ORION PDP 84MPDP User Manual

Seam less multi pdp
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
84MPDP
Seam less Multi PDP
USER'S MANUAL
Made in Korea
84"
Thank you for your purchasing our Plasma display monitor.
Please read through this user's manual for safety before installing this product.
This product is manufactured for Plasma display model only.
Made in Korea

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 84MPDP and is the answer not in the manual?

Questions and answers

Related Manuals for ORION PDP 84MPDP

Summary of Contents for ORION PDP 84MPDP

  • Page 1 84MPDP Seam less Multi PDP USER'S MANUAL Made in Korea 84" Thank you for your purchasing our Plasma display monitor. Please read through this user's manual for safety before installing this product. This product is manufactured for Plasma display model only.

  • Page 2: Table Of Contents

    Contents Features of Plasma monitor Preparing Keep it for safety How to install the monitor (stand, hanger) You can enjoy a wide full-flat screen with high brightness and high quality. Designation Connecting Cable It clearly and finely displays the high quality image by PDP panel with a high Buttons of remote controller resolution of 1,640,000 pixels incomparable to general TVs.

  • Page 3: Keep It For Safety

    KEEP IT FOR SAFETY • If it operates abnormally, stop using it • Do not pull out or hang down the • Do not place any container with water or • Do not input any foreign material. It may • Do not lean on this product or keep it •...

  • Page 4: How To Install The Monitor (Stand, Hanger)

    Checking components About Speakers • Customers can purchase speakers separately and should use other sound system. • Monitor has no sound function. Remote controller 2 batteries for User's manual remote controller (AAA type) About Caring • For the inside cleaning, please inquire at the dealer once a year. •...

  • Page 5: Designation

    Designation Rear side Front side S/W POWER S/W POWER SUB – APL MAIN – APL SUB – APL MAIN – APL S/W POWER S/W POWER SUB – APL MAIN – APL SUB – APL MAIN – APL Receiving glass: Receive the operation signal from the remote controller.

  • Page 6: Connecting Cable

    Connecting Cable...

  • Page 7: Buttons Of Remote Controller

    Buttons of remote controller How to use the basic menu When you press MENU button, the basic menu is displayed on the screen. The basic menu has four items such as VIDEO, MULTI, FUNCTION, and SCREEN. Each item has its subitems. When you select the desired item, that item is displayed in yellow.

  • Page 8: Connecting Pc

    Connecting PC When connecting to PC, connect the connector of the rear side of the monitor as follows: Press [POWER ON] button. S/W POWER S/W POWER POWER ON POWER OFF • Press [POWER ON] button of the remote controller or the main body to AUTO STILL SLEEP...

  • Page 9: Connecting Vcr

    Connecting VCR When connecting to VCR, connect the connector of the rear side of the monitor as follows: If there exists S-VHS connector at the VCR, refer to 'Connecting S-VHS' of the next page. Press [POWER ON] button. POWER ON POWER OFF •...

  • Page 10: Connecting S-Vhs

    Connecting S-VHS When connecting to VCR, connect the connector of the rear side of the monitor as follows: If you use S-VHS connector, you can enjoy the better video quality than VCR. Press [POWER ON] button. POWER ON POWER OFF S/W POWER S/W POWER •...

  • Page 11: Connecting Dvd

    Connecting DVD When connecting to DVD, connect the connector of the rear side of the monitor as follows: Press [POWER ON] button. POWER ON POWER OFF S/W POWER S/W POWER • Press [POWER ON] button of the remote controller or the main body to AUTO STILL SLEEP...

  • Page 12: Connecting Digital Tv

    Connecting DIGITAL TV When connecting to DIGITAL TV, connect the connector of the rear side of the monitor as follows: Press [POWER ON] button. POWER ON POWER OFF S/W POWER S/W POWER • Press [POWER ON] button of the remote controller or the main body to AUTO STILL SLEEP...

  • Page 13: Adjusting Video

    Adjusting video (DVD, VIDEO mode) Adjust it only when 30 minutes or longer elapses after turning on the monitor. Press [MENU] button. Adjust the value to what you want. POWER ON POWER OFF • Press [MENU] button to display the •...

  • Page 14: Pc Mode

    Adjusting video (PC mode) It can be set at the PC mode only. Adjust it only when 30 minutes or longer elapses after turning on the monitor. Press [MENU] button. Adjust the value to what you want. POWER ON POWER OFF •...

