  • Page 1 ANDIAMO.MC Hardware Guide Version 2.0...
  • Page 2 DirectOut GmbH cannot be held responsible for any misleading or incorrect information provided throughout this manual. DirectOut GmbH reserves the right to change specifications at any time without notice. DirectOut Technologies® is a registered trademark of the DirectOut GmbH. © DirectOut GmbH, 2017 page 2 of 72...

  • Page 3: Table Of Contents

    Level Meters - analog output ..............31 Remote protocol ..................32 Signal Routing ..................... 34 Connecting MADI ..................37 Connecting Word clock ................38 Connecting GPO ..................38 Connecting USB ..................39 Connecting Analog ..................40 ANDIAMO.MC Hardware Guide - Version 2.0 page 3 of 72...
  • Page 4 Remote Protocol B - PRE™ (AVID) ............. 56 Remote Protocol C - Yamaha AD8HR ............61 Remote Protocol D - SSL ................65 Remote Protocol AB - Lawo Dallis .............. 66 Index page 4 of 72 ANDIAMO.MC Hardware Guide - Version 2.0...

  • Page 5: About This Document

    WAR NI N GS! alert you when an action should always be observed. This document relates to: • ANDIAMO.MC - firmware version 4.6 ANDIAMO.MC Hardware Guide - Version 2.0 page 5 of 72...

  • Page 6: Chapter 1: Overview Introduction

    CHAPTER 1: Overview CHAPTER 1: Overview Introduction The ANDIAMO.MC is a high-end 32-channel mic preamp and AD/DA MADI converter. It provides two MADI inputs and outputs and 32 channels analog microphone inputs and 32 channels line outputs. With two RU height, two redundant power supplies and excellent sounding converters the device offers best and safe audio quality at a minimal need of rackspace.

  • Page 7: Feature Summary

    (84 V to 264 V AC / 47 Hz to 63 Hz / safety class 1) Applications ANDIAMO.MC can be used for conversion, amplification, monitoring and recording of analog and digital signals. Typical applications include: • recording mic / line signals (32 inputs) •...

  • Page 8: Chapter 2: Legal Issues & Facts

    We would like to remind you to please check carefully whether the failure is caused by erroneous configuration, operation or connection before sending parts for repair. page 8 of 72 ANDIAMO.MC Hardware Guide - Version 2.0...

  • Page 9: First Aid (In Case Of Electric Shock)

    Check their pulse and reanimate if their respiration is poor. Lay the body down and turn it to one side. Call for a doctor immediately. • Having sustained an electric shock, always consult a doctor. ANDIAMO.MC Hardware Guide - Version 2.0 page 9 of 72...

  • Page 10: Updates

    This guide refers to firmware version 4.6 Intended Operation The ANDIAMO.MC is designed for conversion of audio signals from analog to digital and vice versa. In this context digital audio refers to a MADI signal (AES10). WARN ING ! No compensation can be claimed for damages caused by operation of this unit other than for the intended use described above.

  • Page 11: Conformity & Certificates

    Germany Only stamped parcels will be accepted! WEEE-Reg.-No. DE 64879540 Contact DirectOut GmbH Leipziger Str. 32, 09648 Mittweida, Germany Phone: +49 (0)3727 5665-100 Fax: +49 (0)3727 5665-101 Mail: sales@directout.eu www.directout.eu ANDIAMO.MC Hardware Guide - Version 2.0 page 11 of 72...

  • Page 12: Contents

    CHAPTER 2: Legal issues & facts Contents The contents of your ANDIAMO.MC package should include: • 1 x ANDIAMO.MC (19’’, 2 RU) • 2 x power chord • 2 x fixing unit for power plug • 1 x Hardware Guide To complete the delivery please download from the product page on the DirectOut website (www.directout.eu):...

  • Page 13: Accessories

    ANDIAMO unit. BREAKOUT.AN8 - analog input / output, 8 channels Article code: DOBOB0719 BREAKOUT.AN16I - analog input, 16 channels Article code: DOBOB0720 BREAKOUT.AN16O - analog output, 16 channels Article code: DOBOB0721 ANDIAMO.MC Hardware Guide - Version 2.0 page 13 of 72...
  • Page 14 Digital patch cable for connection with DOCAA0332 BREAKOUT.AES or AESid transferring 8 audio channels, length 0.5 m DSUB25.AES100 Digital patch cable for connection with DOCAA0333 BREAKOUT.AES or AESid transferring 8 audio channels, length 0.5 m page 14 of 72 ANDIAMO.MC Hardware Guide - Version 2.0...

