Distribution Box In Engine Compartment F22-F31 - Volvo V70 2014 Wiring Diagram

Fuses

Distribution box in engine compartment F22-F31

15/31 Distribution box in engine compartment
No. No. Fuse function
F22 11B/22 -
F23 11B/23 3/111
F27 11B/27 2/17
2/31
2/182
4/56
6/104
F28 11B/28 2/64
10/65
10/69
F29 11B/29 2/17
16/10
16/11
F30 11B/30 2/32
4/46
4/56
F31 11B/31 4/28
TP 39264202 V70(08-), XC70(08-) & S80(07-) 2014 © Volvo Car Corporation 2013
Light Switch Module (LSM)
Relay, horn
Relay, 15-feed
Relay, headlight washer motor
Central Electronic Module (CEM)
Washer motor headlights
Relay, auxiliary lights
Auxiliary light, front right
Auxiliary light, front left
Relay, horn
Horn 1
Horn 2
Main relay, engine management system
Engine Control Module (ECM)
Central Electronic Module (CEM)
Transmission Control Module (TCM)
continues
via A
- -
- 5
- 5
-
-
2/17, 2/31,
2/182
-
- 20
2/64
2/64
- 15
2/17
2/17
- 10
-
2/32
- 15
16
