RECOMMENDATIONS:
• Install the device near an active power source, on a ceiling above a door or
STEP • 1
somewhere near the door to minimize the need for extra wiring.
Determine
• Use the DIY metal casing to neatly house the device, its power supply and
rechargeable backup battery.
where you
• Please avoid installing the device at a location prone to high moisture or
high condensation level in the environment.
want to install
TimeTec
BLE-2
BLE-2
User uses
Mobile App
to unlock
door
DC12V 3A
Power Input
EM Lock
Emergency
ON-OFF
Break Glass
Keyswitch
Push Button
(Optional)
OUTDOOR INDOOR
STEP • 2
Make sure
that you have
all the required
accessories
for the
installation
The list below is necessary for any single door access system.
• 1 x PW12V Switching Power Supply - AC/DC
switching power supply to keep the battery
charged during daily operation.
• 1 X Rechargeable Backup Battery - To pro-
long the system's standby time during a
power failure.
• 1 X Electronic Door Lock (EM600/EM1200)
- Normally Close (NC) and Normally Open
DC12V
Rechargeable (NO) type of electronic door lock. Adjust Tim-
Battery
eTec BLE-2's output switch to match the EM
lock.
ABOVE CEILING
CEILING
The User Guide for i-TimeTec App can be obtained
in the App or in our website at
www.i-timetec.com
GET i-TIMETEC APP USER GUIDE FOR BLE-2
www.i-timetec.com/smartble2guide
BLE-2
EM 600 / EM 1200
Rechargeable
Battery
Emergency
DIY Metal Casing
Break Glass
• 1 x Release Button - Pressing this button will
cut the electricity to the lock thus releasing it.
• 1 x Emergency Break Glass - A safety device to
unlock the door during an emergency.
• 1 x ON-OFF Keyswitch - Backup key switch to
override the system in case of a system failure.
• 1 x DIY Metal Casing - A protective metal box
designed to house TimeTec BLE-2, power sup-
ply and rechargeable backup battery.
• Install i-TimeTec App.
ON-OFF
Keyswitch
Push Button
PW12V Switching
Power Supply
iOS Android
