Sony D-193 Operating Instructions (primary manual) Operating Instructions page 2

zPower Sources
Playing a CD in a car
Using rechargeable
You can use your player in a car as illustrated
batteries
below.
Charge rechargeable batteries before using
them for the first time.
Use only NC-DMAA rechargeable batteries
for this player. Do not use any other
rechargeable batteries.
1
Open the lid of the battery compartment.
To connect your player to a car cassette deck,
you need the following accessories:
• Car connecting pack
• Car battery cord 2
Insert 2 rechargeable batteries by
or,
matching the ' and ' to the diagram
• Mount kit CPM-300PC (Mount plate + Car
inside the battery compartment and close
connecting pack + Car battery cord)
the lid.
• Car battery cord with car connecting pack
DCC-E26CP
Refer to the instruction manual of each
accessory for details.
When you use the CPM-300PC mount
kit/CPM-300P mount plate
Attach the car mount adaptor supplied to the
CPM-300PC/300P before installing the
player.
Notes
• Do not put the player on the dashboard.
3
• Do not leave the player in a car parked under
Connect the AC power adaptor.
sunlight.
The indication "CHG" lights up. Charge
• If the sound is distorted, set MEGA BASS to
for about 3.5 hours.
OFF.
• Use a Sony car connecting pack for reducing
noise.
• Use only the car battery cord listed in the
optional accessories. If you use any other car
battery cord, smoke, fire or malfunction may
occur.
Switched ignition function
(when using the car battery cord)
With this feature, your player stops
automatically when you turn off the engine of
the car. (This function is not possible with
some cars depending on the model.)
AC power adaptor
to a wall outlet
4
When fully charged, "CHG" disappears.
Disconnect the AC power adaptor.
When to replace the rechargeable
batteries
If the i indication appears in the display and
the sound becomes inaudible, charge the
rechargeable batteries, because the batteries
are used up.
To keep the original battery capacity for a
long time, recharge the batteries when they
are used up (discharged).
Notes
• Charging time varies depending on how the
rechargeable battery is used.
• If the battery is new or has not been used for a
long time, it may not be charged completely
until you charge and discharge it several times.
• If the battery life becomes shorter by about half,
replace it with Sony NC-DMAA rechargeable
battery. Do not use any other rechargeable
battery.
• Carry batteries in the case provided when not
in use to prevent short-circuit or overheating.
zAdditional Information
Using dry batteries
Precautions
1
Open the lid of the battery compartment.
On safety
• Should any solid objects or liquid fall into the
unit, unplug it and have it checked by qualified
personnel before operating it any further.
• Do not put any foreign objects in the DC IN
4.5 V (external power input) jack.
(rear)
On power sources
2
• When you are not using the player for a long
Insert two LR6 (size AA) alkaline
time, disconnect all power sources from the
batteries by matching the ' and ' to the
player.
diagram inside the battery compartment
and close the lid.
On the AC power adaptor
• Use only the supplied AC power adaptor. If
your player is not supplied with it, use AC-
E45HG AC power adaptor. Do not use any
(rear)
other AC power adaptor.
• To unplug the AC power adaptor from the wall
outlet, grasp the adaptor itself, do not pull its
cord.
Note
On dry and rechargeable batteries
• Do not use manganese batteries for this player.
This player is designed so that it cannot charge
To take out the dry batteries any other rechargeable batteries or dry batteries
for safety reasons.
Pull the ' side of the battery as shown.
The supplied rechargeable batteries
(NC-DMAA)
Other rechargeable batteries or dry batteries
When you replace the rechargeable batteries with
new ones, make sure to use the NC-DMAA
When to replace the dry batteries rechargeable batteries.
If the i indication appears in the display
• Do not throw the batteries into fire.
and the sound becomes inaudible, replace all
• Do not carry the batteries with coins or other
the batteries with new ones, because the
metallic objects. It can generate heat if the
batteries become weak.
positive and negative terminals of the battery
DC IN 4.5 V
are accidentally contacted by a metallic object.
