Summary of Contents for Syrincs P4
- Page 1 User manual...
- Page 2 Musikhaus Thomann Thomann GmbH Hans-Thomann-Straße 1 96138 Burgebrach Germany Telephone: +49 (0) 9546 9223-0 E-mail: info@thomann.de Internet: www.thomann.de 09.02.2016 Issue 1...
-
Page 3: Table Of Contents
Table of contents Table of contents 1 General information about this manual 2 For your safety 3 Features 4 Installation 5 Technical specifications 6 Protecting the environment 7 Plug and connection assignment User manual P4 (Issue 1) 3 / 16... -
Page 4: General Information About This Manual
NOTICE This warns of dangers that can result to faults during operation and/or considerable material damage. Environmental damage may also occur if the instructions are not followed. 4 / 16 User manual P4 (Issue 1) - Page 5 General information about this manual Symbols used General warning of a dangerous location Warning of suspended load Notice User manual P4 (Issue 1) 5 / 16...
-
Page 6: For Your Safety
à Decrease the volume level immediately if you experience ringing in your ears or hearing impairment. If this is not possible, keep a greater distance or use sufficient ear protectors. 6 / 16 User manual P4 (Issue 1) - Page 7 Operating conditions This device has been designed for indoor use only. à To prevent damage, never expose the device to any liquid or moisture. Avoid direct sunlight, heavy dirt, and strong vibrations. User manual P4 (Issue 1) 7 / 16...
-
Page 8: Features
Special features of this passive 2-way, full-range speaker: – Connection options: locking NL4 plug connector – Especially suitable for use with DSP amplifiers from Syrincs – Trapezoidal multiplex housing – Fixture on the bottom for SM 707 rotating, tilting speaker flange from Adam Hall –... -
Page 9: Installation
à When mounting the device onto a stand, ensure that the stand is in a safe and stable position and that the weight of the device does not exceed the maximum permissible load capacity of the stand. User manual P4 (Issue 1) 9 / 16... - Page 10 If you notice distortion during operation, either the amp or the speaker is over- loaded. This may permanently damage the amp or the speaker. Always reduce the volume as soon as you notice distortion. 10 / 16 User manual P4 (Issue 1)
-
Page 11: Technical Specifications
63 Hz … 20 kHz (–3 dB) Beam angle 60° × 50° Dimensions (W × H × D) 370 mm × 665 mm × 375 mm Weight 24.5 kg 665 mm 370 mm 375 mm User manual P4 (Issue 1) 11 / 16... -
Page 12: Frequency Response
Technical specifications Frequency response 12 / 16 User manual P4 (Issue 1) -
Page 13: Protecting The Environment
Dispose of this device through an approved waste disposal firm or through your local waste facility. When discarding the device, comply with the rules and regulations that apply in your country. If in doubt, consult your local waste dis- posal facility. User manual P4 (Issue 1) 13 / 16... -
Page 14: Plug And Connection Assignment
NL4 connection 1, + Signal 1 (in phase) 1, – Signal 1 (out of phase) 2, + Signal 2 (in phase) 2, – Signal 2 (out of phase) 14 / 16 User manual P4 (Issue 1) - Page 15 Notes User manual P4 (Issue 1) 15 / 16...
