what the INSYS GPRS/EDGE 5.0 serial is used for. It is also used for leased line operation, i.e. after being switched on it will automatically attempt to estab- lish a connection with the remote terminal, the INSYS virtual COM port.

  • Page 86: General Data Amount

    GSM, GPRS, and EDGE General INSYS GPRS/EDGE 5.0 serial 8.8.1.2 Data Logger User Data A data logger message has the following setup: Device ID 4 byte 2 x 8 bit for the digital inputs 2 byte 4 x 16 bit for the analogue inputs...
  • Page 87 TCP message in adjustable intervals which the TCP remote terminal responds to. This will satisfy the expectations of the provider regarding the amount of data. The INSYS GPRS/EDGE 5.0 serial will provide this function. The application will not notice this action.

  • Page 88: Calculation Example

    The following examples show merely the pure data transmission. When a TCP/IP connection is established via the INSYS GPRS/EDGE 5.0 serial, data is also gener- ated (128 byte). The INSYS GPRS/EDGE 5.0 serial will not terminate a once estab- lished connection automatically, i.e. the amount of data for the connection setup may be ignored.
  • Page 89 INSYS GPRS/EDGE 5.0 serial GSM, GPRS, and EDGE General Transmission of values every 15 minutes  Without user data acknowledge 95 byte / 15 min  380 byte / 1 h  9120 byte / 24 h  rounded to 9 kb / day ...

  • Page 90: Sending Sms As Fax Or E-Mail

    Sending SMS as Fax or E-Mail INSYS GPRS/EDGE 5.0 serial Sending SMS as Fax or E-Mail Overview of network providers for German speaking countries (D, A, CH). All nec- essary information is available from the customer service center of the provider.

  • Page 91: Gprs Dial-In Parameters

    INSYS GPRS/EDGE 5.0 serial GPRS Dial-In Parameters GPRS Dial-In Parameters Overview of network providers for German speaking countries (D, A, CH). All neces- sary information is available from the customer service center of the provider. Note: In HSComm we prepared numerous European APNs for selection.

  • Page 92: Faq

    INSYS GPRS/EDGE 5.0 serial Problem: Possible cause: Remedy The INSYS GPRS/EDGE 5.0 The location of the GSM Check the signal quality of the GSM net- serial does not log in: antenna is incorrect. work. For low field strength – below 12 –...
  • Page 93 Problem: Possible cause: Remedy No reaction to AT com- The serial interface settings The INSYS GPRS/EDGE 5.0 serial and the mands. at INSYS GPRS/EDGE 5.0 application (configuration PC or control- serial and at the application ler) must be operated at the serial inter- are not identical.
  • Page 94 Enter the AT command AT+CGATT=1. are displayed. Afterwards, query the network registra- tion status with AT+CGATT?. If the INSYS GPRS/EDGE 5.0 serial re- sponds as follows:  +CGATT: 1 the device is registered in the GPRS network.  +CGATT: 0 the device could not be registered in the GPRS network.
  • Page 95 – Installation – No. 16) The virtual COM port from The virtual COM port is not Check the settings for the virtual COM INSYS should be used. The activated. port driver on the tab “Serial/Vcom”. device can not be accessed via the virtual COM port.
  • Page 96 INSYS GPRS/EDGE 5.0 serial Problem: Possible cause: Remedy Existing GPRS connection Some providers disconnect Such disconnections can be prevented ceases. connections with no traffic using the TCP keep-alive ( AT**KEEP for an extended period. and PPP check ( AT**PPPIPCHECK functions.

  • Page 97: Technical Data

    INSYS GPRS/EDGE 5.0 serial Technical Data Technical Data 12.1 General GPRS Multislot class 12 GPRS data transmission Coding scheme 1 to 4 EDGE Multislot class 12 EDGE data transmission Modulation and coding scheme 1 to 9 Mobile Station Class B...

  • Page 98: Power Supply

     The antenna and/or the antenna cable are not adjusted to 50 Ω impedance.  The antenna that is being used is misaligned due to the situation at the instal- lation site (metal parts …). To operate the INSYS GPRS/EDGE 5.0 serial, a suitable device protection must be used. Power supply: 10.0.60 V DC...

  • Page 99: Connections, Display And Control Elements

    INSYS GPRS/EDGE 5.0 serial Connections, Display and Control Elements Connections, Display and Control Elements Position Description Antenna connection RS232 interface connection LEDs SIM card slot SIM card eject button - not used - Reset key...

  • Page 100: Serial Interface

    13.2 SIM Card The INSYS GPRS/EDGE 5.0 serial requires a 3V/1.8V SIM card from a GSM provider for operation. The SIM card is the identification for the network provider. The SIM card must be placed into the carrier with the contacts downward to en- sure that the contacts are on top of each other.

  • Page 101: Internal Design

    Connections, Display and Control Elements 13.3 Internal Design For the INSYS GPRS/EDGE 5.0 serial, a µcontroller is placed in series between the external serial interface and the GSM/GPRS/EDGE engine. All commands sent to the INSYS GPRS/EDGE 5.0 serial via the serial interface are first received and evaluated by the µcontroller.

  • Page 102: Standards And Directives

    Standards and Directives INSYS GPRS/EDGE 5.0 serial Standards and Directives The INSYS GPRS/EDGE 5.0 serial complies with the directives 89/336/EEC, 73/23/EEC, and R&TTE 1999/5/EG. It complies with the following standards:  DIN EN 55022: 1998-04 class B  DIN EN 61000-6-2 ...

  • Page 103: Declaration Of Conformity

    INSYS GPRS/EDGE 5.0 serial Declaration of Conformity Declaration of Conformity...
  • Page 104 Declaration of Conformity INSYS GPRS/EDGE 5.0 serial...

  • Page 105: International Safety Instructions

    INSYS GPRS/EDGE 5.0 serial International Safety Instructions International Safety Instructions The following Siemens safety instructions in English apply to the used GSM/GPRS engine TC63 and MC75. Following US FCC specifications, each device must have a sticker with a note referring to the “FCC ID” attached.

  • Page 106: Compliance With Fcc Rules And Regulations

    International Safety Instructions INSYS GPRS/EDGE 5.0 serial IMPORTANT! Cellular terminals or mobiles operate using radio signals and cellular networks. Be- cause of this, connection cannot be guaranteed at all times under all conditions. Therefore, you should never rely solely upon any wireless device for essential com- munications, for example emergency calls.
