Rural King RK55 Shuttle Shift Series Operator's Manual page 49

DESCRIPTION OF TRACTOR CONTROlS
/ min
► TACHOMETER
This meter shows the revolutions of
the engine and the PTO shafts as
well as the travel speed in top gear.
3 - 4
RK55S,55SC-영문판-03.indd 4
R5SO305A
► WAT E R T E M P E R AT U R E
WARNING lAMP
This comes on when the coolant
temperature is over 110 degrees.
T45O306A
► FUEl GAUGE
Shows the amount of fuel in the tank
when the ignition switch is "ON".
T45O307A
