- Page 1 ® DirectOut Technologies ® D.O.TEC ANDIAMO.MC Hardware Guide Version 1.1...
- Page 2 DirectOut GmbH reserves the right to change specifications at any time without notice. ® ® DirectOut Technologies and D.O.TEC are registered trademarks of the DirectOut GmbH. © DirectOut GmbH, 2013 ® page 2 of 52 D.O.TEC ANDIAMO.MC Manual - Version 1.1 © 2013 DirectOut GmbH...
-
Page 3: Table Of Contents
General Purpose Output Analog Input / Output Delay Compensation ChAPtER 5: MEnu nAvigAtion Menu Map Input sensitivity (Gain setting) ChAPtER 6: tRoublEshooting And MAintEnAnCE Troubleshooting Maintenance ® © 2013 DirectOut GmbH D.O.TEC ANDIAMO.MC Manual - Version 1.1 page 3 of 52... - Page 4 APPEndix A: wiRing dsub-25 DSUB-25 - analog (female) APPEndix b: wiRing gPo DSUB-9 (female) APPEndix C: ConfiguRAtion ExAMPlEs APPEndix d: sEnsitivity <> gAin Explanation Examples indEx ® page 4 of 52 D.O.TEC ANDIAMO.MC Manual - Version 1.1 © 2013 DirectOut GmbH...
-
Page 5: About This Manual
– are used for important points of clarification or cross refer- ences. warning Warnings – alert you when an action should always be observed. ® © 2013 DirectOut GmbH D.O.TEC ANDIAMO.MC Manual - Version 1.1 page 5 of 52... -
Page 6: Chapter 1: Overview
Welcome to the ANDIAMO.MC, D.O.TEC’s 32 channel microphone amplifi er with MADI I/O and remote control. The ANDIAMO.MC provides two MADI inputs and outputs, 32 chan- nels mic/line input and 32 channels line output. With two RU height, low weight, two redundant power supplies and excellent sounding converters the device offers best and safe audio quality at a minimal need of rackspace. -
Page 7: Applications
® DirectOut Technologies CHAPTER 1: Overview Applications ANDIAMO.MC can be used for conversion, amplifi cation, monitor- ing and recording of analog and digital signals. Typical applications include: • recording mic / line signals (32 inputs) • redundant recording using both MADI I/Os • 1:2 splitting of analog input signals (input ... -
Page 8: Chapter 2: Legal Issues & Facts
See „CHAPTER 6: Troubleshooting and Maintenance“ on page 39 for assistance with troubleshooting. ® page 8 of 52 D.O.TEC ANDIAMO.MC Manual - Version 1.1 © 2013 DirectOut GmbH... -
Page 9: First Aid (In Case Of Electric Shock)
Lay the body down and turn it to one side. Call for a doc- tor immediately. • Having sustained an electric shock, ALWAYS consult a doc- tor. ® © 2013 DirectOut GmbH D.O.TEC ANDIAMO.MC Manual - Version 1.1 page 9 of 52... -
Page 10: Contents
® DirectOut Technologies CHAPTER 2: Legal issues & facts Contents The contents of your ANDIAMO.MC package should include: • 1 x ANDIAMO.MC (19’’, 2 RU) • 2 x power chord • 2 x fixing unit for power plug • 1 x Hardware Guide... - Page 11 ® DirectOut Technologies CHAPTER 2: Legal issues & facts BREAKOUT.AN16O - analog output, 16 channels ® © 2013 DirectOut GmbH D.O.TEC ANDIAMO.MC Manual - Version 1.1 page 11 of 52...
