Carbon Monoxide Detector (Digital Display)
Model Number: OR-DC-619
Specifications:
Alarm Condition: EN50291 -1:2010 +A1:2012
Sensor: "ECO-cell" Electrochemical carbon monoxide sensor with more than 7
years lifetime
Power: 3 x1.5V AA alkaline batteries
Temperature: Operating range -20°C to 50°C
Humidity: Operating range 5%-100% relative humidity.
Mounting: Accessories supplied for wall mounting
Alarm: 85+ dB on 1m @ 3.4 ± 0.5 KHz pulsing alarm
Test/Reset Button: Test button verifies proper unit operation.
Accuracy of Digital Display: 25-999 ppm (±15%) when measured in condition
of 20˚C (±5˚C). Atmosphere pressure ±10% and 40% (±5%) relative humidity.
Size & Weight: 122mm×77mm×35mm /120g without battery
Sensor Life Time: six years from first powered on but no longer then seven
years from production date printed on back side of unit.
Warranty: Six-year limited warranty from date of purchase against defects in
material and workmanship on CO detector unit.
Quick Set Up
Remove the three enclosed AA batteries
and install them into the battery box.
Observe the battery polarity markings at
the bottom of the battery box.
When the batteries are first installed, the unit will beep one time and
the red , green and yellow LEDs will flash one by one. "888 ppm" will
be displayed with blue backlight. After approximately 1 minute -2
minutes, the display and backlight will be off and the green light will
flash every 4 seconds indicating that the unit is operational. Fit on
battery cover. Your CO detector is now operational.
Caution: Please do not press the test/reset button when you
install the batteries!!!
1
Advertisement
Table of Contents
Related Manuals for Orno OR-DC-619
Summary of Contents for Orno OR-DC-619
- Page 1 Carbon Monoxide Detector (Digital Display) Model Number: OR-DC-619 Specifications: Alarm Condition: EN50291 -1:2010 +A1:2012 Sensor: “ECO-cell” Electrochemical carbon monoxide sensor with more than 7 years lifetime Power: 3 x1.5V AA alkaline batteries Temperature: Operating range -20°C to 50°C Humidity: Operating range 5%-100% relative humidity.
- Page 2 Operating and Alarm Characteristics LCD Display Display Alarm Sound Units Status Recommendation Shows Refer to “What to A display of CO 4 quick beeps, Concentration concentration Repeated every of CO do When the “for example” from 30-999 ppm. 5 seconds. detected.
- Page 3 PRESS TEST BUTTON: (1)Press the test/reset button, the blue back light will be lighted. And the unit beeps four times with red led flashes four times. Then it will display the highest CO concentration which have been detected by the detector since it was tested from the last time to press TEST button.
- Page 4 The following suggestions are intended to help you with the placement and installation of your CO detector. • Place out of the reach of children. Under no circumstance should children be allowed to handle the CO detector. • Install in a bedroom or hallway located close to the sleeping area. Take special care to verify the alarm can be heard in sleeping areas.
- Page 5 Danger CO Levels Concentration of CO in Air Approximate Inhalation Time and Symptoms Developed (ppm = parts per million) 50 ppm The maximum allowable concentration for continuous exposure for healthy adults in any 8-hour period. 200 ppm Slight headache, fatigue, dizziness, nausea after 2-3 hours. 400 ppm Frontal headaches within 1-2 hours, life threatening after 3 hours.
- Page 6 •Do not paint the CO detector. Paint will seal the vents and interfere with proper sensor operation. •Do not mount the CO detector directly above or near a diaper pail, as high amounts of methane gas can cause temporary readings on the digital display. What to do When the Alarm Sounds (1) Operate the Test/Reset button;...
