DESCRIPTION OF TRACTOR CONTROlS
<Engine oil pressure lamp>
Will go out as soon as
the engine starts if the oil
pressure is correct. If it
comes on while the en-
gine is running, stop the
engine and get expert ad-
vice.
<Charge lamp >
This light will go off as
soon as the engine starts
to run to indicate that the
alternator is changing.
(Please note, as broken
fan belt can cause the light
to come on, please stop
the engine as overheating
can occur if not rectified
immediately)
Glow signal Lamp indi-
cates preheating.
3 - 6
RK55S,55SC-영문판-03.indd 6
< Air cleaner filter con-
tamination indicator >
This comes on when the air cleaner
is clogged by foreign materials.
When this comes on, open the cover
and clean the inside of the cleaner.
Also, blow air through the filter in
the direction of intake air to clean it
or replace the filter with a new one.
<DPF warning lamp>
This lamp blinks when car-
bon is accumulated in the
diesel particulate filter. If
this lamp blinks, press the
regeneration button.
<DPF progress indicator>
This lamp comes on when
DPF regeneration is in
progress.
<PTO monitor lamp >
The PTO monitor lamp on
the dash panel indicates
the state.
1. If the monitor glows:
The PTO is rotating.
. If the monitor is off: The
PTO is off.
3. If the monitor blinks:
The PTO is present-
ly stationary but will in-
stantly start rotating of
the clutch pedal is re-
leased or the imple-
ments lowered.