-
Page 12: Updates
This guide refers to fi rmware version 1.2. intended operation The ANDIAMO.MC is designed for conversion of audio signals from analog to digital and vice versa. In this context digital audio refers to a MADI signal (AES10). warning No compensation can be claimed for damages caused by operation of this unit other than for the intended use described above. -
Page 13: Conformity & Certificates
Phone: +49 (0)3727 6205-333 // Fax: +49 (0)3727 6205-56 www.directout.eu Manufacturer: IMM Elektronik GmbH, Leipziger Strasse 32, 09648 Mittweida, Germany Phone: +49 (0)3727 6205-0 // Fax: +49 (0)3727 6205-56 www.imm-gruppe.de ® © 2013 DirectOut GmbH D.O.TEC ANDIAMO.MC Manual - Version 1.1 page 13 of 52... -
Page 14: Chapter 3: Installation
Retain the protective cap if the optical port is unused. This will pro- tect against soiling which can lead to malfunction. Connect signal cable for the MADI signals. ANDIAMO.MC- SC / SC version (optical / optical) ANDIAMO.MC- SC / BNC version (optical / coaxial) ®... - Page 15 PSU 1 and PSU 2 to independent power supplies with separate fuses. signal cables are not included in delivery ® © 2013 DirectOut GmbH D.O.TEC ANDIAMO.MC Manual - Version 1.1 page 15 of 52...
- Page 16 Link: http://www.directout.eu/en/support/downloads/andiamo.mc.html Keep any packaging in order to protect the device should it need to be dispatched for service. ® page 16 of 52 D.O.TEC ANDIAMO.MC Manual - Version 1.1 © 2013 DirectOut GmbH...
- Page 17 • follow the installation instructions in the ‘Software Guide AN- DIAMO REMOTE’ Start the ‘ANDIAMO Remote’ application • Check selected COM port or MIDI I/O • Click ‘CONNECT’ ® © 2013 DirectOut GmbH D.O.TEC ANDIAMO.MC Manual - Version 1.1 page 17 of 52...
-
Page 18: Chapter 4: Operation
To ensure that the device is completely disconnected from mains voltage, the power chords must be disconnected. ® page 18 of 52 D.O.TEC ANDIAMO.MC Manual - Version 1.1 © 2013 DirectOut GmbH... -
Page 19: Menu Control
Blinking LEDs are also used to indicate an error (e.g. missing sync). Concentrate on the section where one LED is blinking and the re- maining LEDs are glowing weak. ® © 2013 DirectOut GmbH D.O.TEC ANDIAMO.MC Manual - Version 1.1 page 19 of 52... -
Page 20: Clocking
MADI input and no signal present lEd (green): indicates use of internal clock generator as clock source LED ON = Clock source set to internal clock generator ® page 20 of 52 D.O.TEC ANDIAMO.MC Manual - Version 1.1 © 2013 DirectOut GmbH... -
Page 21: Clocking Continued - Madi State
The MADI input that locks fi rst will be selected automatically. Once the selected input looses its signal, the other input will be se- lected as signal source, if an input signal is detected there. ® © 2013 DirectOut GmbH D.O.TEC ANDIAMO.MC Manual - Version 1.1 page 21 of 52... -
Page 22: Sample Rates
If the clock source is set to word clock or MADI input no adjustment of the base rate is possible - the measured frequency of the clock source is indicated then. ® page 22 of 52 D.O.TEC ANDIAMO.MC Manual - Version 1.1 © 2013 DirectOut GmbH... -
Page 23: Bank Selection / Signal Routing
ANDIAMOs. If both Bank LEDs are <ON> ‘Matrix Mode’ is enabled. If both Bank LEDs <heartbeat> ‘Matrix Mode’ is enabled and delay compensation is active. ® © 2013 DirectOut GmbH D.O.TEC ANDIAMO.MC Manual - Version 1.1 page 23 of 52... -
Page 24: Output Format
LED ON = MADI output is set to 96k Frame LED OFF = MADI output is set to 48k Frame 96k Frame is available with 2 FS only. ® page 24 of 52 D.O.TEC ANDIAMO.MC Manual - Version 1.1 © 2013 DirectOut GmbH... -
Page 25: Level Settings
The level setting of the input channels is accessible using the menu - see „Input sensitivity (Gain setting)“ on page 36 - or using the remote control. ® © 2013 DirectOut GmbH D.O.TEC ANDIAMO.MC Manual - Version 1.1 page 25 of 52... -
Page 26: Level Meters - Analog Input
LED ON = analog input signal equals to more than -18 dB The LED starts to light up softly at -80 dB and reaches full brightness at -18 dB ® page 26 of 52 D.O.TEC ANDIAMO.MC Manual - Version 1.1 © 2013 DirectOut GmbH... -
Page 27: Display - Input Channel Settings
LED ON = digital output signal equals to more than -80 dB The light intensity of the LEDs depends on the audio level. ® © 2013 DirectOut GmbH D.O.TEC ANDIAMO.MC Manual - Version 1.1 page 27 of 52... -
Page 28: Remote Protocol
This setting may be modifi ed in the system menu - see „CHAPTER 5: Menu Navigation“ on page 34. Mapping table: Code Protocol reserved reserved reserved reserved reserved reserved reserved reserved ® page 28 of 52 D.O.TEC ANDIAMO.MC Manual - Version 1.1 © 2013 DirectOut GmbH... - Page 29 See ‘Software Guide ANDIAMO Remote’ for a mapping of applica- ble protocols. This feature is not yet implemented and reserved for future use. ® © 2013 DirectOut GmbH D.O.TEC ANDIAMO.MC Manual - Version 1.1 page 29 of 52...