  • Page 15: Splitting Into Multi-Screen

    Splitting into multi-screen Setting Picture Mode (DVD, VIDEO, PC mode) (DVD, VIDEO mode) You can display the desired screen format, and you can simultaneously display DVD, VIDEO, and PC according You can select various screens with a professional's sense without user's adjustment. to the split format of the screen.

  • Page 16: Setting Language

    Setting language Adjusting Display Size (DVD, VIDEO mode) (DVD, VIDEO mode) You can set the language for the menu (OSD). You can enjoy a bigger screen by vertically magnifying 2.35:1 screen to 16:9 screen. As for PC mode, the menu screen is differently displayed. See 31 page. [ASPECT] button of the remote controller has the same function.

  • Page 17: Setting Language

    Setting language Setting Afterimage Anti Image Burn (PC mode) (PC mode) You can set the language for the menu (OSD). It removes the afterimage which may be occurred by pausing the display for a long time. As for DVD or VIDEO mode, the menu screen is differently displayed. See 29 page. It can be set at PC mode only.

  • Page 18: Setting Auto-Tracking

    Setting Auto-Tracking Setting screen position (PC mode) (PC mode) It automatically controls the position of the PC screen displayed on the screen. When the PC screen is skewed or cut, you can adjust the position of the screen. It can be set at PC mode only. It can be set at PC mode only.

  • Page 19: Setting Frequency

    Setting frequency Setting phase (PC mode) (PC mode) It can be set at PC mode only. It can be set at PC mode only. Press [MENU] button. Press [MENU] button. POWER ON POWER OFF POWER ON POWER OFF • Press [MENU] button to display the •...

  • Page 20: Hot Buttons Of Remote Controller

    Hot buttons of Remote controller Hot buttons of the remote controller help us directly setting functions without setting the menu. So, if you are familiar with these buttons, it is convenient for you to use. STILL button POWER ON POWER OFF •...

  • Page 21: Before You Consider It As A Failure

    Before you consider it as a failure About Plasma display panel Before calling for any repair, check the followings, and then call for the near A/S center. The followings are phenomena caused by the characteristics of the plasma display panel. Because it is not any failure, you may use it at rest.

  • Page 22: Specification

    Specification Resolution of PC video signal Product name PK-8420 Frequency Sync polarity Resolution Power supply 100~ 240V AC, 50/60Hz Hor(KHz) Ver(Hz) Consuming power 31.469 59.940 Normal 1,280W(Max) 640x480 37.861 72.809 Plasma display panel AC type (VGA) 37.500 75.000 84inch, 16:9 aspect ratio 43.269 85.008 Contrast ratio...

  • Page 23: To Install As Stand Type

    84MPDP Seam less Multi PDP To install as Stand Type STAND UNIT Made in Korea Please read through this user's manual for safety before installing this product. This product is manufactured for Plasma display model only. Made in Korea...
  • Page 24 1.Installation Assemble Bracket Holder to stand. Contents • Fix Bracket Holder on to post. • Insert screws to the rear of stand and fasten them with nuts from the front. BRACKET HOLDER 1.Installation 2.Monitor Installation 3.Cable Arranging Insert screws (M8*65L) and 2 washers.
  • Page 25 2. Monitor Installation Make sure monitors are Install Switcher into Bracket Holder. lifted by two or more persons for installation. • Assemble Switcher and Bracket Terminal as following figures. • Firstly, install monitor to be placed at the bottom. • There are grooves for Switcher at the bottom of the bracket terminal. •...
  • Page 26 Push installed monitors to Install monitor to be placed on top. the center to attach them together. • When installing top monitor, align guide pins of the lower monitor with grooves in the top • Align guide pins of the left and right monitors with grooves in the side monitors. monitor.
  • Page 27 Install Mask Front Up. Install mask front side. • Install Mask Front Up first. • Install Mask front side to the sides of monitor. • The side displaying logo is the Mask front down. • Fasten screws from the center. •...
  • Page 28 Install Mask Front Down. Install IR sensor to the bottom of monitor. • The side displaying logo is the Mask front down. • Install IR sensor so that it faces forward. • Fasten screws from the center. • IR sensor with cable can be connected with the Switcher through the bottom hole at the Bracket Holder.
  • Page 29 3. Cable Arranging Arrange cables after completing stand and monitor assembly. memo • After installation, arrange cables connected to various devices (power supply unit, VCR, DVD and PC, etc.) into the grooves located at the rear of post. Then, hide them with a cover to complete installation.

