Trident Installation: Preface
This guide will illustrate how to physically install the Trident.
The guide below will walk through the different steps illustrated on the Get
Started card included with your Neptune Systems Trident, but the
recommended method is to use the Trident Initial Setup task found in Apex
Fusion. The guide can also be used to supplement the Trident Initial Setup
Task and provide additional information for those looking for further details.
DO NOT CONNECT THE TRIDENT TO YOUR APEX
..
While this may seem counterintuitive, do not connect your Trident to the
Apex until instructed to do so. Connecting the Trident before other
necessary connections are made will cause the Trident to go into an error
mode and will cause the installation of the system to take additional time.
Update Apex AOS
.
On the Apex dashboard click the button with 3 gears, then click the WiFi
button. If there is not a large orange Update AOS button, then your Apex
already has the latest AOS version installed. If you see a large orange
Update AOS button, click that button and then click the Update button
The minimum required AOS version for the Apex is 5.05_5D19.
Advertisement
Table of Contents
Related Manuals for Neptune Systems Trident
Summary of Contents for Neptune Systems Trident
- Page 1 The guide below will walk through the different steps illustrated on the Get Started card included with your Neptune Systems Trident, but the recommended method is to use the Trident Initial Setup task found in Apex Fusion. The guide can also be used to supplement the Trident Initial Setup Task and provide additional information for those looking for further details.
- Page 2 Connect Black Sample Line Tubing It is suggested to make the initial connections to the Trident in an open space. The first connection that should be made is to connect the black sample line tubing to the black connector on the back of the Trident.
- Page 3 Install Reagent C Turn the Trident around so the front is accessible and open the reagent drawer. Find the reagent C bottle and give it a good shake. Place the bottle in the drawer and connect the reagent C intake assembly (green) to the bottle.
- Page 4 4. Avoid placing the sample line above the Trident. If the sample line becomes disconnected, then a gravity siphon can occur. Connect 1LINK to Apex Connect the 1LINK cable to an available 1LINK port.
- Page 5 Clicking on the gear: 1. Can initiate an alkalinity or combined test (Alk, Ca, and Mg) immediately. 2. Can turn your trident to “off” by switching it to “Manual.” PLEASE NOTE: THAT IF TURNING THE TRIDENT OFF FOR MORE THAN 72...
- Page 6 Add Trident Error Notification Make sure to be notified if the Trident experiences an error that can be resolved in the Trident Troubleshooting Guide (below).
- Page 7 No Test in 24H The "No Test in 24H" error indicates that the Trident has been off for more than 24 hours. For the Trident to continue to run appropriately and not require a Neptune Systems service, it must be run at least once every 24...
- Page 8 Recommended Course of Action No Test in 24H Check to make sure the Trident is not in Manual operation mode. If it is set to manual, then change it to Automatic. Next, run a test of your choosing. Error Condition...
- Page 9 Apex Fusion or see the guide to manually replace reagents Error Condition Stirrer Explanation of Error Stirrer The “Stirrer” error indicates that the mixing stir bar inside the Trident is not working. Recommended Course of Action This indicates an issue that can only be diagnosed by Neptune Systems Support.
- Page 10 To resolve this, run the reagent A replacement task in Apex Fusion or see the guide to manually replace reagents. After replacing the reagent, reboot the Trident or unplug the 1LINK cable to the Trident. Error Condition Test B Fail...
- Page 11 Recommended Course of Action Volts- 1LINK If you are using a 1LINK cable with the Trident, this error can be resolved by simply removing the 1LINK cable from the Trident and then reconnecting it. If the VOLT error continues, disconnect the far end of the 1LINK cable from the EB832 or 1LINK module then reconnect it.
- Page 12 Ensure that the power supply cord is properly connected to the Trident power input jack. Also verify that the power supply has AC input power. Neptune Systems does not recommend plugging the Trident power supply into an EneryBar outlet. But if...
- Page 13 Trident Controlled Dosing Task. Neptune Systems does not recommend running the Trident Controlled Dosing Task or going through this guide until the Trident has been in operation for at least 7 to 10 days. You, as the aquarist, must generally understand the amount of each additive needed to maintain stable alkalinity, calcium, and magnesium parameters in the aquarium for this guide to be successful.
- Page 14 Select the Control Range Enter the control range for the desired parameter. This is the range in which the Trident will have influence over the dosing volume. Outside the range the Trident will return to the “normal dosing amount.”...
- Page 15 Select the Control Limit Enter the control limit for the dosing pump of the controlled parameter. This is the degree in which the Trident will have influence over the dosing volume. When the maximum or minimum dosing amount is reached the Trident will no longer influence and the dosing will return to the “normal...
- Page 16 When the car is going far below the speed limit, the driver will push hard on the gas to achieve that speed. This is what the Trident will do when the parameter is near the minimum allowable range- it will add the highest allowable amount of additive according to the control limit.
- Page 17 It best to keep this around the recommended values listed above. If using too narrow of range, then the Trident will not be able to effectively influence controlled dosing. Control Limit In most situations, this is the variable to change if fine-tuning the desired level.