Notes
• Do not mix rechargeable batteries with dry
• Do not charge the dry batteries.
batteries.
• Do not mix new batteries with old ones.
• Do not use different types of batteries together.
On the player
• When the batteries are not to be used for a long
• Keep the lens of the player clean and do not
time, remove them.
touch it. If you do so, the lens may be damaged
• If the battery leakage occurs, wipe off any
and the player will not operate properly.
deposit in the battery compartment, and install
• Do not put any heavy object on top of the
new batteries.
player. The unit and the CD may be damaged.
• Do not leave the player in a location near heat
Battery life (approx. hours)(EIAJ*)
sources, or in a place subject to direct sunlight,
Battery life varies depending on how the
excessive dust or sand, moisture, rain,
player is used.
mechanical shock, unleveled surface, or in a car
with its windows closed.
NC-DMAA 3.5
• If the player causes interference to radio or
(charged for
television reception, turn off the player or move
about 3.5 hours)
it away from the radio or television.
• Do not wrap the player in a cloth or blanket
Two Sony alkaline 10 during use as it may cause malfunction or
batteries LR6SG serious accidents.
On headphones/earphones
*Measured value by the standard of EIAJ
(Electronic Industries Association of Japan). Road safety
(When the unit is used on a flat and stable place.)
Do not use headphones/earphones while
driving, cycling, or operating any motorized
How to attach the battery vehicle. It may create a traffic hazard and is
illegal in some areas. It can also be potentially
compartment lid
dangerous to play your headsets at high volume
If the battery compartment lid is detached by
while walking, especially at pedestrian crossings.
an accidental drop, excessive force, etc.,
You should exercise extreme caution or
attach it as illustrated in the numbered order.
discontinue use in potentially hazardous
situations.
Preventing hearing damage
Avoid using headphones/earphones at high
volume. Hearing experts advise against
continuous, loud and extended play. If you
experience a ringing in your ears, reduce volume
or discontinue use.
Caring for others
Keep the volume at a moderate level. This will
allow you to hear outside sounds and to be
considerate to the people around you.
Maintenance
To clean the lens
Clean the lens with a lens cleaning kit KK-DM1.
Lens
To clean the casing
Use a soft cloth slightly moistened in water or a
mild detergent solution. Do not use alcohol,
benzine or thinner.
Polarity of the plug
Troubleshooting Specifications
Should any problem persist after you have made
CD player
these checks, consult your nearest Sony dealer.
System
Compact disc digital audio system
The CD does not play or "no dlSC"
Laser diode properties
appears in the display though a CD
Material: GaAlAs
Wavelength: 780 nm
is placed in the unit.
Emission duration: Continuous
m The CD is dirty or defective.
Laser output: Less than 44.6 µW (This output
m Insert the CD with the label side up.
is the value measured at a distance of 200
m Moisture condensation has occurred.
mm from the objective lens surface on the
Leave the unit aside for several hours until
optical pick-up block with 7 mm aperture. )
the moisture evaporates.
Error correction
m The lens is dirty.
Sony Super Strategy Cross Interleave Reed
m Close the lid of the unit and the battery
Solomon Code
compartment firmly.
D-A conversion
m Make sure the batteries are inserted
1-bit quartz time-axis control
correctly.
Frequency response
m Connect the AC power adaptor to a wall
20 - 20,000 Hz +1 dB (measured by EIAJ CP-
outlet securely.
–3
307)
m The rechargeable batteries are used up.
Output (at 4.5 V input level)
Connect the AC power adaptor and
charge the batteries. Headphones (stereo minijack)
Approx. 5 mW + approx. 5 mW
m Dry batteries are used up. Replace them
at 16 ohms
with new ones.
(Approx. 2 mW + approx. 2 mW
at 16 ohms*)
When you press (, "00" appears in
*For the customers in France
the display for a moment, and
disappears. The CD does not play.
General
m The rechargeable batteries are used up.
