- Page 1 User Manual USER’S MANUAL D6000 Series Digital Video Recorder...
-
Page 2: Table Of Contents
User Manual Contents Chapter 1: DVR Features ............................3 DVR Feature ..............................3 Chapter 2: Overview ..............................3 2.1 Front Panel ..............................3 2.2 Rear Panel ..............................1 2.3 Remote Control(just for reference) ......................1 Chapter 3: Installation ............................. 2 3.1 Install Hard Disk ............................ - Page 3 User Manual 6.3 Stop Recording ............................18 6.4 Estimated Recording Length ........................18 Chapter 7: Playback ............................... 19 7.1 Playback Control ............................19 Chapter 8: USB Progamming (optional) ......................19 8.1Driver Installation: ............................19 8.2 Program Interface ............................20 8.3 Program Running ............................20 Chapter 9: Specification ............................
-
Page 4: Dvr Feature
User Manual Chapter 1: DVR Features DVR Feature MPEG4 compression 4-Channel: 4 BNC Camera Inputs - 2 BNC Video Outputs 9-Channel: 9 BNC Camera Inputs - 1 BNC Video Output 4-Channel: 2 Audio Inputs - 2 Audio Outputs 9-Channel: 1 Audio Input -1 Audio Output System Format : NTSC /PAL Motion Detection with Sensitivity and Area Settings Time Schedule, Alarm and Motion Triggered Recording Modes... -
Page 5: Rear Panel
User Manual 17.UP 19.DOWN 18.SEL/EDIT/RIGHT 20.PTZ: enter PTZ mode 2.1.2 9-channel DVR front panel(just for reference) 1.Power switch 11.PAUSE 2.Power LED 12.PLAY 3.IR receiver 13.FWD: forward 4.HDD LED 14.STOP 5.Search 15.REC: record 6.MUTE: turn on/off audio output 16.MENU/ESC/LEFT 7.CH-: view previous channel 17.UP 8.CH+: view next channel 18.SEL/EDIT/RIGHT... -
Page 6: Remote Control(Just For Reference)
User Manual 2.2.2 9-channels DVR rear panel(just for reference) 1.FAN 10. LAN: ethernet port 2. Audio input 11. Audio output 3. Video output 12. CH9: video input 4.CH4: video input 13. CH8: video input 5. CH3: video input 14. CH7: video input 6. -
Page 7: Chapter 3: Installation
User Manual Chapter 3: Installation 3.1 Install Hard Disk NOTICE : Don’t take out HDD when DVR is running. Make sure the HDD is set to be MASTER according to the hard drive manual. (1) Remove the screws around the top cover; (2) Remove the top cover carefully;... -
Page 8: Chapter 1: Dvr Features
User Manual 4.2 Detecting Installed Hard Drive DVR will detect the installed hard drive and display the hard drive information. CHECKING HDD…… MASTER [WDC WD3200AAJB-00T] SLAVE…… 4.3 Format Hard Drive When the DVR detects a new hard drive, you will be prompted to format the hard drive before using the DVR. -
Page 9: Camera Setup
User Manual Menu Directory Camera Setup Record Setup Record Frame rate Video Quality Change Password Record Schedule Set Time Sensor Setup Hidden Channel Main Menu Hard Drive Setup Audio Port Setup Miscellaneous Setup PTZ Setup Image Parameters Network Setup Password Enable Language Keypad Tones Video Backup... -
Page 10: Record Frame Rate
User Manual 5.5 Record Frame Rate The total frame rate is 50fps (PAL) or 1 3FPS 2 5FPS 60fps (NTSC). You can set the frame rate RECORD FRAMERATE for the channel which you selecte to TOTAL 36FPS record. If the sum of the frame rate you select for all cameras is more than 50fps 3 25FPS 4 3FPS... -
