Summary of Contents for Foxtech T3500
- Page 1 T3500 Tethered Power System for Drones User Manual 2019.05 V1.0...
- Page 2 T3500 Tethered Power System for Drones User Manual Product List: - One set of 4KW tethered boxes. - 3.5KW onboard power supply (except optional or customized) - One 220Vac input cable, default 16A plug (if using 16A to 10A socket, please note that the socket is full power only 2.2KW)
- Page 3 T3500 Tethered Power System for Drones User Manual The first step (preparation): Open the ground station cover, plug in the 220vac input cable, connect the 220vac input source (main supply or equipment power ≥ 5KW, if it is a generator, please turn the generator on for 3~5 minutes) the operation panel is as follows: Please know the device on the operating surface to read the following steps.
- Page 4 T3500 Tethered Power System for Drones User Manual The second step (joining work): A) Check if the winch control button is in the 0 position. If it is not, please adjust it to the 0 position. Otherwise, the winch will be pulled and the cable will not be pulled out. In severe cases, it will alarm.
- Page 5 T3500 Tethered Power System for Drones User Manual 1. Pull out the cable 3~5m, suitable for aircraft distance 2.Connect the cable jack-plug to the onboard power input port. 3. The cable hook is hung on the reserved port of the air unit carbon plate or other stable place.
- Page 6 T3500 Tethered Power System for Drones User Manual achieve the purpose of the automatic winch later. The different aircraft has different load capacity, the torque is also different, normally does not exceed 4 gears, and the factory setting is 600r/min.
- Page 7 T3500 Tethered Power System for Drones User Manual C) Turn off the main power switch, unplug the of onboard unit power, turn on the main power, turn on the winch control switch, tighten the cable to the box, then turn off the main power.
-
Page 8: Other Configurations
T3500 Tethered Power System for Drones User Manual Other configurations: 1. Press the power button of the cable to enter the ground station power setting interface. Press once again to enter the initial voltage setting stage. Rotate left and right to adjust the initial voltage: 380~400Vdc. Click "confirm"... - Page 9 T3500 Tethered Power System for Drones User Manual 3.The operation panel and the chassis of the device adopt anti-disassembly mechanical structure. Once the breakage is found, customer no longer enjoys the 1-year warranty and technical after-sales service by default. Hardware and Function Parts 1.
- Page 10 T3500 Tethered Power System for Drones User Manual This content is subject to change. Download the latest version from https://www.foxtechfpv.com/tethered-power-system-for-drones.html For everyday updates, please follow Foxtech Facebook page: Foxtechhobby YouTube Channel: Foxtech 2019 FOXTECH All Rights Reserved ©...
