Distribution Box In Engine Compartment F38 - Volvo V70 2014 Wiring Diagram

Fuses

Distribution box in engine compartment F38

15/31 Distribution box in engine compartment
No. No. Fuse function
F38 11B/38 8/18
8/28
7/17
8/19
8/81
8/159
2/14
6/73
7/17
7/35
8/3
8/18
8/28
8/81
8/117
7/35
8/3
8/113
8/164
TP 39264202 V70(08-), XC70(08-) & S80(07-) 2014 © Volvo Car Corporation 2013
EVAP valve, 4-Cyl.
Turbocharger control valve, 4-Cyl.
Mass air flow sensor MAF, 4-Cyl. Turbo
Solenoid, variable valve timing, intake, 4-Cyl. Turbo
Solenoid, variable valve timing, exhaust, 4-Cyl. Turbo
Bypass valve
Relay, glow plug system
Coolant pump, Start/Stop, 4-Cyl. Diesel
Mass air flow sensor MAF, 5-Cyl. Turbo
Oil level sensor, 5-Cyl. Turbo
Electromagnetic clutch climate control system, 5-Cyl. Turbo
EVAP valve, 5-Cyl. Turbo
Turbocharger control valve, 5-Cyl. Turbo
Solenoid, variable valve timing, exhaust, 5-Cyl. Turbo
Solenoid, variable valve timing, intake, 5-Cyl. Turbo
Oil level sensor, 5-Cyl. Diesel
Electromagnetic clutch, climate control system, 5-Cyl. Diesel
Bypass valve, EGR cooling, 5-Cyl. Diesel
Electric piston cooling valve
continues
via A
- 10
-
-
-
-
-
-
2/14
-
-
-
-
-
-
-
-
-
-
-
18
