- Page 1 AU-D18 Analogue Stereo Lip Sync Corrector OPERATION MANUAL...
- Page 2 Safety Precautions Please read all instructions before attempting to unpack or install or operate this equipment, and before connecting the power supply. Please keep the following in mind as you unpack and install this equipment: Always follow basic safety precautions to reduce the risk of fire, electrical shock and injury to persons.
-
Page 3: Table Of Contents
Table of Contents 1. Introduction .................. 1 2. Applications ................. 1 3. Package Contents ..............1 4. System Requirements ..............1 5. Features ..................1 6. Specifications ................2 6.1 Input Audio Reference Level ......... 2 7. Operation Controls and Functions ..........3 Top Panel .............. -
Page 4: Introduction
1. Introduction The analog to analog Lip SYNC Corrector is a tiny cutie device for your audio output delay correction. For every channel of your audio output, the Lip SYNC corrector is able to adjust it with the best timing to display so that users may received both video and audio with more vividly and live enjoyment. -
Page 5: Specifications
6. Specifications Input Port 1 x L/R Sample Frequency 48 kHz Output Port 1 x L/R Input Impedance 44Kk Ω Output Imp edance 1k Ω Power Supply 5V / 1A DC ( US/EU standards, CE/FCC/UL certified) ESD Protection Human body model: ± 8kV (air-gap discharge) ±... -
Page 6: Operation Controls And Functions
7. Operation Controls and Functions 7.1 Top Panel POWER LED: The LED will illuminate in blue when the power is turn on. ① 7.2 Rear Panel L/R IN: These slots are to connect with input source equipments such as ① DVD/Blue-Ray player with RCA cable for audio input signal sending. 7.3 Left Panel L/R OUT: These slots are where you connect the amplifier or active ①... -
Page 7: Front Panel
7.4 Front Panel Lip SYNC switch: This switch has 8 section from 0 to 7 that allows user to ① set the audio output for delay display from 0~300 millisecond. 7.5 Rear Panel DC 5V: This slot is where you plug the 5V DC power supply into the unit ①... -
Page 8: Connection And Installation
5. Connection Diagram 6. Specifications Input Port 2 x Analogue Audio (L/R stereo) LPCM 7.1, 5.1 or 2 channels and Bitstream (Dolby HDMI input Audio Format TrueHD, Dolby Digital Plus and DTS-HD Master Audio) Output Port 2 x Analogue Audio (L/R stereo) PCM2/5.1/7.1, Dolby 5.1, DTS 5.1, DD+, HDMI Output Audio Formats D-TrueHD, DTS-HD... -
Page 9: Acronym
Acronyms Acronym Complete Term... - Page 11 www.cypeurope.com...
