Summary of Contents for Galaxy EPABX 104
-
Page 3: Table Of Contents
USER & PROGRAMMING MANUAL Sl.No. Features ..............Page No. Specifications ..............2-3 Internal Call ................4 Internal CLI ................4 Auto Call Back on Busy ............4 Call Pickup ................4 Barge In .................. 4 Call Forward ................4 Do Not Disturb ............... 5 O’Dialing ................. -
Page 4: Specifications
System Tones & Rings System Tones & Rings System Tones & Rings System Tones & Rings System Tones & Rings System Tones & Rings 1. Dial Tone (400 Hz Monotone) 2. Busy Tone (400 Hz Monotone) 640 msec 640 msec 7.5 sec 3. - Page 5 7. Intercom Ring 128 msec 128 msec 8. Trunk Ring 300 msec 300 msec 350 msec 1.6 sec 9. Urgent Ring 640 msec 640 msec 10. Intercom RBT (400 Hz + 440 Hz Dual Tone) 1.28 sec 1.28 sec 11. Trunk RBT (400 Hz + 440 Hz Dual Tone) 300 msec 300 msec 350 msec...
-
Page 6: Internal Call
01 INTERNAL CALL Lift the handset you will hear the Internal dial tone Dial the desired Extn No. The called Extn Rings Speech is established when the called party lift the handset If called Extn busy, then use Auto Call back on Busy feature described in the manual 02 INTERNAL CLI In this feature the calling Extn No. -
Page 7: Do Not Disturb
07 DO NOT DISTURB If an Extn does not want to be called, this feature allows the Extn to protect from being called. But the Extn user can call others Lift the handset an dail 1* + PPW + 31 To Cancel 1* + PPW + 30 08 O’... -
Page 8: Call Queue
10 CALL QUEUE Dial ‘O’ to make an external call, if you find the CO line is busy, then dial 7 over busy tone If your request is accepted, you get confirmation tone and replace the handset By using this feature as soon as the CO line becomes free, your Extn will start ringing And as you lift the handset you will be connected to the CO line dial tone... -
Page 9: Call Conference
14 CALL CONFERENCE This unique feature allows to have a 3 party conference between 1 CO line and 2 Extns While in conversation with a CO line (incoming or outgoing) press flash to hold a existing CO call and dial the Extn number whom you want to invite for conference Wait for answer then press flash twice to establish a conference... -
Page 10: Simultaneous Ringing
18 SIMULTANEOUS RING In this mode all incoming call will ring Simultaneously on all Extns 19 AUTO CUT FOR LENGTHY CALLS This feature helps the customer to restrict the duration of the external calls It disconnects the external calls after 5minutes and can be set for each Extns 20 MUSIC ON HOLD You can hold a conversating party by the following feature for... -
Page 11: System Programming
SYSTEM PROGRAMMING (A) PROGRAMMING PASSWORD: Dial 1# + password (Initial Password is 6336). If password is right then confirmation tone else NU tone Now you can dial codes as given below (B) TO PROGRAM DEFAULT SETTINGS: (C) TO PROGRAM GLOBAL MEMORY DIALING: Location number (100 to 109) + Telephone Number + # (D) TO CHANGE SYSTEM PASSWORD: 2 + New Password + New Password (4 digit) -
Page 12: Quick References
QUICK REFERENCES External Call Call Transfer : Flash + Extn No. iii Redial : # # Call Queue Ring When Free Call Pickup vii Barge In : Dial 1 On busy tone viii Dynamic Local Lock : Enable 1* + *1 Disable 1* + Extn PW + *0 Dynamic STD Lock : Enable 1* + #1 Disable 1* + Extn PW + #0... - Page 13 WARRANTY Customer Name : _____________________________________ Organization : _____________________________________ Address : _____________________________________ _____________________________________ _____________________________________ Phone No. : _____________________________________ Mobile No. : _____________________________________ Email ID : _____________________________________ Model : _____________________________________ Configuration : _____________________________________ Sl. No. of the System: _____________________________________ Date of Installation : _____________________________________ Date of Purchase : _____________________________________ Invoice No.