  • Page 30: To Install As Wall Mounting Type

    84MPDP Seam less Multi PDP To install as Wall mounting Type HANGER UNIT Made in Korea Please read through this user's manual for safety before installing this product. This product is manufactured for Plasma display model only. Made in Korea...
  • Page 31 Contents 1.Keep it for safety Please keep it! 1. Keep it for safety • Check the material of a wall and the thickness of a finishing material. • If the material of a wall is unbreakable concrete, light-weight concrete, strong natural 2.
  • Page 32 1. How to fasten anchor and bolt 2. Installation Separate brackets from wall-type securing device. • • Pull in the order and direction shown in the picture to separate them. Drill a hole with 8mm of diameter and 80mm~100mm Drill of depth at the anchor spot marked at the wall.
  • Page 33 Assemble fixing Align wall-fixing unit with the anchors installed. Fasten them with the enclosed nuts. devices for wall type and Bracket Holder. • In case bolts cannot be fastened to the designated positions, they can be fastened to the nearest •...
  • Page 34 3. Monitor Installation Make sure monitors are Connect Monitor connection cable. lifted by two or more persons for installation. • Every cable should be connected before monitor installation. • Firstly, install monitor to be placed at the bottom. Since there is no space between monitor and wall, cables should be installed first. •...
  • Page 35 Install monitor to be placed on top. Install Switcher into Bracket Holder. • When installing top monitor, align guide pins of the lower monitor with grooves in the top • Assemble Switcher and Bracket Terminal as following figures. monitor. • Connect Switcher and Monitor cable and assemble into the grooves. •...
  • Page 36 Push installed monitors to the center to attach them together. Install mask front side. • Align guide pins of the left and right monitors with grooves in the side monitors. • Install Mask front side to the sides of monitor. •...
  • Page 37 Install IR sensor to the bottom of monitor. memo • Install IR sensor so that it faces forward. Same instructions as of front down screws (M4*6L)

  • Page 38: To Install As Wall Mounting Type(Vertical)

    84MPDP Seam less Multi PDP To install as Wall mounting Type VERTICAL HANGER UNIT Made in Korea Please read through this user's manual for safety before installing this product. This product is manufactured for Plasma display model only. Made in Korea...
  • Page 39 Contents 1.Keep it for safety Please keep it! 1. Keep it for safety • Check the material of a wall and the thickness of a finishing material. • If the material of a wall is unbreakable concrete, light-weight concrete, strong natural 2.
  • Page 40 1. How to fasten anchor and bolt 2. Installation Separate brackets from wall-type securing device. • • Pull in the order and direction shown in the picture to separate them. Drill a hole with 8mm of diameter and 80mm~100mm Drill of depth at the anchor spot marked at the wall.
  • Page 41 Assemble fixing Align wall-fixing unit with the anchors installed. Fasten them with the enclosed nuts. devices for wall type and Bracket Holder. • In case bolts cannot be fastened to the designated positions, they can be fastened to the nearest •...
  • Page 42 3. Monitor Installation Make sure monitors are Connect Monitor connection cable. lifted by two or more persons for installation. • Every cable should be connected before monitor installation. • Firstly, install monitor to be placed at the bottom. Since there is no space between monitor and wall, cables should be installed first. •...
  • Page 43 Install monitor to be placed on top. Install Switcher into Bracket Holder. • When installing top monitor, align guide pins of the lower monitor with grooves in the top • Assemble Switcher and Bracket Terminal as following figures. monitor. • Connect Switcher and Monitor cable and assemble into the grooves. •...
  • Page 44 Push installed monitors to the center to attach them together. Install Mask Front Up. • Align guide pins of the left and right monitors with grooves in the side monitors. • Install Mask Front Up first. (In case of vertical installation, Mask Front Up and Mask Front Down are installed at the side of Monitor.) •...
  • Page 45 Install mask front side. Install Mask Front Down. • Install Mask front side to the sides of monitor. • The side displaying logo is the Mask front down. • Fasten screws from the center. • Fasten screws from the center. Mask Front Down Mask Front Side Fasten screws in 8 places...
  • Page 46 Install IR sensor to the bottom of monitor. memo • Install IR sensor so that it faces forward. Same instructions as of front side screws (M4*6L)
