5
SUPPLEMENT
E.

Spindle speed attainment check

1. Command
Programming format
Function
4.

M-code (Clamp)

A.

B-axis clamping/unclamp

1. Command
Programming format
Function
B.

Turning spindle C-axis clamping/unclamping

1. Command
Programming format
Function
C. Turning spindle chuck open/close
1. Command
Programming format
Function
Serial No. 294060
M250
Confirms whether the specified spindle speed has been attained.
M107 B-axis clamping
M108 B-axis unclamping
This function code activates the clamping mechanism of the B-axis. (M107)
This function code deactivates the clamping mechanism of the B-axis. (M108)
M210 Turning spindle 1 C-axis clamping
M211 Turning spindle 1 C-axis braking
M212 Turning spindle 1 C-axis unclamping
M310 Turning spindle 2 C-axis clamping
M311
Turning spindle 2 C-axis braking
M312
Turning spindle 2 C-axis unclamping
This function code activates the C-axis clamping mechanism to clamp the C-axis when the
turning spindle No. 1 is connected to the C-axis. (M210)
This function code activates the C-axis braking mechanism to brake the C-axis when the
turning spindle No. 1 is connected to the C-axis. (M211)
This function code deactivates the C-axis clamping mechanism and braking mechanism
when the turning spindle No. 1 is connected to the C-axis. (M212)
This function code activates the C-axis clamping mechanism to clamp the C-axis when the
turning spindle No. 2 is connected to the C-axis. (M310)
This function code activates the C-axis braking mechanism to brake the C-axis when the
turning spindle No. 2 is connected to the C-axis. (M311)
This function code deactivates the C-axis clamping mechanism and braking mechanism
when the turning spindle No. 2 is connected to the C-axis. (M312)
M206 Turning spindle 1 Chuck open
M207
Turning spindle 1 Chuck close
M306 Turning spindle 2 Chuck open
M307 Turning spindle 2 Chuck close
This function code opens the chuck of the turning spindle No. 1. (M206)
This function code closes the chuck of the turning spindle No. 1. (M207)
This function code opens the chuck of the turning spindle No. 2. (M306)
This function code closes the chuck of the turning spindle No. 2. (M307)
5-72