-
Page 30: Madi / Word Clock / Usb
(optical) bnC socket (coaxial) MADI output (64 ch), connect MADI output here Both MADI outputs always work in parallel and carry the same sig- nal. ® page 30 of 52 D.O.TEC ANDIAMO.MC Manual - Version 1.1 © 2013 DirectOut GmbH... -
Page 31: General Purpose Output
(ANDIAMO Remote); e.g. to control a recording light. A power supply (12 V, max. 200 mA) is also provided. See „Appendix B: Wiring GPO“ on page 43. ® © 2013 DirectOut GmbH D.O.TEC ANDIAMO.MC Manual - Version 1.1 page 31 of 52... -
Page 32: Analog Input / Output
Observe the technical specifi - cations - see „CHAPTER 7: Technical Data“ on page 40. TASCAM is a registered trademark of TEAC corporation. ® page 32 of 52 D.O.TEC ANDIAMO.MC Manual - Version 1.1 © 2013 DirectOut GmbH... -
Page 33: Delay Compensation
+4 samples id 02 +4 samples Two ANDIAMO.MCs daisy-chained To ensure proper detection for delay compensation no other device must be connected in between two ANDIAMOs. ® © 2013 DirectOut GmbH D.O.TEC ANDIAMO.MC Manual - Version 1.1 page 33 of 52... -
Page 34: Chapter 5: Menu Navigation
Use SET ▼ to modify parameter, sensitivity or <PAD> on/off state. To (de)activate the ‘Matrix Mode’ navigate to the parameter ‘BANK’ and press a SET button longer than two seconds. ® page 34 of 52 D.O.TEC ANDIAMO.MC Manual - Version 1.1 © 2013 DirectOut GmbH... -
Page 35: Menu Map
® DirectOut Technologies CHAPTER 5: Menu Navigation Menu Map to Remote Protocol to channel 01 ® © 2013 DirectOut GmbH D.O.TEC ANDIAMO.MC Manual - Version 1.1 page 35 of 52... -
Page 36: Input Sensitivity (Gain Setting)
- 55 dBu - 18 dBu 0 dBu + 6 dBu (- 36 dBu with activated PAD) + 24 dBu (- 14 dBu with activated PAD) ® page 36 of 52 D.O.TEC ANDIAMO.MC Manual - Version 1.1 © 2013 DirectOut GmbH... - Page 37 1 dB values. There is a correlation between ‘input sensitivity’ and the commonly used term ‘gain’. See „Appendix D: Sensitivity <> Gain“ on page 46 ® © 2013 DirectOut GmbH D.O.TEC ANDIAMO.MC Manual - Version 1.1 page 37 of 52...
- Page 38 The channel format (56 ch or 64 ch) as well as the frame format (48k Frame or 96k Frame) of the MADI output can be adjusted. This setting does not affect the input signal. ® page 38 of 52 D.O.TEC ANDIAMO.MC Manual - Version 1.1 © 2013 DirectOut GmbH...
