  • Page 1 SL STRIP 10IP LED LUMINAIRE...
  • Page 2 Document Number: SL STRIP 10IP LED Luminaires User Manual Version as of : 17th Sep 2015 SL STRIP 10IP User’s Manual 2015 Vari-Lite.

  • Page 3: Warnings And Notices

    Showline Limited Two-Year Warranty Showline offers a two-year limited warranty of its luminaires against defects in materials or workmanship from the date of delivery. A copy of Showline two-year limited warranty containing specific terms and conditions can be obtained by contacting your local Showline office.

  • Page 4: About This Manual

    Note: The SL STRIP 10 IP LED Luminaire is universal voltage 100 to 240 VAC (auto-ranging). Included Items QuickStart Guide SL STRIP 10IP LED Luminaire Diffuser Lens Kit* *Note: Diffusers with 3 different beam angles for options: 15 degree, 25 degree...

  • Page 5: Main Features

    INSTALLATION SL STRIP 10IP LED Luminaires are provided with Trunnion Arms. The user can tighten the wing screws manually. For hanging applications it is recommended (and may be required by local and national safety codes) to use and install a safety cable (sold separately).

  • Page 6: Power Requirements

    D i r e c t connection to an AC power source using an AC input cable. For wiring of AC input connector, refer to LED Luminaires to AC Power C o n n e ction from the AC output of another SL STRIP 10IP LED Luminaire. When using this method, it is very important not to connect any other type of equipment.

  • Page 7: Layout Overview

    The luminaire is equipped with an IP rated connector and an AC Input cable is provided. Rear Panel Overview POWER INPUT CAUTION / ATTENTION: SL STRIP 10IP (15A Max.) POWER INPUT(输⼊电压): 110-240V~, 50/60Hz; RISK OF ELECTRIC SHOCK DO NOT OPEN POWER CONSUMPTION(功耗): 150W Max.

  • Page 8: Operation Modes

    SL STRIP 10 IP LED Luminaires Installation and User's Manual OPERATION MODES The SL STRIP 10IP LED Luminaire has three different operation modes. Please follow illustrations below to operate the unit in your desired mode. Function Parameter Parameter Value Mode...
  • Page 9 SL STRIP 10 IP LED Luminaires Installation and User's Manual SL STRIP 10IP DMX Mapping (RGBW 16 Bit Mode) SL STRIP 10IP DMX Mapping (RGBW 8 Bit Mode) Red_1-10 Green_1-10 Blue_1-10 White_1-10 OPERATION MODES...

  • Page 10: Chase Mode

    SL STRIP 10 IP LED Luminaires Installation and User's Manual 1. Setting the DMX Address Press the “MODE’ button to select and activate the “DMX” menu. Set the DMX address, DMX Bit, DMX Fade and DMX Channel. Press the “MENU” button to select and enter the desired menu. DMX Addr Addr:512 MODE...

  • Page 11: Manual Mode

    SL STRIP 10 IP LED Luminaires Installation and User's Manual Chase Speed Menu: Press the “MENU’ button to select the “Chase Speed” menu. Chase Speed:01 In this menu, you can adjust the program chase speed. MODE DOWN MENU Press the "UP " and "DOWN" buttons to adjust the chase speed from 01 to 99.

  • Page 12: Rdm Parameter Ids

    SL STRIP 10 IP LED Luminaires Installation and User's Manual SL STRIP 10IP RDM Parameter IDs The following tables outline and describe all the RDM parameters IDs associated with SL STRIP 10IP. Table 1: SL STRIP 10IP RDM Parameter IDs SL STRIP 10IP...
  • Page 13 SL STRIP 10 IP LED Luminaires Installation and User's Manual Table 1: SL STRIP 10IP RDM Parameter IDs RDM PARAMETER IDS...
  • Page 14 SL STRIP 10 IP LED Luminaires Installation and User's Manual Table 2: SL STRIP 10IP Manufacturer Status IDs Manufacturer Defined Status IDs Manufacturer Specific messages are in the range of 0x8000 —0xFFDF. Each Manufacturer-specific Status ID shall have a unique meaning, which shall be consistent across all products having a given Manufacturer ID. See Table B-2, ANSI E1.20-2010...

  • Page 15: Technical Specifications

    SL STRIP 10 IP LED Luminaires Installation and User's Manual TECHNICAL SPECIFICATIONS 1. Operational Specifications 10 homogenized 4-in-1 RGBW LED Arrays Source: Beam Angle: 6 degree native beam angle. 15, 25 or 11 x 38 degree diffuser lens 2240 lumens Light Output: Color Temerature: 2700 - 6500K (user adjustable)
  • Page 16 SL STRIP 10 IP LED Luminaires Installation and User's Manual...
  • Page 17 Dallas 10911 Petal Street Dalls, TX 75238 Tel: +1 214-647-7880 Fax: +1214-647-8031 Asia Unit C, 14/F, Roxy Industrial Centre No. 41-49 Kwai Cheong Road Kwai Chung, N.T., Hong Kong Tel: +852 2796 9786 Fax: +852 2798 6545 Auckland 19-21 Kawana Street Northcote, Auckland 0627 New Zealand Tel: +64 9 481 0100...