  • Page 15: Chapter 3: Installation

    BNC / SC Version SC / SC Version N OT E ! Retain the protective cap if the optical port is unused. This will protect against soiling which can lead to malfunction. ANDIAMO.MC Hardware Guide - Version 2.0 page 15 of 72...
  • Page 16 This device may operate with only one power supply. To provide power supply redundancy, it is recommended to connect both PSU 1 and PSU 2 to independent power supplies with separate fuses. page 16 of 72 ANDIAMO.MC Hardware Guide - Version 2.0...
  • Page 17 N OTE To update the fi rmware an installed USB Serial driver (Windows) and the Update Tool are necessary. The software and the installation instructions are available at www.directout.eu. ANDIAMO.MC Hardware Guide - Version 2.0 page 17 of 72...
  • Page 18 Installation of ‘ANDIAMO Remote’ (Windows® / OS X®) • download the ‘Software Guide ANDIAMO Remote‘ • download the ‘ANDIAMO Remote’ application • follow the installation instructions in the ‘Software Guide ANDIAMO Remote’ page 18 of 72 ANDIAMO.MC Hardware Guide - Version 2.0...
  • Page 19 CHAPTER 3: Installation This page is left blank intentionally. ANDIAMO.MC Hardware Guide - Version 2.0 page 19 of 72...

  • Page 20: Chapter 4: Operation Introduction

    • 44.1 kHz or 48 kHz = 1 FS • 88.2 kHz or 96 kHz = 2 FS • 176.4 kHz or 192 kHz = 4 FS page 20 of 72 ANDIAMO.MC Hardware Guide - Version 2.0...

  • Page 21: Global Control

    Note that an unlit LED does not guarantee that the device is free of voltage. To ensure that the device is completely disconnected from mains voltage, the power chords must be disconnected. ANDIAMO.MC Hardware Guide - Version 2.0 page 21 of 72...

  • Page 22: Menu Control

    N OTE Blinking LEDs are also used to indicate an error (e.g. missing sync). Concentrate on the section where one LED is blinking and the remaining LEDs are glowing weak. page 22 of 72 ANDIAMO.MC Hardware Guide - Version 2.0...
  • Page 23 • Configuration of the system fan control • Redundancy Modes • USB Embedder • Preset management • Display Dark The settings are stored inside the device. * ANDIAMO.MC provides D/A calibration only. ANDIAMO.MC Hardware Guide - Version 2.0 page 23 of 72...

  • Page 24: Clocking

    LED blinking = Clock source set to MADI input and no signal present LED (green): indicates use of internal clock generator as clock source LED ON = Clock source set to internal clock generator page 24 of 72 ANDIAMO.MC Hardware Guide - Version 2.0...
  • Page 25 The redundancy mode is adjusted via remote control. Default setting ‘Standard’: The MADI input that locks fi rst will be selected automatically, switchover at signal loss, no revert when signal is regained. ANDIAMO.MC Hardware Guide - Version 2.0 page 25 of 72...

  • Page 26: Sample Rates

    96k Frame signal has been detected. With 48k Frame signals no distinction is possible between 1 FS or 2 FS or 4 FS - so the scaling factor has to be set manually. page 26 of 72 ANDIAMO.MC Hardware Guide - Version 2.0...

  • Page 27: Output Format

    96k Frame is available at 2 FS operation only. TI P To convert a 2 FS MADI signal from 48k Frame (SMUX) into a 96k Frame signal, set the converter to 2 FS operation and activate 96k Frame. ANDIAMO.MC Hardware Guide - Version 2.0 page 27 of 72...

  • Page 28: Level Settings

    The level setting of the input channels is accessible using the menu - see „CHAPTER 5: Menu Navigation“ on page 42. T I P Additional settings via remote control: • Output gain/level trim for individual channels • DA calibration in 0.1 dB increments page 28 of 72 ANDIAMO.MC Hardware Guide - Version 2.0...

  • Page 29: Level Meters - Analog Input

    LED (green): indicates signal level of channel input LED ON = analog input signal equals to more than -18 dBFS The LED starts to light up softly at -60 dBFS and reaches full brightness at -18 dBFS. ANDIAMO.MC Hardware Guide - Version 2.0 page 29 of 72...

