Bourgault X35 Quick Reference Manual

Console Toolbar
The lower Console Toolbar can be accessed
by swiping up from the bottom of the
screen. It will pop up on the bottom of the
screen with the available functions.
Quick Help
Question mark button on the
Console Toolbar toggles on/off
help mode. While in the help mode
a blue question mark is displayed
beside each icon on the screen. To see
description for icon touch blue question
mark beside it. To continue to work turn off
help mode.
Initial One-Time Setup
Select wrench icon to go to Settings page.
1. Change units settings - go to User/
Units.
2. Enable Auto Section Control (ASC)
if using coverage map to turn seeder
on/off. Go to System/Features/
Implement. Also enable Area Counters
to record treated areas for each tank.
3. GPS settings (if used) - go to System/
GPS, enter appropriate GPS settings to
get GPS signal into X35 console.
Note: GPS is the preferred ground speed
source to achieve the best accuracy.
4. Create your specific tractor profile - go
to Vehicle/New and follow prompts.
5. Create your specific airseeder tank and
drill profile - go to Implement/New/
Factory and follow prompts. Select
Apollo for ECU type.
6. Detect ECU's following the procedure
in the X35 manual
- ECU Manage).
7. Verify geometry for each boom. Go to
Implement/Geometry.
P/N 0252-92-03
Assy P/N 0252-93-01
X35 Console
(Section 6.3.2
Quick Reference Guide
(v 4.02)
1. Specific Seeding Scenario Setup
1. Go to Settings page (wrench icon
in bottom left corner).
2. Select appropriate tank grouping
(how the tanks are actually inter-
connected together) - go to Implement
/Seeder/Granular/Tank Grouping.
SELECT
GROUPING
