Distribution Box In Engine Compartment F8-F21 - Volvo V70 2014 Wiring Diagram

Fuses

Distribution box in engine compartment F8-F21

15/31 Distribution box in engine compartment
No. No. Fuse function
F8 11B/8 9/7
F9 11B/9 6/1
F10 11B/10 4/7
4/106
F11 11B/11 4/31
6/28
F12 11B/12 9/7
F13 11B/13 4/16
F14 11B/14 4/16
F15 11B/15 2/182
F16 11B/16 10/1
10/2
F17 11B/17 4/56
F17-F20 Fuses in the Central Electronic Module (CEM)
F18 11B/18 4/16
F19 11B/19 4/99
6/164
F20 11B/20 4/28
4/28B
4/46
4/9
F21 11B/21 9/43
9/44
TP 39264202 V70(08-), XC70(08-) & S80(07-) 2014 © Volvo Car Corporation 2013
Heated windshield
Wiper Motor Module (WMM)
Combustion Preheater Module (CPM)
Control module, remote parking heater start
Passenger compartment fan control module
Motor, passenger compartment fan
Heated windshield
Brake Control Module (BCM), pump
Brake Control Module (BCM), valves
Relay, headlight washer motor
Lamp housing, front left
Lamp housing, front right
Central Electronic Module (CEM)
Brake Control Module (BCM)
Speed dependent power steering control module
Electrical power steering module (EHPS)
Transmission Control Module (TCM)
Transmission Control Module (TCM) MPS6
Engine Control Module (ECM)
Supplemental restraint system module (SRS)
Heated windshield washer nozzle, left
Heated windshield washer nozzle, right
continues
via A
2/182 40
- 30
- 25
-
- 40
-
2/182 40
- 40
- 20
- 20
- 10
-
- 20
-
- 5
- 5
-
- 10
-
-
-
- 10
-
15