  • Page 30: Display - Input Channel Settings

    The level metering of the input channel is ‘behind’ the PAD switch. It may be useful to check PAD setting if no signal seems to be present. WARN ING Switching PAD may result in abrupt changes of loudness. page 30 of 72 ANDIAMO.MC Hardware Guide - Version 2.0...

  • Page 31: Level Meters - Analog Output

    (dBFS). LED (green): indicates signal level of channel output LED ON = analog output signal equals to more than -60 dBFS The light intensity of the LEDs depends on the audio level. ANDIAMO.MC Hardware Guide - Version 2.0 page 31 of 72...

  • Page 32: Remote Protocol

    • Embedded Serial (‘Serial over MADI’) • Embedded MIDI (‘MIDI over MADI’) • USB over Ethernet (‘DO.Net’) The connection methods are explained in the Software Guide for the ANDIAMO Remote - available at www.directout.eu. page 32 of 72 ANDIAMO.MC Hardware Guide - Version 2.0...
  • Page 33 Remote control via Lawo (Dallis) The ANDIAMO.MC can be remote controlled from a Lawo mc² mixing console or Nova router. This requires an own Lawo certified firmware which is available at the ANDIAMO.MC product page at www.directout.eu. A license for this firmware can be obtained from DirectOut GmbH or your local DirectOut representative.

  • Page 34: Signal Routing

    MADI @ 2 FS = 32 channels, MADI @ 4 FS = 16 channels Both portions of the MADI stream are used for A/D input and D/A output - no selection possible. page 34 of 72 ANDIAMO.MC Hardware Guide - Version 2.0...
  • Page 35 MADI outputs may transmit individual signals. Delay compensation not active. Both LED columns blinking two times alternately. Matrix Mode active Extended Routing active MADI outputs may transmit individual signals. Delay compensation active. ANDIAMO.MC Hardware Guide - Version 2.0 page 35 of 72...
  • Page 36 + 4 samples NOT E To ensure proper detection of delay compensation no other device must be connected in between two ANDIAMOs. Delay compensation may be deactivated in the ANDIAMO Remote. page 36 of 72 ANDIAMO.MC Hardware Guide - Version 2.0...

  • Page 37: Connecting Madi

    The MADI outputs may work in parallel or idependent from each other - see “Extended Routing” on page 35 TI P Additional settings via remote control: • Routing Matrix (Matrix Mode / Extended Routing) • Redundancy Modes ANDIAMO.MC Hardware Guide - Version 2.0 page 37 of 72...

  • Page 38: Connecting Word Clock

    (12 V, max. 200 mA) is also provided. This allows to remote control external devices; e.g. a recording light. DSUB-9 socket (female) Connect for GPO application here. Observe the pin out - see „Appendix B - DSUB-9 Pin assignment“ on page 51. page 38 of 72 ANDIAMO.MC Hardware Guide - Version 2.0...

  • Page 39: Connecting Usb

    USB socket (Type B) Connect for fi rmware updates and remote control here. The use of the USB port requires the USB Serial driver installed. The driver and the installation instructions are available at the ANDIAMO.MC product page at www.directout.eu. TI P Additional settings via remote control: •...

  • Page 40: Connecting Analog

    25..32 Analog audio input (balanced) - connect audio channels 25 to 32 here The pinout complies with AES59 (‘TASCAM pinout’) see „Appendix A - DSUB-25 Pin assignment“ on page 50. page 40 of 72 ANDIAMO.MC Hardware Guide - Version 2.0...
  • Page 41 The line output is not servo balanced. Do not connect the negative lead to ground. This may cause damage at the output stage. Observe the technical specifications listed in this document. ANDIAMO.MC Hardware Guide - Version 2.0 page 41 of 72...

  • Page 42: Chapter 5: Menu Navigation

    NOT E Blinking LEDs are also used to indicate an error (e.g. missing sync). Concentrate on the section where one LED is blinking and the remaining LEDs are glowing weak. page 42 of 72 ANDIAMO.MC Hardware Guide - Version 2.0...
  • Page 43 > 2 sec SELECT MATRIX MODE SELECT SELECT SET ▲ ▼ REMOTE PROTOCOL SELECT SELECT SELECT TO CHANNEL 31 SET ▲ P48 SET ▼ PAD CHANNEL 32 SET ▲ ▼ SENSITIVITY ANDIAMO.MC Hardware Guide - Version 2.0 page 43 of 72...

