Bourgault X35 Service Instructions Manual

N-cab components installation for 6000/ 7000 series air seeders
Hide thumbs Also See for X35:

Advertisement

Quick Links

INSTRUCTIONS
X35 CONSOLE IN-CAB COMPONENTS INSTALLATION
It is recommended to carefully follow the detailed steps of the instructions. Please check crate packing list against contents to be sure all parts
have been received.
On all Bourgault equipment, left and right are determined by standing behind the machine and looking forward. For this manual the drawings and
instructions are given for the assembly.
For safety, maintenance, warranty policy, and operating instruction of the unit, refer to the operators manual.
All information, illustrations and specifications in this manual are based on the latest product information. Bourgault updates products continually
to improve quality. We reserve the right to make changes at any time.
PRINTED IN CANADA
This Instruction used for the following Pkgs:
6358-03-73 AMK ISO UPGD TO X35
6362-40-10 PKG X35 IN-CAB CMPNT
6362-41-10 PKG X35 IN-CAB CMPNT W/O MON
SERVICE INSTRUCTIONS
6000/ 7000 Series Air Seeders
Assembly Instruction #: 0252-80-27
AUGUST, 2017
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the X35 and is the answer not in the manual?

Questions and answers

Summary of Contents for Bourgault X35

  • Page 1 It is recommended to carefully follow the detailed steps of the instructions. Please check crate packing list against contents to be sure all parts have been received. On all Bourgault equipment, left and right are determined by standing behind the machine and looking forward. For this manual the drawings and instructions are given for the assembly.
  • Page 2: Table Of Contents

    1.3.2 ISOBUS Harness (3151-78) ..................2 1.3.3 In-Cab SwitchBox Harness (3132-41) ..............4 1.3.4 Power Extension Harness(3151-68 or 3151-69) ............5 1.3.5 Main Power to the X35 System Components on the Air Seeder Tank ......5 Installation ..........................6 Schematic - IN-Cab components connection ................7...
  • Page 3: Components

    INSTRUCTIONS COMPONENTS X35 CONSOLE The X35 console is a Linux based computer system contained within an ABS housing. The console has no internal moving parts and the housing is designed to ensure long life in even the toughest conditions. The console has a 12" LCD touch screen display.
  • Page 4: Harnesses

    GPS IN GPS D SUB ADAPTOR REMOTE ENGAGE POWER REMOTE MAPPPING CAN 2 SYSTEM POWER IN SWITCHED POWER ISO BUS LOOP A SYSTEM POWER ISO BUS LOOP B SINGLE CAN 2 TERMINATOR PORT X35_AS_HARNESS_101915401.JPG Figure 3 - X35 Main Harness (3151-45)
  • Page 5 INSTRUCTIONS Figure 4 - Bourgault ISOBUS X35 Harness (3151-78)
  • Page 6: In-Cab Switchbox Harness (3132-41)

    If the 9-pin AMP ISOBUS connection does not exist in the tractor cab, use switchbox ISOBUS adapter harness (3132-42) to connect into the ISOBUS in the same location as the X35 console. CONNECTS TO Also use the switchbox power harness (3132-76) to...
  • Page 7: Power Extension Harness(3151-68 Or 3151-69)

    MAIN POWER TO THE X35 SYSTEM COMPONENTS ON THE AIR SEEDER TANK Following components are used to supply main power to the X35 system components located on the air seeder tank and tillage implement: High Current Power Relay Harness (3132-87)
  • Page 8: Installation

    Mount the relay near the battery where it will be protected and the contacts will not 4. Make the following harness connections: be shorted. a. Connect X35 harness (3151-45) to the k. Connect the end labelled 12V Battery "+" back of the X35 monitor, refer to Figure from 3132-87 to positive battery terminal.
  • Page 9: Schematic - In-Cab Components Connection

    INSTRUCTIONS SCHEMATIC - IN-CAB COMPONENTS CONNECTION UNITS WITH SIMPLIFIED ISOBUS X35 HARNESS #3151-78...
  • Page 10 INSTRUCTIONS NOTE & P OR ADDITIONAL INFORMATION AND QUESTIONS REGARDING CONSOLE AND SIGNAL REFER TO ERVICE ARTS SECTION ON OUR WEB SITE WWW OURGAULT...
