▶ A IR CONdITIONINg SYSTEM
The system is designed to ensure
optimum temperature inside the cab
and maximum comfort and safety
for the operator.
However, it is advisable to consult
our specialized workshops whenev-
er repairs or adjustments need to be
performed.
Do not approach the system with
open flames, as any escape from
the circuit may produce a lethal gas.
RK55S,55SC-영문판-06.indd 11
① Alternator
② Compressor
③ Speed Fan
④ Electric Resistance
⑤ Evaporator
⑥ Air Filter
⑦ Recirculation Inlets
⑧ Pivotal Air Diffusers
CABIN SYSTEM
Roof Hatch
T45O617A
▶ R OOF HATCH (IF EqUIppEd)
Ventilation-push the latch towards
the front of the tractor and then
push the hatch up.
Emergency Exit-Push firmly up-
wards to release the support struts
from the lower retainer clips.
T45O618A
6
6 - 11