  • Page 44: Input Sensitivity (Gain Setting)

    (PAD not activated) -48 dBu (PAD activated) 0 dBu +6 dBu (-36 dBu with activated PAD) +24 dBu (-14 dBu with activated PAD) +30 dBu (0 dBu with activated PAD) page 44 of 72 ANDIAMO.MC Hardware Guide - Version 2.0...
  • Page 45 Positive values are displayed as calculation of a decimal minus a combination of 1 dB values. N OT E There is a correlation between ‘input sensitivity’ and the commonly used term ‘gain’. See „Appendix C - Sensitivity <> Gain“ on page 52. ANDIAMO.MC Hardware Guide - Version 2.0 page 45 of 72...
  • Page 46 CHAPTER 5: Menu Navigation This page is left blank intentionally. page 46 of 72 ANDIAMO.MC Hardware Guide - Version 2.0...

  • Page 47: Chapter 6: Troubleshooting And Maintenance

    To clean the device, use a soft, dry cloth. To protect the surface, avoid using cleaning agents. N OT E ! The device should be disconnected from the power supply during the cleaning process. ANDIAMO.MC Hardware Guide - Version 2.0 page 47 of 72...

  • Page 48: Chapter 7: Technical Data

    • 4 x DSUB-25 (8 analog audio channels each - balanced), AES59 compliant Analog Output • 4 x DSUB-25 (8 analog audio channels each - balanced), AES59 compliant • The outputs are not servo balanced. page 48 of 72 ANDIAMO.MC Hardware Guide - Version 2.0...

  • Page 49: Word Clock

    • 1 x USB 2.0 socket (Type B) • Open drain MOSFET switch - max. 30 V, max. 200 mA. • Power supply: +12 V, max. 200 mA (in total) ANDIAMO.MC Hardware Guide - Version 2.0 page 49 of 72...

  • Page 50: Appendix A - Dsub-25 Pin Assignment

    CH 1 OUT + CH 4 − CH 4 IN − CH 3 + CH 3 IN + CH 2 − CH 2 IN − CH 1 + CH 1 IN + page 50 of 72 ANDIAMO.MC Hardware Guide - Version 2.0...

  • Page 51: Appendix B - Dsub-9 Pin Assignment

    GPO - Open drain MOSFET switch - max. 30 V, max. 200 mA. Power supply: + 12 V, max. 200 mA (in total) The pinout (3, 4, 5, 8, 9) complies with the GPO of PRODUCER.COM ANDIAMO.MC Hardware Guide - Version 2.0 page 51 of 72...

  • Page 52: Appendix C - Sensitivity <> Gain

    The reference level for digital full scale is a virtual value now. For the ANDIAMO.MC, we have therefore decided to specify the ‘sensitivity’ of the input setting rather than the ‘gain’. With a sensitivity of 0 dBu, an input signal with 0 dBu analog level will lead to a digital output level of 0 dBFS.
  • Page 53 0 dBu +18 dB -30 dBFS Input level Sensitivity Gain Digital level Ref. Level: +18 dBu Input level -10 dBu, Sensitivity 0 dBu (= Gain +18 dB), Digital level -10 dBFS ANDIAMO.MC Hardware Guide - Version 2.0 page 53 of 72...
  • Page 54 0 dBu +18 dB -30 dBFS Input level Sensitivity Gain Digital level Ref. Level: +18 dBu Input level -10 dBu, Sensitivity -10 dBu (= Gain +28 dB), Digital level 0 dBFS page 54 of 72 ANDIAMO.MC Hardware Guide - Version 2.0...

  • Page 55: Appendix D - Remote Protocols

    Appendix D - Remote Protocols Appendix D - Remote Protocols Overview ANDIAMO.MC supports various remote control protocols for comfortable use straight from a mixing console or DAW application. The objective of this section is to help building a working setup and to inform about particular peculiarities.