Page 11: Sensor Setup
User Manual NO-RECORD [ white]: DVR will not record during the time. NORMAL-RECORD [ red]: DVR will record continuously. SENSOR-RECORD [S]: DVR will record when sensor or motion is triggered. In order to activate the record schedule, press the [ ] record button when NOTE: viewing the cameras. -
Page 12: Motion Detector Setup
User Manual 5.10 Motion Detector Setup This section allows you to set up motion detection options for each camera. MOTION DETECTOR SETUP: ON/OFF: Enable or disable motion detection MOTION DETECTOR SETUP recording. LEVEL1 AREA LEVEL2 AREA LEVEL: Sensitivity for motion detection. LEVEL2 AREA LEVEL2... -
Page 13: Miscellaneous Setup - Change Password
User Manual HDD FORMAT: will erase all video and data on the installed hard drive and make it readable by the DVR Note: You will be prompted for the password when formatting a hard drive. The default password is “111111” 5.12 Miscellaneous Setup - Change Password This option allows you to change the MISCELLANEOUS SETUP... -
Page 14: Miscellaneous Setup - Hidden Channel
User Manual 5.14 Miscellaneous Setup - Hidden Channel The system provides a function to hide a MISCELLANEOUS SETUP channel in monitoring mode. The selected CHANGE PASSWORD SET TIME channel can still be recorded while it’s hidden; HIDDEN CHANNEL [ 4 ] AUDIO PORT SETUP the hidden picture is viewable during playing PTZ SETUP... -
Page 15: Miscellaneous Setup - Image Parameters
User Manual 5.17 Miscellaneous Setup - Image Parameters You can adjust the image parameters MISCELLANEOUS SETUP according to your needs. CHANGE PASSWORD SET TIME Move the cursor to this selection and HIDDEN CHANNEL [ 1 ] AUDIO PORT SETUP PTZ SETUP press [◄] or [►] button to select a channel IMAGE PARAMETERS [ CH4 ]... -
Page 16: Miscellaneous Setup - Keypad Tones
User Manual 5.19 Miscellaneous Setup - Keypad Tones MISCELLANEOUS SETUP This function allows you to enable CHANGE PASSWORD /disable buzzer sound when pressing a SET TIME HIDDEN CHANNEL [ 4 ] button. Press [SEL] to select ON or AUDIO PORT SETUP PTZ SETUP IMAGE PARAMETERS [ CH4 ]... - Page 17 User Manual network and the first code “00” must not to be changed. IP ALLOCATION: DVR supports DHCP and NETWORK SETUP Static IP modes. If your modem/router supports MAC ADDRESS DHCP function, you can use DHCP mode. When <00:11:22:33:44:55> IP ALLOCATION [DHCP] IP ADDRESS using STATIC mode, you will be required to setup...
- Page 18 User Manual NETWORK SETUP GATEWAY: Set this number to the gateway set by your modem/router. MAC ADDRESS <00:11:22:33:44:55> IP ALLOCATION [STATIC] IP ADDRESS [192.168.1.100] SUBNET MASK [255.255.255.0] GATEWAY [192.168.1.1] DNS1 ADDRESS [0.0.0.0] DNS2 ADDRESS [0.0.0.0] HTTP PORT USER SETUP DDNS SETUP (HTTP PORT) 80, 1024-49151 )MOVE (SEL)SELECT (MENU)EXIT NOTE: To adjust the IP ADDRESS，SUBNET MASK and GATEWAY value, only when the...
- Page 19 User Manual DDNS SETUP：If you require an external DDNS SETUP service to maintain a dynamic IP address enter the user information here. DDNS PROVIDER [WWW.DynDNS.com ] DDNS USER NAME DONS PASSWORD )MOVE (SEL)SELECT (MENU)EXIT LAN-DVR Connection See the diagram below for steps to connect your DVR to a local area network or the internet. For remote monitoring from your computer，you must have a LAN connection available or broadband Internet access.
