Table of contents 1 General information about this manual 2 For your safety 3 Features 4 Connections and controls 5 Technical specifications 6 Plug and connection assignment 7 Protecting the environment User manual P43 CWA (Issue 1) 3 / 20...
NOTICE This warns of dangers that can result to faults during operation and/or considerable material damage. Environmental damage may also occur if the instructions are not followed. 4 / 20 User manual P43 CWA (Issue 1)
Page 5
General information about this manual Symbols used General warning of a dangerous location Warning – dangerously high voltage Notice User manual P43 CWA (Issue 1) 5 / 20...
DANGER Electric shock caused by high voltages inside Within the device there are areas where high voltages may be present. à Never remove any covers. There are no user-serviceable parts inside. 6 / 20 User manual P43 CWA (Issue 1)
Page 7
Operating conditions This device has been designed for indoor use only. à To prevent damage, never expose the device to any liquid or moisture. Avoid direct sunlight, heavy dirt, and strong vibrations. User manual P43 CWA (Issue 1) 7 / 20...
Page 8
à Unplug the device before electrical storms occur and when it is unused for long periods of time to reduce the risk of electric shock or fire. 8 / 20 User manual P43 CWA (Issue 1)
– Switchable pattern (cardioid or end-fire) – Power supply via locking PowerCON input – powerCON-Ausgang for additional devices – Multiplex housing – Pole mount (2 × M20) Optionally available accessories: – Transport casters User manual P43 CWA (Issue 1) 9 / 20...
Connections and controls Connections and controls ö & 10 / 20 User manual P43 CWA (Issue 1)
Page 11
– LIMIT: The red LED indicates that the limiter has been triggered. – SIGNAL: The green LED indicates that a signal is present at the input. – POWER: The green LED lights up when the device is turned on. User manual P43 CWA (Issue 1) 11 / 20...
Page 12
Lockable powerCON output socket (NAC3FCB). This output is looped through from the input socket. Here you can connect the power supply for additional devices. POWER Main switch. Turns the device on and off. 12 / 20 User manual P43 CWA (Issue 1)
Frequency range 40 Hz … 120 Hz (–3 dB) Dimensions (W × H × D) 650 mm × 400 mm × 650 mm Weight 52 kg 400 mm 650 mm 650 mm User manual P43 CWA (Issue 1) 13 / 20...
Page 14
Technical specifications Frequency response 14 / 20 User manual P43 CWA (Issue 1)
180°. Since the interference affects both cores equally, by subtracting the phase-shifted signals, the interfering signal is completely neutralized. The re- sult is a pure signal without any noise interference. User manual P43 CWA (Issue 1) 15 / 20...
Page 16
Signal (out of phase, –) XLR connector (unbalanced) Ground, shielding Signal Jumpered with pin 1 RCA connections The figure and the table show the pin assignment of an RCA connector. Signal Ground 16 / 20 User manual P43 CWA (Issue 1)
Dispose of this device through an approved waste disposal firm or through your local waste facility. When discarding the device, comply with the rules and regulations that apply in your country. If in doubt, consult your local waste dis- posal facility. User manual P43 CWA (Issue 1) 17 / 20...