  • Page 56: Remote Protocol B - Pre™ (Avid)

    • PAD affects 30 dB not 18 dB as the PRE™ device • Different gain ranges of PRE™ (gain 0 dB to +69 dB) and ANDIAMO.MC (input sensitivity 0 dB to -54 dB), i.e. values higher than +54 dB will have no effect.
  • Page 57 Setup - MIDI - Input Devices Setup - Peripherals - Mic Preamps • Specify four PRE™ devices • Assign individual MIDI channels for each device (there are 16 channels available) ANDIAMO.MC Hardware Guide - Version 2.0 page 57 of 72...
  • Page 58 • Assign the channel mapping for each PRE™ • Done. • The control is available in the Edit- and Mix-Window. • Click into the ‘mic’ area to open an enlarged view of the control page 58 of 72 ANDIAMO.MC Hardware Guide - Version 2.0...
  • Page 59 PAD disabled PAD disabled Input sensitivity: +30 dBu Input sensitivity: 0 dBu Input sensitivity: -54 dBu N OT E Holding <alt> while changing a parameter will affect all channels http://akmedia.digidesign.com/support/docs/PRE_Guide_v90_70448.pdf ANDIAMO.MC Hardware Guide - Version 2.0 page 59 of 72...
  • Page 60 Bidirectional MADI link with EXBOX.MIDICOM (MADI 1) Pro Tools® Bidirectional MIDI link with EXBOX.MIDICOM (DIN) MADI Embedder mode set to MIDI EXBOX.MIDICOM MADI + MIDI Bidirectional MADI link with EXBOX.MIDICOM (MADI 2) ANDIAMO.MC page 60 of 72 ANDIAMO.MC Hardware Guide - Version 2.0...

  • Page 61: Remote Protocol C - Yamaha Ad8Hr

    • The console will permanently check, which devices are connected and they will be listed with their IDs. • You can assign audio I/O slots for each device. The ANDIAMO.MC shows up as four consecutive devices, each of which has eight channels.
  • Page 62 HA CONTROL page, which can be found next to the PHASE / INSERT pages • The HPF on/off and frequency settings are ignored by the ANDIAMO.MC. • As the AD8HR protocol does not support a pad command, the Andiamo.MC’s pad is included in the gain value.
  • Page 63 • The console will permanently check, which devices are connected and they will be listed with their IDs. • You can assign audio I/O slots for each device.The ANDIAMO.MC shows up as four consecutive devices, each of which has eight channels.
  • Page 64 Bidirectional MIDI link with EXBOX.MIDICOM (DSUB-9 Desk MADI RS-232 Embedder mode set to 232 EXBOX.MIDICOM Baud rate set to 38k4 MADI + RS-232 Bidirectional MADI link with EXBOX.MIDICOM (MADI 2) ANDIAMO.MC page 64 of 72 ANDIAMO.MC Hardware Guide - Version 2.0...

  • Page 65: Remote Protocol D - Ssl

    first 8 slots starting form the left, and 8 Line output modules in the corresponding lower slots. The ANDIAMO.MC supports 2 FS S/MUX mode for higher sample rate operation with C200. ANDIAMO.MC Hardware Guide - Version 2.0...

  • Page 66: Remote Protocol Ab - Lawo Dallis

    Remote Protocol AB - Lawo Dallis General Information ANDIAMO.MC with an own Lawo certifi ed fi rmware can be remote controlled from a Lawo mc² mixing console or Nova router. A license for this fi rmware can be obtained from DirectOut GmbH.
  • Page 67 ‘AB’ must be selected on the front panel of the device. ANDIAMO.MC will then force the sync source to MADI Input. Please make sure to set up a bi-directional MADI connection between the console / router and the ANDIAMO.MC.

  • Page 68: Index

    Signal Routing .......... 34 Bank Routing ........34 Single-/Multi-mode ........12 Gain see Input Sensitivity SNR (AD & DA) ........49 Support ............ 47 System Settings ........42 Impedance (input/output) ......49 page 68 of 72 ANDIAMO.MC Hardware Guide - Version 2.0...
  • Page 69 Index Technical Data .......... 48 THD (AD & DA) ........49 Troubleshooting ........47 Updates ........... 10 USB ............7 Warranty ..........10 ANDIAMO.MC Hardware Guide - Version 2.0 page 69 of 72...
  • Page 70 Notes page 70 of 72 ANDIAMO.MC Hardware Guide - Version 2.0...
  • Page 71 Notes ANDIAMO.MC Hardware Guide - Version 2.0 page 71 of 72...
  • Page 72 DirectOut GmbH Leipziger Strasse 32 T: +49-3727-5665-100 09648 Mittweida F: +49-3727-5665-101 Germany www.directout.eu...