-
Page 39: Chapter 6: Troubleshooting And Maintenance
To clean the device, use a soft, dry cloth. To protect the surface, avoid using cleaning agents. The device should be disconnected from the power supply during the cleaning process. ® © 2013 DirectOut GmbH D.O.TEC ANDIAMO.MC Manual - Version 1.1 page 39 of 52... -
Page 40: Chapter 7: Technical Data
• 30 - 50 kHz @1 FS • 60 - 100 kHz @2 FS MAdi format (i/o) • 48k Frame, 96k Frame • 56 channel, 64 channel • S/MUX 2 ® page 40 of 52 D.O.TEC ANDIAMO.MC Manual - Version 1.1 © 2013 DirectOut GmbH... - Page 41 • Open drain MOSFET switch - max. 30 V, max. 200 mA. • Power supply: + 12 V, max. 200 mA (in total) latency • ca. 1 ms (A/D - D/A) ® © 2013 DirectOut GmbH D.O.TEC ANDIAMO.MC Manual - Version 1.1 page 41 of 52...
- Page 42 ® DirectOut Technologies This page is left blank intentionally. ® page 42 of 52 D.O.TEC ANDIAMO.MC Manual - Version 1.1 © 2013 DirectOut GmbH...
-
Page 43: Appendix A: Wiring Dsub-25
Power supply: + 12 V, max. 200 mA (in total) The pinout (3, 4, 5, 8, 9) complies with the GPO of D.O.TEC® PRO- DUCER.COM TASCAM is a registered trademark of TEAC corporation. ® © 2013 DirectOut GmbH D.O.TEC ANDIAMO.MC Manual - Version 1.1 page 43 of 52... -
Page 44: Appendix C: Configuration Examples
Remote protocol ‘ABCD’ active. *) As the scaling factor is set to 2 FS, the number of available channels in the MADI signal is reduced to 32 channels. ® page 44 of 52 D.O.TEC ANDIAMO.MC Manual - Version 1.1 © 2013 DirectOut GmbH... - Page 45 **) The setting ‘56 ch’ affects the MADI output signal only. All 32 MADI input channels are fed to the analog outputs. See the ‘Software Guide ANDIAMO Remote’ for application exam- ples. ® © 2013 DirectOut GmbH D.O.TEC ANDIAMO.MC Manual - Version 1.1 page 45 of 52...
-
Page 46: Appendix D: Sensitivity <> Gain
The reference level for digital full scale is a virtual value now. For the Andiamo.MC, we have therefore decided to specify the ‘sen- sitivity’ of the input setting rather than the ‘gain’. With a sensitivity of 0 dBu, an input signal with 0 dBu analog level will lead to a digital output level of 0 dBFS. -
Page 47: Examples
= -6 dBu digital level = -4 dBFS input level = -6 dBu sensitivity = -6 dBu digital level = 0 dBFS ® © 2013 DirectOut GmbH D.O.TEC ANDIAMO.MC Manual - Version 1.1 page 47 of 52... -
Page 48: Index
Input sensitivity General Purpose Output ____________ 31 see General Purpose Output Impedance input ............41 output ............41 Input sensitivity ________________ 36 Intended Operation ________________ 12 ® page 48 of 52 D.O.TEC ANDIAMO.MC Manual - Version 1.1 © 2013 DirectOut GmbH... - Page 49 ® DirectOut Technologies Notes ® © 2013 DirectOut GmbH D.O.TEC ANDIAMO.MC Manual - Version 1.1 page 49 of 52...
- Page 50 ® DirectOut Technologies Notes ® page 50 of 52 D.O.TEC ANDIAMO.MC Manual - Version 1.1 © 2013 DirectOut GmbH...
- Page 51 ® DirectOut Technologies Notes ® © 2013 DirectOut GmbH D.O.TEC ANDIAMO.MC Manual - Version 1.1 page 51 of 52...
- Page 52 ® DirectOut Technologies Notes ® page 52 of 52 D.O.TEC ANDIAMO.MC Manual - Version 1.1 © 2013 DirectOut GmbH...
