- Page 1 QUICK REFERENCE GUIDE LED LCD TV Please read this manual carefully before operating your set and retain it for future reference. 32LS341C 42LS349C 42LS341C www.lg.com P/NO : MFL67415430 (1211-REV00)
-
Page 2: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS IMPORTANT SAFETY INSTRUCTIONS Always comply with the following precautions to avoid dangerous situations and ensure peak performance of your product. Read these instructions. Keep these instructions. WARNING/CAUTION Heed all warnings. Follow all instructions. RISK OF ELECTRIC SHOCK DO NOT OPEN Do not use this apparatus near water. - Page 3 IMPORTANT SAFETY INSTRUCTIONS Protect the power cord from being walked on Keep the packing anti-moisture material or or pinched particularly at plugs, convenience vinyl packing out of the reach of children. receptacles, and the point where they exit Anti-moisture material is harmful if from the apparatus.
- Page 4 Make sure the product is turned off, Do not attempt to modify this product in any unplugged and all cables have been way without written authorization from LG removed. It may take 2 or more people to Electronics. Unauthorized modification could carry larger TVs.
- Page 5 IMPORTANT SAFETY INSTRUCTIONS If you smell smoke or other odors coming If the TV feels cold to the touch, there may from the TV, unplug the power cord and be a small “flicker” when it is turned on. This contact an authorized service center. is normal, there is nothing wrong with TV.
-
Page 6: Licenses
In addition to the source code, all referred license terms, warranty disclaimers and copyright notices are available for download. LG Electronics will also provide open source code to you on CD-ROM for a charge covering the cost of performing such distribution (such as the cost of media, shipping and handling) upon email request to opensource@lge.com. -
Page 7: Table Of Contents
TABLE OF CONTENTS TABLE OF CONTENTS IMPORTANT SAFETY INSTRUCTIONS LICENSES OPEN SOURCE SOFTWARE NOTICE TABLE OF CONTENTS INSTALLATION PROCEDURE ASSEMBLING AND PREPARING Unpacking Parts and buttons Lifting and moving the TV Setting up the TV - Attaching the stand - Mounting on a table - Mounting on a wall - Tidying cables MAKING CONNECTIONS... -
Page 8: Installation Procedure
INSTALLATION PROCEDURE / ASSEMBLING AND PREPARING INSTALLATION PROCEDURE Open the package and make sure all the accessories are included. Attach the stand to the TV set. Connect an external device to the TV set. ASSEMBLING AND PREPARING Unpacking Check your product box for the following items. If there are any missing accessories, contact the local dealer where you purchased your product. - Page 9 ASSEMBLING AND PREPARING For LS341C series Quick Reference Guide Power Cord Remote Control, Batteries (AAA) (See p.26) (For 32LS341C) (For 42LS341C) Stand Body / Stand Base Stand Body / Stand Base Desk-Mount Screw (See p.14) (See p.15) (See p.18) (For 32LS341C)
- Page 10 ASSEMBLING AND PREPARING For LS349C series Quick Reference Guide Power Cord Remote Control, Batteries (AAA) (See p.26) Stand Body Stand Base Stand Screws (See p.16) (See p.16) 8 EA, M4 x 20 (See p.16) Protection Cover Desk-Mount Screw (See p.17) (See p.18)
-
Page 11: Parts And Buttons
ASSEMBLING AND PREPARING Parts and buttons For LS341C series Side Connection Panel Screen Buttons USB Input SETTINGS INPUT Speakers Remote Control and Intelligent Sensors AV IN ANTENNA CABLE VIDEO L/MONO AUDIO Power Indicator VIDEO AUDIO COMPONENT IN Rear Connection Panel Buttons Description ꔰ... - Page 12 ASSEMBLING AND PREPARING For LS349C series Side Connection Panel Screen USB Input Remote Control Intelligent Sensors Power Indicator Speakers AV IN CABLE ANTENNA VIDEO L/MONO AUDIO SETTINGS INPUT VIDEO AUDIO COMPONENT IN Touch Buttons Rear Connection Panel Touch Button Description ꔰ...
-
Page 13: Lifting And Moving The Tv
ASSEMBLING AND PREPARING Lifting and moving the TV When moving or lifting the TV, read the following When transporting a large TV, there should to prevent the TV from being scratched or be at least 2 people. damaged and for safe transportation regardless of When transporting the TV by hand, hold the its type and size. -
Page 14: Setting Up The Tv
Put your TV on a pedestal stand and mount the TV on a table or wall. Attaching the stand If you are not mounting the TV to a wall, use the following instructions to attach the stand. For 32LS341C 2 EA P4 x 16... - Page 15 ASSEMBLING AND PREPARING For 42LS341C 4 EA P4 x 16 Stand Body Stand Base CAUTION When attaching the stand to the TV set, place the screen facing down on a cushioned table or flat surface to protect the screen from scratches. 4 EA M4 x 14 CAUTION...
- Page 16 ASSEMBLING AND PREPARING For LS349C series 4 EA M4 x 20 Stand Body Front CAUTION Stand Base When attaching the stand to the TV set, place the screen facing down on a cushioned table or flat surface to protect the screen from scratches. 4 EA M4 x 20 CAUTION...
