PROTECT
Projector Enclosure:
• PROTECT Slim
• PROTECT 54-80
• PROTECT 72-116
LIST OF ITEMS::
Projector Enclosure
adjustable arm with mount
mounting set
installation manual
installation template
1. Installation:
A. Prepare an installation place and mark mounting
points using installation template as below:
C. Remove element B from guide C from projector
enclosure.
B. Install element A to the ceiling. Use the selected
pins and screws from the assembly kit.
D. Install projector on projector mount B.
Warning! To connect the mount with the projector, select
the appropriate screws from the mounting kit according to
the recommendations of the projector manufacturer.
1/2
Advertisement
Related Manuals for Viz-Art Automation PROTECT Series
Summary of Contents for Viz-Art Automation PROTECT Series
- Page 1 PROTECT Projector Enclosure: • PROTECT Slim • PROTECT 54-80 • PROTECT 72-116 LIST OF ITEMS:: Projector Enclosure adjustable arm with mount mounting set installation manual installation template 1. Installation: A. Prepare an installation place and mark mounting B.
- Page 2 M6x20 – 4 pcs.; M8x20 – 4 pcs.; washers: ø4x9 – 4 pcs.; ø5x10 – 4 pcs.; ø6x12 – 4 pcs.; ø8x16 – 4 pcs.; ø8x40 – 4 pcs. dowels screws: ø5x40 z flat head – 4 pcs. manufactured: VIZ-ART Automation tel.+48 22/6138899 www.viz-art.pl...
