- Page 1 60CM CERAMIC COOKTOP SC-600AUECT INSTRUCTION MANUAL Please read this manual carefully before using, and keep it for future reference.
-
Page 3: Table Of Contents
CONTENTS General Safety Product Overview Installation Cleaning and Maintenance FAQs Specifications Customer Helpline... -
Page 4: General Safety
GENERAL SAFETY IMPORTANT INFORMATION Read this manual thoroughly before you start using the Ceramic Cooktop. The safety precautions instructions reduces the risk of fire, electric shock and injury when correctly complied to. Please follow all instructions and take notice of all warnings. WARNING! •... - Page 5 GENERAL SAFETY INSTRUCTIONS (Cont.) USAGE CONDITIONS AND RESTRICTIONS • Supervision over children is to ensure that they do not play with the appliance. Never allow them to use, play with or crawl inside the appliance. Cleaning and maintenance must not be done by children. •...
- Page 6 GENERAL SAFETY INSTRUCTIONS (Cont.) • Do not use any unstable or plastic cookware products or aluminium foil containers. No large cookware are to overlap bench as this can deflect heat back onto the cooktop and damage the surface. Cookware products can become hot while in use with this appliance.
-
Page 7: Product Overview
PRODUCT OVERVIEW Max. 1800W zone Max. 1200W zone Max. 1200W zone Glass Plate Max. 1800W zone Control Panel Heating Zone Selection On/Off Control Power Regulation Timer Control Keylock... -
Page 8: Installation
INSTALLATION Before installing your appliance, read all safety instructions in this manual, especially the sections on electrical safety and installation. UNPACKING • When unpacking the appliance, be sure to keep all the packaging materials until you have made sure your new appliance is undamaged and in good working order. - Page 9 INSTALLATION (Cont.) IMPORTANT ADVICE • The appliance must only ever be located and installed in a kitchen and not any other room. • Where you want to place the Cooktop, the wall and bench around the appliance must be able to sustain temperatures of 95˚C. Laminates, surface materials and fixing adhesives must be certified that it can sustain the tempertures.
- Page 10 INSTALLATION (Cont.) COOKTOP PREPERATION • Make sure there is plenty of ventilation and control elements are easily accessible. • The cooktop can be fitted to benchtops of 40-50mm • For rangehood installation above the appliance, check the rangehood instructions for required clearences before installation of the product. •...
- Page 11 INSTALLATION (Cont.) INSTALLING COOKTOP IN YOUR BENCH • Measurements for fitting and cutout of the appliance are as below. 1. 560 mm (width) 5. 50 mm 2. 490 mm (depth) 6. 50 mm 3. 50 mm 7. 50 mm (space underneath cooktop) 4.
- Page 12 INSTALLATION (Cont.) APPLYING SEAL The Ceramic Cooktop has a special seal which prevents liquid from infiltrating into the cabinet. Be sure to strictly follow these instructions in order to correctly apply this seal- ing tape before inserting the Cooktop into the benchtop. •...
- Page 13 INSTALLATION (Cont.) INSTALLAING AND MOUNTING THE COOKTOP Once you have installed the seal underneath the cooktop carefully turn it back to the right side up and lower it gently into the cutout in your benchtop. Press the side down gently so that the cooktop is resting firmly on the benchtop surface. •...
- Page 14 INSTALLATION (Cont.) WARNING! SURFACE TEMPERATUERS OF BASE EXCEED 95˚C, UNDER BENCH ACCESS MUST BE RESTRICTED BY USE OF NON-COMBUSTIBLE BARRIER ON INSTALLATION • The barrier must be >50mm from the base of the cooktop. • The barrier must leave a ventilation gap of 30-70mm but not greater than 70mm. ELECTRICAL CONNECTION •...
-
Page 15: Cleaning And Maintenance
OTHER USEFUL INFORMATION CLEANING AND MAINTENANCE CAUTION! • Before cleaning any part of the Cooktop, be sure to have all controls are switched off and the cooktop has called down sufficiently. • Make sure once all cooking zones are switched off that the cooktop surface is cool before you commence cleaning. -
Page 16: Faqs
FAQS If experiencing issues with your cooktop and isn’t operating correctly please check the following pages for solutions to the problems. If none of the solutions offered help solve the problem with your appliance then please contact our call centre on 1300 296 699. DO NOT ATTEMPT TO REPAIR THE APPLIANCE YOURSELF. -
Page 17: Specifications
SPECIFICATIONS Power Supply 220-240V ~ 50/60Hz Cooking Zones 4 Zones Installed Electric Power 6000W Product Size 590 (w) x 520 (d) x 55 (h) mm Cutout Dimensions 560 (w) x 490 (d) mm... -
Page 20: Customer Helpline
CUSTOMER HELPLINE: info@ayonz.com DISTRIBUTED BY: Ayonz Pty Ltd...