- Page 17 When installing the wall mounting bracket, use the Protection cover. NOTE (For 32LS341C) When removing the Protection Cover from bottom of TV, insert your fingers into hole of cover. Hold firmly and pull upwards towards you to remove.
-
Page 18: Mounting On A Table
ASSEMBLING AND PREPARING Mounting on a table Securing the TV to a table Fix the TV to a table to prevent from tilting Lift and tilt the TV into its upright position on a forward, damage, and potential injury. table. To secure the TV to a table, insert and tighten the supplied screw on the rear of the stand. -
Page 19: Mounting On A Wall
If you install the TV on a ceiling or slanted wall, it may fall and result in severe injury. We recommend that you use an LG brand wall Use an authorized LG wall mount and mount when mounting the TV to a wall. -
Page 20: Tidying Cables
ASSEMBLING AND PREPARING Tidying cables Securing the TV to a wall (optional) (Depending on model) For LS341C series Gather and bind the cables with the cable holder. Insert and tighten the eye-bolts, or TV brackets and bolts on the back of the TV. Cable Holder - If there are bolts inserted at the eye-bolts position, remove the bolts first. -
Page 21: Making Connections
MAKING CONNECTIONS MAKING CONNECTIONS You can connect various external devices to the TV. Supported external devices are: HD receivers, DVD players, VCRs, audio systems, USB storage devices, PC, gaming devices, and other external devices. For more information on external device’s connection, refer to the manual provided with each device. NOTE If you record a TV program on a DVD recorder or VCR, make sure to connect the TV signal input cable to the TV through a DVD recorder or VCR. -
Page 22: Connecting To A Hd Receiver, Dvd Player Or Vcr Player
MAKING CONNECTIONS Connecting to a HD receiver, DVD player or VCR player Connect a HD receiver, DVD Player or VCR to the TV and select an appropriate input mode. HDMI Connection HDMI is the best way to connect a device. Transmits digital video and audio signals from an external device to the TV. -
Page 23: Component Connection
MAKING CONNECTIONS Component Connection Transmits the analog video and audio signals from an external device to the TV. Connect the external device and the TV with the component cable as shown in the following illustration. NOTE If cables are installed incorrectly, it could cause the image to display in black and white or with distorted color. -
Page 24: Composite Connection
MAKING CONNECTIONS Composite Connection Transmits the analog video and audio signals from an external device to the TV. Connect the external device and the TV with the composite cable as shown in the following illustration. NOTE If you have a mono VCR, connect the audio cable from the VCR to the AUDIO L/MONO jack of the TV. AV IN AV IN VIDEO... -
Page 25: Connecting To A Pc
MAKING CONNECTIONS Connecting to a PC NOTE It is recommended to use an HDMI connection for the best image quality. Depending on the graphics card, DOS mode may not work if a HDMI to DVI Cable is in use. In PC mode, there may be noise associated with the resolution, vertical pattern, contrast or brightness. -
Page 26: Remote Control
REMOTE CONTROL REMOTE CONTROL The descriptions in this manual are based on the buttons on the remote control. Please read this manual carefully and use the TV correctly. To install batteries, open the battery cover, insert batteries (1.5 V AAA) matching ends to the label inside the compartment, and close the battery cover. - Page 27 REMOTE CONTROL SETTINGS POWER ENERGY Accesses the main menu. Q. MENU SAVING Accesses the quick menu. GUIDE INFO RATIO INPUT Navigation buttons (up/down/left/right) Scrolls through menus or options. OK ꔉ Selects menus or options and confirms your input. ꕣ (BACK) Returns to the previous level.
-
Page 28: Specifications
Temperature Operating Humidity Less than 80% Storage Temperature -20 - 60°C Storage Humidity Less than 85% 32LS341C 42LS341C MODELS (32LS341C-SA) (42LS341C-SA) With stand 738.0 mm x 501.0 mm x 185.0 mm 972.0 mm x 635.0 mm x 212.0 mm... - Page 29 SPECIFICATIONS HDMI (PC) supported mode Component port connecting information Horizontal Vertical Component ports on the Resolution Frequency (KHz) Frequency (Hz) 640x350 31.468 70.09 720x400 31.469 70.08 640x480 31.469 59.94 Video output ports on DVD player 800x600 37.879 60.31 1024x768 48.363 60.00 1152x864 54.348...
-
Page 30: General Troubleshooting
GENERAL TROUBLESHOOTING GENERAL TROUBLESHOOTING Installation Symptom Possible Cause(s) Possible Solution(s) Cannot direct enter (TV in Pass-through Mode) Installer If the channel lineup is locked, only channels channel number. Menu item 028 CH. OVERIDE is set that are active in the TV’s channel lineup can to 0, i.e., disabled (recommended be selected. - Page 31 Check that “+” and “-” match in battery compartment. Too much light in room. Dim room light. Wrong Installer Remote. Requires compatible Installer Remote. Contact your LG dealer. Bed Switch set to wrong bed. Set Bed Switch or update Installer Menu, as necessary.
- Page 32 The model and serial numbers of the TV are located on the back and/or one side of the TV. Record them below should you ever need service. MODEL SERIAL...
