Distribution Box In Engine Compartment F38-F39 - Volvo V70 2014 Wiring Diagram

Fuses

Distribution box in engine compartment F38-F39

15/31 Distribution box in engine compartment
No. No. Fuse function
F38 11B/38 4/46
6/139
6/140
7/35
8/3
8/28
8/77
8/117
8/125
8/126
F39 11B/39 7/15
7/82
7/15
7/215
7/15
8/18
TP 39264202 V70(08-), XC70(08-) & S80(07-) 2014 © Volvo Car Corporation 2013
Engine Control Module (ECM)
Upper actuator motor, intake manifold, 6-Cyl. W/O T
Lower actuator motor, intake manifold, 6-Cyl. W/O T
Oil level sensor, 6-Cyl.
Electromagnetic clutch, climate control system
Turbo control valve
Control valve, fuel volume
Solenoid, variable valve timing, intake, 6-Cyl.
Solenoid cam profile front, 6-Cyl. W/O T
Solenoid cam profile rear, 6-Cyl. W/O T
Front heated oxygen sensor, 4-Cyl.
Rear heated oxygen sensor, 4-Cyl. Turbo
Front heated oxygen sensor, 5-Cyl. Diesel
Rear heated oxygen sensor, 5-Cyl. Diesel
Front heated oxygen sensor, 5-Cyl. Turbo.
EVAP valve, 5-Cyl. Turbo.
continues
via A
- 10
-
-
-
-
-
-
-
-
-
- 10
-
-
-
- 15
-
-
19
