This step-by-step guide walks you through how to completely disassemble your new HTC One (M8) smartphone.
Following the detailed instructions we have provided will help you safely replace, or repair, not only a broken
M8 display assembly (LCD and touch screen), but also any other internal components (i.e. rear-facing camera,
lightning connector and headphone jack assembly, power button cable, etc.) that may have become damaged.
You can find a full archive of fixez.com disassemble guides and HD repair videos, for numerous makes and
models of smartphones and tablets, by visiting http://www.fixez.com.
http://www.fixez.com/
HTC One (M8)
DISASSEMBLE GUIDE

Recommended Tools

•
5-0007 Plastic Triangle Opening Tool
•
5-0013 T5 Torx Screwdriver
•
5-0016 Small Phillips Screwdriver
•
5-0022 Nylon Spudger
•
5-1342 SIM Card Ejection Tool
•
5-1370 Fine Tip Curved Tweezers
•
5-1387 Precision Knife Set
•
5-1665 Multi-Purpose Heat Gun
Page 1 of 10

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the One M8 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for HTC One M8

Summary of Contents for HTC One M8

  • Page 1: Recommended Tools

    • 5-1665 Multi-Purpose Heat Gun This step-by-step guide walks you through how to completely disassemble your new HTC One (M8) smartphone. Following the detailed instructions we have provided will help you safely replace, or repair, not only a broken M8 display assembly (LCD and touch screen), but also any other internal components (i.e. rear-facing camera, lightning connector and headphone jack assembly, power button cable, etc.) that may have become damaged.

  • Page 2: Rear Cover

    This will make it easier to remove the grills from the Insert the sharp edge of the precision knife in the gap between the HTC One (M8) display assembly and the first (top) grill. Use the precision knife to carefully lift the grill from its adhesive.
  • Page 3 HTC One (M8) – Disassemble Guide Next, locate and remove the four torx screws (T5) on the other side of the M8 that also secure the display assembly to the body/housing of the smartphone (marked with orange circles). Insert the precision knife between the rear cover and the M8’s display assembly to free the first of many clips...
  • Page 4 HTC One (M8) – Disassemble Guide Motherboard First, locate and remove the two small Phillips screws (#00) that secure the connection for the battery terminal (marked with solid orange circles). Next, locate and remove the two coaxial cable connec- tions that are also secured to the motherboard (marked with open orange circles).
  • Page 5 HTC One (M8) – Disassemble Guide You can now lift the motherboard up and out of the HTC One (M8). Be careful when maneuvering it through the cables and tape so that no damage occurs. Next, remove the remainder of tape that is protecting the ribbon cables on the smartphone.
  • Page 6 Pull its small plug from the locking socket. Next, use the fine tip curved tweezers to remove the vibrator from its housing and lift it out of the HTC One (M8). The wafer connection for the front-facing camera is slightly covered by a plastic cover.

  • Page 7: Front-Facing Camera

    HTC One (M8) – Disassemble Guide Now, locate and remove the four small Phillips screws (#00) that secure the daughterboard to the back of the display assembly. Next, release the ribbon cables in the two locking sockets that are located on either side of the daughter- board (marked with orange rectangles).

  • Page 8: Rear-Facing Camera

    The loudspeaker is also held in place with adhesive. Use a small amount of heat to soften the adhesive, if necessary. Then use the fine tip curved tweezers to lift the loudspeaker up and out of the HTC One (M8). Page 8 of 10 http://www.fixez.com/...
  • Page 9 Then use the fine tip curved tweezers to lift the micro-usb dock port and headphone jack assembly up and out of the HTC One (M8) smartphone. Battery The battery is held in place with two strips of heavy-duty adhesive.
  • Page 10 HTC One (M8) – Disassemble Guide Breakdown 1. HTC One (M8) Display Assembly (LCD and Touch Screen) 2. HTC One (M8) Rear Battery Cover 3. HTC One (M8) Display Assembly Grills 4. HTC One (M8) Motherboard 5. HTC One (M8) Battery 6.