-
Page 20: Language
User Manual 5.22 Language You can change the OSD language from MAIN MENU the default English to other languages, if your DVR supports multi-languages. CAMERA SETUP RECORD SETUP RECORD FRAMERATE VIDEO QUALITY NORMAL RECORD SCHEDULE SENSOR SETUP HARD DRIVE SETUP MISCELOLANEOUS SETUP NETWORK SETUP LANGUAGE... - Page 21 User Manual You can directly select the start& end time of a recording video to backup. Move the cursor to “START” or “END”; BACKUP STARTING TIME press [SEL] to enter the interface. Press [◄] or [►] button to move the cursor, and 2008/08/22 16:20:22 then press [SEL] to modify the value.
-
Page 22: Reset Menu
User Manual Please read Charter 8 on how to play back your backup file. 5.24 Reset Menu If you select this item, the system will restore all your settings to factory default values. You need to enter your password to reset the menu. 5.25 NTSC/PAL Output select Change the jumper JS1 to select NTSC or PAL video output format according to the... -
Page 23: Audio Recording
User Manual ● ]: the red pot next to the channel name indicates that the channel is being recorded. [A-REC]: indicates the current record schedule is set to NORMAL-RECORD mode. [S-REC]: indicates the current record schedule is set to SENSOR-RECORD mode. [N-REC]: indicates the current record schedule is set to NO-RECORD mode. -
Page 24: Chapter 7: Playback
User Manual Chapter 7: Playback 7.1 Playback Control Press the [►] PLAY button goes into PLAYBACK mode. The newest record event will be played. Press the [MENU] button during PLAYBACK SEARCH VIDEO mode，then the system will list all the recorded events. -
Page 25: Program Interface
User Manual 8.2 Program Interface Button functions: 1.PTZ Control 11.Convert Streams to AVI file 2.Zoom in，Zoom Out 12.Back One Frame 3.HDD Play Mode 13.Record 4.File Play Mode 14.Stop 5.Net Play Mode 15.Play 6.Event List 16.Pause 7.Control Panel 17.Fast Forward Remote DVR Control 18.Forward One Frame 9.Change Storage Device 19.Playback Slider... - Page 26 User Manual After you’ve seen the USB icon, double click “ ” icon on your desktop to run the program. Note: if you do not follow above steps, the program will fail to detect HDD Press to open the video event lists. Press configure the program local settings...
- Page 27 User Manual Press to play video. 8.3.2 FILE play mode: (only when you plug a USB Memory Stick into your PC) Press “ ” to open a folder and select the file you want play. Double click the file.
- Page 28 User Manual 8.3.3 NET play mode: This mode allows you to remote control your DVR via Internet or Intranet. Press “ ” to pop up the login window. Fill in Host Name, Host Port, User Name and Password of the DVR that you want remotely access and then press Login to enter the main page.
-
Page 29: Chapter 9: Specification
User Manual Chapter 9: Specification 4 / 9-Channel DVR Items Descriptions Video Standard NTSC/PAL Video Input/Output 4 Channels/2 Channels，9 Channels/1 Channel Audio Input/Output 2 Channels/2 Channels，1 Channel/1 Channel NTSC:720X480@30fps(Each Ch) Resolution PAL:720X576@25fps(Each Ch) Monitoring Features Full-D1，1-CH/4-CH/9-CH Display NTSC:720X240@60fps(4/9Ch.Total) Resolution PAL:720X288@50fps(4/9Ch.Total) Variable Frame Rate/Variable QL per Recording Features... -
Page 30: Chapter 10: Appendix
User Manual Chapter 10: Appendix 10.1 System connection diagram Alarm Sensor PC(Optional) Camera TV or Monitor LAN(RJ-45)Port on DVR 10.2Accessories Power Cord Power Adaptor User’s Manual Design may vary depending on country USB Cable (For Software CD Remote Controller PC Backup Only) - Page 31 User Manual China prints 2008.4 V1.0 The material in this document is the intellectual property of our department . No part of this manual be reproduced, copied, translated, transmitted, or published in any form or by any means without our department prior written permission.
