Extension Wall Mounting Brackets
No. 23 Adjustable Extension Bracket - Showing 2 Positions
24"
181⁄4"
21⁄2"
13⁄4"
107⁄16"
53⁄4"
.320 DIA. (3) MTG. Holes
1"
No. 23 Adjustable Extension Bracket - Showing 1 Position
20"
21⁄2"
Washer
53⁄4"
147⁄16"
53⁄4"
.320 DIA. (3) MTG. Holes
A Milestone AV Technologies Brand
3100 North Detroit Street
Warsaw, Indiana 46582
P: 574.267.8101 or 800.622.3737
F: 574.267.7804 or 877.325.4832
E: info@da-lite.com
www.da-lite.com
DL–0339 (Rev. 1) 12.15
© 2015 Milestone AV Technologies LLC. Printed in U.S.A.
3⁄4"
Washer
1"
1"
Section A-A
Same For All
Plastic Brackets
3⁄4"
No. 11 Extension Bracket
14"
21⁄2"
13⁄4"
107⁄16"
53⁄4"
.320 DIA. (3) MTG. Holes
No. 11 Extension Bracket
10"
A
21⁄2"
A
53⁄4"
147⁄16"
53⁄4"
.320 DIA. (3) MTG. Holes
7⁄16
1"
7⁄16"
79163
MOUNTING INSTRUCTIONS FOR
No. 11 and No. 23
Wall Brackets
