Summary of Contents for FROGGYS FOG Fire Base 1300 Cased
Page 1
FireBase is a registered trademark of Froggys Fog Manual Firebase 1300 and Fire Base 1300 Cased Froggys Fog 302 Rutherford Lane Columbia, TN 38401 877-376-4499 sales@froggysfog.com www.froggysfog.com www.trainingsmoke.com...
Page 2
• Spilled fluid or splashed fluid droplets can cause slip hazard. Mop up the fluid and dispose of it according to regulations. Froggys Fog Fluids are environmentally safe products and can be recycled biologically. • Artificially-made fog can be produced in many different ways. The method used here to produce fog, with a device which works according to the vaporizer principle, is the most harmless one.
Page 3
Fire Rescue Fog High Density – Long Lasting Smoke Fluid Use only Original Froggys Fog – Fog Fluids. Other fluids can cause considerable damage to the unit and void the warranty. You can get more general information about fog fluids from your dealer or www.froggysfog.com...
Page 4
6 Operating the SG-1300 and SG-1300-CASED SG-1300 is a powerful fog generator, producing every desired effect from a tiny puff of smoke to the thickest fog. Digital technology makes fine adjustments of the pump possible. In steps of 1% the output can be adjusted from 1-99%. Control panel SG-1300 •...
Page 5
Control choices External control You may control the SG-1300 or SG-1300-CASED externally through the XLR sockets. Please note: DMX takes priority. That means: when the machine is controlled via 5-PIN DMX 512 this data takes priority over the 0-10 V (+) 3-PIN XLR Analog Remote and Stand-alone operation.
Page 6
Adjust the pump output with the Up/Down-buttons Press the Enter-button once to start the fogging process. The machine now produces fog until the Enter-button is pressed again. The output can be changed during the fogging process. Press Mode again to standard menu. Operating with firebase SG-RM-XLR remote and 0-10V (+) DC Connect the SG-1300 or SG-1300-CASED to the SG-RM-XLR remote...
Page 7
Control via FireBase SG-RM-WR - Wireless Remote for FireBase Series A wireless remote is available as an option. It will be delivered with a 3pin XLR plug. Connect the receiver of the radio remote to the machine by using the 3pin XLR socket on the back of the machine.
Page 8
Operating with the internal timer With the internal timer the „fog time” and ”wait time” as well as the output can be adjusted. To start the Timer-Mode, press the Mode-button for more than 2 seconds. The red Timer-LED] shines as soon as the machine has switched to the Timer-Mode. As long as the timer is in operation, the red Timer-LED blinks.
Page 9
Pressing the Enter button will bring you back to the standard menu where you start the programming. Pressing the enter button during the programming in Timer-menus will start the cycle with the last time shown on the display. (P.xx = Starts with wait time, F.xx = Starts with fog time).
Page 10
10 Trouble-Shooting SG-1300 does not fog • Check external control signals • Check mains supply • Check fluid tank (empty?) • Check for correct connections at the fluid bottle • Check for fluid in the fluid tube • Check if fluid filter is clogged SG-1300 fogs uncontrollably •...
Page 11
11 Specifications Procedure: Simulated Smoke – Vaporizing Fog Generator Power requirement: 1300 Watt Voltage: 110 V/ 60 Hz Warm up time: approx. 7 min. Fluid Consumption: at max. output 120 ml/min at cont. output 35 ml/min Fluid tank capacity: 5 Liter Fog output: adjustable in steps of 1% (0-99) Fogging time:...
Page 12
The right of guarantee service is also lost if fluids other than Froggys Fog Fluids have been used or if units are sent to us with full fluid bottles. Also noncompliance with the instructions in this manual or mistakes by incorrect handling/ treating of the machine will lead to a loss of guarantee and also any faults and damages caused by undue force.
