- Page 1 J5250 Trike Bike www.fisher-price.com...
-
Page 2: Warnings And Caution
Warnings and Caution Important Safety Information • Please use this product with caution, as it requires skill to operate WARNING safely to avoid falls, collisions, and injuries to yourself and others. • This product is intended for outdoor use on smooth, paved surfaces. To avoid serious injury: •... - Page 3 Parts Lower Steering Stop 2 Retainers Frame Upper Steering Stop 2 Wheel Bushings Handlebar Front Axle Fork • Please save all packaging material until assembly is complete to ensure that no parts are discarded. • Please wipe each part with a clean, dry cloth before assembly. 2 Rear Wheels #8 x ”...
- Page 4 Assembly Screws Gear Press Press • Locate the four screws on each rear wheel. These screws should Rear Axle Release Levers face out when assembling the rear wheels to the frame. • Make sure the gear in the center of each rear wheel is flush with the outside surface of the rear wheel.
- Page 5 Assembly Wheel Bushings Grooves Front Wheel Rear Wheel Assembly • Fit a wheel bushing into the center hole in each side of the • Lift and “snap” the rear wheel assembly into the grooves in the front wheel. back end of the frame. •...
- Page 6 Assembly Front Axle Front Wheel Retainers • Slide the front axle through the center hole in the front wheel. • Fit the retainers over the ends of the front axle and onto the fork. • Insert two #8 x ” screws into each retainer and tighten. Fork Grooves Cap Nut Front Axle...
- Page 7 Assembly Upper Steering Stop Frame Neck • Fit the upper steering stop to the top of the frame neck. Frame Neck • Position the fork so that the tab faces forward. • Fit the fork up through the hole in the frame neck. Handlebar Lower Steering Stop Fork...
- Page 8 Assembly Handlebar Cover #8 x ” Screw Seat Stem #8 x ” Screw #8 x 2 ” Screw • Fit the seat stem into the large hole in the top of the frame. • Fit the handlebar cover to the back of the fork and the handlebar. •...
- Page 9 Convert to Bike Rear Axle Release Levers Rear Axle Assembly • Press the rear axle release levers on the back end of the frame. • Lower the rear axle assembly.
- Page 10 Convert to Bike Grooves Rear Wheels Gear • Push the rear wheels together. • Lift the rear wheels until the gears on the outside of rear wheels “snap” into the grooves in the frame. • Check to be sure the rear wheels are secure, by pulling down on them.
- Page 11 Convert to Trike Rear Axle Release Levers Rear Axle Assembly • Press the rear axle release levers on the back end of the frame. • Lower the rear axle assembly.
- Page 12 Convert to Trike Grooves Rear Wheels Gears • Slide the rear wheels out. • Lift the rear wheels until the gears on the inside of the rear wheels “snap” into the grooves in the frame. • Check to be sure the rear wheels are secure, by pulling down on them.
