- Page 1 ELL10(K) Linear Translation Stage Operating Manual Original Instructions...
-
Page 3: Table Of Contents
Chapter 5 Troubleshooting and FAQ ............................. 12 Chapter 6 Specifications ................................. 13 Chapter 7 Regulatory ................................15 Declarations of Conformity ......................... 15 7.1.1 For Customers in Europe ........................15 7.1.2 For Customers In The USA ....................... 15 Chapter 8 Thorlabs Worldwide Contacts ..........................16... -
Page 5: Chapter 1 Introduction
Introduction The ELL10 Linear Translation Stage is part of the Thorlabs series of resonant piezo motor circuits and bare modules for OEM applications. The resonant piezo design of these motors offers fast response times and precise positioning, and therefore they are particularly useful in scanning applications. -
Page 6: Chapter 2 Safety
ELL10 Linear Stage Evaluation Kit Chapter 2: Safety Chapter 2 Safety For the continuing safety of the operators of this equipment, and the protection of the equipment itself, the operator should take note of the Warnings, Cautions and Notes throughout this handbook and, where visible, on the product itself. Warning: Risk of Electrical Shock Given when there is a risk of electrical shock. -
Page 7: Chapter 3 Installation
ELL10 Linear Stage Evaluation Kit Chapter 3: Installation Chapter 3 Installation Environmental Conditions Warning Operation outside the following environmental limits may adversely affect operator safety. Location Indoor use only Maximum altitude 2000 m Temperature range 15°C to 40°C Maximum Humidity Less than 80% RH (non-condensing) at 31°C To ensure reliable operation the unit should not be exposed to corrosive agents or excessive moisture, heat or dust. -
Page 8: Mounting
ELL10 Linear Stage Evaluation Kit Chapter 3: Installation Mounting Warning The safety of any system incorporating this equipment is the responsibility of the person performing the installation. Cautions Although the module can tolerate up to 8kV of air discharge, it must be treated as an ESD sensitive device. When handling the device, anti-static precautions must be taken and suitable discharge appliances must be worn. - Page 9 ELL10 Linear Stage Evaluation Kit Chapter 3: Installation Figure 2 ELL10 with MMP1 top plate fitted, showing stage in backwards/home position Figure 3 Fixing the ELL10 to the work surface 1. Slide the moving world to one end of travel to gain access to the mounting holes as shown above. 2.
-
Page 10: Chapter 4 Operation
ELL10 Linear Stage Evaluation Kit Chapter 4: Operation Chapter 4 Operation Getting Started Caution Although the module can tolerate up to 8kV of air discharge, it must be treated as an ESD sensitive device. When handling the device, anti-static precautions must be taken and suitable and discharge appliances must be worn. Do not expose the Stage to magnetic fields as this could affect the positioning and homing sensor operation. -
Page 11: Controlling The Stage
ELL10 Linear Stage Evaluation Kit Chapter 4: Operation Controlling the Stage The stage can be controlled in three ways; via the handset, by the Elliptec software running on a PC, or by writing a custom application using the messages described in the communications protocol document. Homing and Jogging functionality can also be accessed by applying voltages to the digital lines on Connector J1. -
Page 12: Software Control
4.2.2 Software Control When connected to the host PC, the stage can be controlled remotely, via the Elliptec software. 1. Download the Elliptec software from the Downloads section at www.thorlabs.com. Double click the saved .exe file and follow the on-screen instructions. -
Page 13: Communications Protocol
ELL10 Linear Stage Evaluation Kit Chapter 4: Operation 4.2.3 Communications Protocol Custom move applications can be written in languages such as C# and C++. The communication bus allows multi-drop communication with speeds at 9600 baud, 8 bit data length, 1 stop bit, no parity. Protocol data is sent in ASCII HEX format, while module addresses and commands are mnemonic character (no package length is sent). - Page 14 ELL10 Linear Stage Evaluation Kit Chapter 4: Operation Connector J1 Pin Out TYPE FUNCTION Ground ODTX - open drain transmit 3.3V TTL RS232 RX receive - 3.3V TTL RS232 In Motion, open drain active low max 5mA JOG/Mode, active low max 5V BW Backward , active low max 5V FW Forward, active low max 5V VCC +5V +/-10% 850mA...
-
Page 15: Frequency Search
ELL10 Linear Stage Evaluation Kit Chapter 4: Operation Frequency Search Due to load, build tolerances and other mechanical variances, the default resonating frequency of a particular motor may not be that which delivers best performance. A frequency search can be performed using the Main GUI panel in the ELLO software, or by using the serial communication line (SEARCHFREQ_MOTORX message), which offers a way to optimize the operating frequencies for backward and forward movement. -
Page 16: Chapter 5 Troubleshooting And Faq
ELL10 Linear Stage Evaluation Kit Chapter 5: Troubleshooting and FAQ Chapter 5 Troubleshooting and FAQ Stage is moving back and forth after power up If the digital line “bw” is driven low before powering up the stage, the module will go into calibration mode. Remove power to exit calibration mode. -
Page 17: Chapter 6 Specifications
ELL10 Linear Stage Evaluation Kit Chapter 6: Specifications Chapter 6 Specifications Parameter Value Performance 60.0 mm (2.36”) Travel 50 µm Homing/Positioning accuracy ±20 µm Repeatability (with 100g load) 90 mm/s Max Velocity (No Load) 6.0 m/s/s Max Acceleration (No Load) Minimum Motor Holding Force (both motors engaged) 6.3 µm Vertical Straightness... - Page 18 ELL10 Linear Stage Evaluation Kit Chapter 6: Specifications Specifications Cont… Communications Multi-Drop 3.3 V/5 V TTL RS232 Picoflex® Connector on Linear Stage Board Picoflex® Connectors on Interface Board Micro-B USB 5 VDC Power: [For Plug with Ø5.5 mm OD (Ground) and Ø2.1 mm ID (+5 V)] 9600 baud Speed...
-
Page 19: Chapter 7 Regulatory
ELL10 Linear Stage Evaluation Kit Chapter 7: Regulatory Chapter 7 Regulatory Declarations of Conformity 7.1.1 For Customers in Europe 7.1.2 For Customers In The USA This equipment has been tested and found to comply with the limits for a Class A digital device, persuant to part 15 of the FCC rules. -
Page 20: Chapter 8 Thorlabs Worldwide Contacts
Contact Thorlabs for more information. Waste treatment is your own responsibility. “End of life” units must be returned to Thorlabs or handed to a company specializing in waste recovery. Do not dispose of the unit in a litter bin or at a public waste disposal site. - Page 22 www.thorlabs.com...