Power requirements
Connect the AC power adaptor and
For the area code of the model you purchased,
charge the batteries.
check the upper left side of the bar code on the
m The dry batteries are used up. Replace
package.
them with new ones.
• Sony NC-DMAA rechargeable battery:
2.4 V DC, Ni-Cd, 700 mAh
No sound, or noise is heard.
• Two LR6 (size AA) batteries: 3 V DC
m Connect the plugs firmly.
• AC power adaptor (DC IN 4.5 V jack):
m Plugs are dirty. Clean the plugs with a dry
U2/CA2/E92/MX2 model: 120 V, 60 Hz
soft cloth periodically.
CED/CEX/EE/EE1/E13/G5/G6/G7/G8/
CE7 model: 220 - 230 V, 50/60 Hz
"Hl dc ln" appears in the display.
CEK model: 230 - 240 V, 50 Hz
m Use only the supplied AC power adaptor
EA3 model: 110 - 240 V, 50/60 Hz
or AC power adaptor AC-E45HG (not
AU2 model: 240 V, 50 Hz
supplied).
JE.W/E33 model: 100 - 240 V, 50/60 Hz
HK2 model: 220 V, 50/60 Hz
"Hold" appears in the display when
CN2/AR1 model: 220 V, 50 Hz
you press a button.
• Sony CPM-300P mount plate for use on car
m The buttons are locked. Slide HOLD back. battery: 4.5 V DC
Dimensions (w/h/d) (without projecting parts
The i indication appears in the and controls)
Approx. 131 28 148 mm
display when you press a button.
(5 1 ⁄ 1 1 ⁄ 5 4 ⁄ in.)
m The rechargeable batteries are used up. 4 9 5
Mass (without rechargeable batteries)
Connect the AC power adaptor and
Approx. 220 g (7.8 oz)
charge the batteries.
Operating temperature
m The dry batteries are used up. Replace
5°C - 35°C (41°F - 95°F)
them with new ones.
Supplied accessories
The battery life is short.
For the area code of the model you purchased,
m Manganese batteries are used. Use alkaline
check the upper left side of the bar code on the
batteries.
package.
m Replace the batteries with new ones.
AC power adaptor (1)
Earphones (1)
The volume is limited to a certain
Rechargeable batteries (2)
level even if you attempt to turn it
Connecting cord (Phono plug 2
up.
miniplug) (1)
m AVLS function keeps down the volume.
AC plug adaptor (1)*
Hold down MENU until "AVLS"
Battery carrying case (1)
disappears from the window.
*Supplied with E13 model
You cannot use the AMS function
Design and specifications are subject to change
nor enjoy the various playing
without notice.
modes such as REPEAT 1, REPEAT
and REPEAT SHUFFLE.
m If you use the following discs, the AMS or
play mode function may not operate well:
— a CD where the pause between the
tracks is extremely short,
— a CD that has only one track,
— a CD that has more than 95 tracks.
You cannot operate the =/+
buttons.
m After starting play, you cannot operate
these buttons until the elapsed time
appears in the display. Press them after
the time indication appears in the display.
Play does not start right away.
m It may take longer to start playing the CD
that has a lot of tracks. Wait for a while.
Optional accessories
Mount plate CPM-300P
Mount kit CPM-300PC
Car connecting pack CPA-9
Car battery cord with car connecting pack
DCC-E26CP
Car battery cord DCC-E245
Active speaker system SRS-A21, SRS-A41,
SRS-A71
Rechargeable battery NC-DMAA (2P)
Connecting cord RK-G129HG, RK-G136HG
AC power adaptor AC-E45HG
Stereo headphones MDR-A44L, MDR-301LP,
MDR-E848LP, MDR-35*
* When using optional headphones, use only
headphones with stereo miniplugs. You
cannot use headphones with micro plugs.
Stereo miniplug Micro plug
Your dealer may not handle some of the above
listed accessories. Please ask the dealer for
detailed information about the accessories in
your country.
stereo
