Specifications:

 Model/Capacity Matrix:
Excel 10: 0 to 500 g x 1 g, 505 to 10000 g x 5 g
Excel 20: 0 to 500 g x 1 g, 505 to 20000 g x 5 g
Excel 30: 0 to 500 g x 1 g, 510 to 30000 g x 10 g
 Platter size: 215 x 275 mm (9" x 11")
 Overall size: 340 x 300 x 110 mm (13.4" x 11.8" x 4.3")
 Display: 6 digit backlit LCD, 0.8" (20 mm) tall, backlight is LED
 Color: Black and gray
 Keys: 2-key tactile switch keypad
 Functions: ZERO, PCS (piece counting), UNIT key not used
 Power: AC Adapter UL/CUL approved Input: 120 VAC, 60Hz, 5 Watts. Output:
9 VDC, 200mA Class 2 AC-DC power adapter model A20920N
 Foot: Adjustable (5)
 Calibration test weight : Fixed: 100% of scale capacity
 Warranty: 3 months
 USB for connection to PC running FP Navigator

Features

 Accurate and reliable
 Piece Count feature
 Compact and lightweight

Backlight for LCD
