Page 3
PARTS - PIÈCES Left vertical molding Right vertical molding Moulure droite Moulure gauche #35706012060 Bottom #35706012050 Fond Left panel Panneau supérieur Right panel #35706012040 Panneau gauche #35706012030 Panneau droit #35706012010 #35706012020 Horizontal molding Left drawer side Right drawer side Drawer back Drawer front Côté...
Page 4
PARTS - PIÈCES #A12100 #A11080 #A22500 #A53840 7/16" pan head Angle bracket Tête ronde 7/16 po 7/16" flat head Cam lock #A22510 Tête plate 7/16 po Équerre Serrure de came Cam bolt #A11600 Boulon de came 1 1/4" flat head Tête plate 1 1/4 po #A54220 Drawer bracket...
Page 5
This illustration shows how the cam fastening system works. Ces illustrations montrent le fonctionnement du dispositif de fixation par came. REMINDER: Do not use power tools to assemble your furniture. To prevent stripping of holes, do not overtighten the screws during the assembly. Tighten to fully seat.
Page 6
the metal slide will protrude at the front of the panel proper orientation of cam lock la glissière va dépasser au devant bonne orientation de la serrure de came du panneau lightly tap the connector into the hole with a hammer tapez le connecteur légèrement dans le trou avec un marteau 13 a B345706012CTCP 1...
Page 7
the metal slide will protrude at the front of the panel la glissière va dépasser au devant du panneau proper orientation of cam lock bonne orientation de la serrure de came lightly tap the connector into the hole with a hammer tapez le connecteur légèrement dans le trou avec un marteau B345706012CTCP 1 7 /16...
Page 8
Molding (G) can be adjusted up and down by loosening this Screw (4) La Moulure (G) peut être ajustée vers le haut et le bas en déserrant cette Vis (4) Molding (G) must slightly surpass the finished surface of the Bottom (D) la Moulure (G) doit dépasser la surface finie du Fond (D) proper orientation of cam lock...
Page 9
Finished edges are facing upwards Les bords finis font face vers le haut LOCK SERRER B345706012CTCP 1 9 /16...
Page 10
Turn the connector screw clockwise to lock in place. Tournez la vis du connecteur vers la droite pour verrouiller en place. B345706012CTCP 1 10 /16...
Page 11
WARNING Please make sure that the back panel is attached securely. All nails must be driven into the parts straight. Failure to do so could cause instability, product collapse, and/or serious injury. AVERTISSEMENT raw surface Veuillez vous assurer que le panneau arrière est solidement fixé. Tous les clous doivent être enfoncés perpendiculairement.
Page 12
Lay the drawer sides down on a flat hard surface. Carefully line up the drawer bracket with the holes in the drawer side as shown. Using a hammer, tap each drawer bracket stem part way into each hole. Repeat this process until the drawer bracket is fully seated on the drawer side.
Page 13
finished edge bord fini B345706012CTCP 1 13 /16...
Page 14
raw surface surface non finie finished surface surface finie B345706012CTCP 1 14 /16...
Page 16
MAXIMUM LOADS roller CHARGES MAXIMALES cabinet member rouleau glissière du cabinet This unit has been designed to support the maximum loads shown. Exceeding these load limits could cause sagging, instability, product collapse, and/or serious injury. drawer runner coulisse du tiroir roller Ce meuble a été...
