Rural King RK55 Shuttle Shift Series Operator's Manual page 59

DESCRIPTION OF TRACTOR CONTROlS
► BRAKE PEDAl
Right and left brake pedals are pro-
vided to assist in turning the tractor
in the field.
CAUTION
•
A connecting latch is provided
to connect the right and left
brake pedals for high speed
or road use.
•
In the interest of safety al-
ways use it on the road or at
high speed as using one side
only can cause rollovers.
•
When servicing the tractor
ensure that the adjustment on
both sides in the same.
3 - 14
RK55S,55SC-영문판-03.indd 14
Acceleration Pedal
► FOOT OPERATED ACCEl-
ERATOR
This pedal can override a fixed hand
throttle setting.
Parking Brake Lever
T45O31A
► PARKING BRAKE lEVER
Connect the brake pedals, push
them down while pulling the park
brake up to engage. Press the park-
ing brake pedal and push the Brake
pedal to release.
T45O30A
