- Page 1 GRUNDFOS INSTRUCTIONS ALPHA Reader MI401 Installation and operating instructions...
-
Page 2: Table Of Contents
5.1 Cleaning the product 5.2 Changing the battery 5.3 Installing software and updates Fault finding the product 6.1 Grundfos GO Balance app on Apple iOS 6.2 Grundfos GO Balance app on Android 6.3 ALPHA Reader Technical data Disposing of the product... -
Page 3: General Information
Notes or instructions that make the job easier and ensure safe Note operation. 1.2 Abbreviations used in this document Abbreviation Description Application Bluetooth low energy 1.3 Radio communication Grundfos ALPHA Reader BLE unit is approved in all EU countries. -
Page 4: Receiving The Product
2. Receiving the product 2.1 Scope of delivery • Quick guide • MI401 ALPHA Reader unit • CR2032 lithium battery. Fig. 1 ALPHA Reader... -
Page 5: Product Introduction
3. Product introduction The MI401, ALPHA Reader unit is the receiver and transmitter of pump performance data. The unit broadcasts to an Android or iOS-based mobile device via Bluetooth. The unit uses a small lithium battery. The unit is together with the Grundfos GO Balance app used for balancing heating system primarily in one-family houses. -
Page 6: Starting Up The Product
3. Press the power button to switch on the unit. The indicator light flashes every second indicating that the unit is on. 4. Start the Grundfos GO Balance app on your mobile device. Bluetooth is automatically activated. The app will try to find the transmission from the unit. -
Page 7: Supported Devices
4.2 Supported devices The unit and the Grundfos GO Balance app is supported by Android devices with Android 4.4 or later and iOS devices with iOS 8 or later. You must use a mobile device which support Bluetooth. 4.3 Performing hydronic balancing... -
Page 8: Setting Up A Signal Repeater
4.4 Setting up a signal repeater You can expand the range of the unit signal by using a second unit. The second unit will repeat the signal from the primary unit which is installed on the pump. The primary unit must be on and transmitting data. 1. -
Page 9: Servicing The Product
3 seconds. 5.3 Installing software and updates If you have installed Grundfos GO Balance on a mobile device, you will be notified when software updates are available through either App Store or Google Play. -
Page 10: Fault Finding The Product
6. Fault finding the product 6.1 Grundfos GO Balance app on Apple iOS The app does not start when you press the icon. The app freezes. The app exits without warning. 1. Close the app. 2. Press the home button twice very quickly to see running apps. -
Page 11: Alpha Reader
6.3 ALPHA Reader The signal between the mobile device and the unit is lost. 1. Move your mobile device closer to the unit. Outside Bluetooth range. 2. If the signal is not strong enough, use a second unit as signal repeater. See section 7. -
Page 12: Disposing Of The Product
This product or parts of it must be disposed of in an environmentally sound way: 1. Use the public or private waste collection service. 2. If this is not possible, contact the nearest Grundfos company or service workshop. Dispose of the waste battery through the national collective schemes. If in doubt, contact your local Grundfos company. - Page 13 We, Grundfos, declare under our sole responsibility that the product Grundfos MI401, ALPHA Reader, to which the declaration below relates, is in conformity with the Council Directives listed below on the approximation of the laws of the EC/EU member states.
- Page 14 HR: EC/EU deklaracija sukladnosti Mi, Grundfos, izjavljujemo s punom odgovornošću da je proizvod Grundfos MI401, ALPHA Reader, na koja se izjava odnosi u nastavku, u skladu s direktivama Vijeća dolje navedenih o usklađivanju zakona država članica EZ-a / EU-a. Napomena: Postoje dva seta direktiva vijeća i standarda navedenih dolje. Jedan set se odnosi do, i uključujući 19 Travanja 2016.
- Page 15 PT: Declaração de conformidade CE/UE A Grundfos declara sob sua única responsabilidade que o produto Grundfos MI401, ALPHA Reader, ao qual diz respeito a declaração abaixo, está em conformidade com as Directivas do Conselho sobre a aproximação das legislações dos Estados Membros da CE/UE.
- Page 16 RS: Deklaracija o usklađenosti EC/EU Mi, kompanija Grundfos, izjavljujemo pod punom vlastitom odgovornošću da je proizvod Grundfos MI401, ALPHA Reader, na koji se odnosi deklaracija ispod, u skladu sa dole prikazanim direktivama Saveta za usklađivanje zakona država članica EC/EU. Napomena: Ispod su navedena dva seta direktiva Saveta. Jedan set se odnosi na vreme do i uključuje 19.
- Page 17 UA: Декларація відповідності директивам EC/EU Ми, компанія Grundfos, під нашу одноосібну відповідальність заявляємо, що виріб Grundfos MI401, ALPHA Reader, до якого відноситься нижченаведена декларація, відповідає директивам EC/EU, переліченим нижче, щодо тотожності законів країн-членів ЄС. Примітка: Існує два комплекти директив та стандартів EC/EU, перелічених нижче.
- Page 18 Phone: Telefax: +54-3327 411 111 Telefax: +86-021-612 253 33 +852-27861706/27861741 Telefax: +852-27858664 Australia Croatia Hungary GRUNDFOS Pumps Pty. Ltd. GRUNDFOS CROATIA Phone: +61-8-8461-4611 d.o.o. GRUNDFOS Hungária Kft. Telefax: +61-8-8340 0155 Phone: +385 1 6595 400 Phone: +36-23 511 110 Telefax: +385 1 6595 499...
- Page 19 Phone: +44-1525-850000 Telefax: +31-88-478 6332 s Telefax: +386 (0) 1 568 06 Telefax: +44-1525-850011 New Zealand U.S.A. South Africa GRUNDFOS Pumps NZ Ltd. GRUNDFOS Pumps Phone: +64-9-415 3240 GRUNDFOS (PTY) LTD Corporation Telefax: +64-9-415 3250 Phone: (+27) 11 579 4800...
- Page 20 98936810 0216 ECM: 1175074 www.grundfos.com www.grundfos.com...
