Analog Voltage Output - CHINT NVF5 Series Quick Start-Up Wizard

（1） Single Phase 230V （NVF5-0.4/TD2～2.2/TD2 （2） Three Phase380V （NVF5-0.4/TS4-B～
and NVF5-0.4/TD2-B～2.2/TD2-B）
NVF5-0.4/TD2～2.2/TD2 and
NVF5-0.4/TD2-B～2.2/TD2-B Power Terminal
Terminal
Main Power Supply
R、S、T
Input
Main Power Supply
L1、L2
Input
U、V、W Inverter Output
Grounding
P+ P- DC Bus Terminals
P B
Outer Brake Resistor
Terminals
P+ B
3.2 Power terminal and I/O terminal block diagram
AO Dip Switch：Left， （0~20）mA or （4~20）mA Analog Current Ouput；Right， （0~10）
V Analog Voltage Output.
AI1 Dip Swith： Left， （0~20） mA or （4~20） mA Analog Current input； Right， （0~10） VAnalog
Voltage input.
AI2：Current Output need to be customized.
Figure 3-1
Name
QF
Single-phase input poweer
230V 50/60Hz
Three-phase input power
380V~440V 50/60Hz
Power grounding
Programmable
Multifunction
Input
Analog input power supply
2 x Analog input
V:(-10～10)V
I:(0～20)mA or (4～20)mA
Analog input common
RS485 communication
The three-phase AC input terminals ,connecting
with the power grid
The Single-Phase AC input terminals ,connecting
with the power grid
The three-phase AC output terminals ,connecting
with the AC motor
Grounding terminals,ensure reliable grounding
Single phase type DC+ and DC-
Three phase type brake resistor terminals
Single phase type brake resistor terminals
Brake resistor
Main circuit terminal
Motor grounding
Control circuit terminal
Programmable relay outputs
Programmable open collector
high-speed output
Analog output
Output
V:(0～10)V
I:(0～20)mA or (4～20)mA
AO A11
J2 Multifunction interface
AOI AOV
I1 V1
J2、J3 Multifunction extension card interface
J3 Multifunction interface
Figure 3-3
7.5/TS4-B）
NVF5-0.4/TS4-B～7.5/TS4-B
Power Terminal
Figure 3-2
Description
