TN857 CI-IP-ADAPTER-1 Telex IP-224 Ethernet Adapter
The Telex IP-224 Ethernet Adapter provides a reliable means of remotely controlling up to two Codan base stations
remotely. The adapter can be used in conjunction with Telex model C-6200, C-Soft, IP-1616 and IP-2002 consoles.
The IP-223 is interconnected to the distant remote control console(s) by means of any available Wide Area Network
(WAN) or Local Area Network (LAN) connection.
The IP-224 can be confi gured to operate in modes that allow it to connect to both digital and analog radios, and
perform a variety of other tasks related to using radios on a digital network. The IP-224 can be rack mounted
providing easy installation and service. A sleek LCD display provides user feedback when programming and VU
meters are provided on the front of the display for alignment purposes. All other confi gurations are completed in the
web browser confi guration windows.
The Telex IP-224 Ethernet Adapter provides the following features:
Ethernet TX and LINK LEDs
PTT (Push To Talk) Monitor, F1 and F2 relays
Four (4) PTT Modes and Three (3) Monitor Modes
Nine (9) Selectable PTT Frequencies
Seven (7) Digital Outputs for Channel Selection
CTCSS (Continuous Tone Coded Squelch System) Generation(64 frequencies)
Software Gain Control
Direct Radio Control
Handset Port for Monitoring Activity and Transmission
Single Function Tone Recognition (16 Function Tones)
AGC (Automatic Gain Control)
RX (Receive) Audio Squelch
ANI (Automatic Number Identifi cation) Over-the-Air Protocol
Up to 1000 function tones supported
MDC1 and FleetSync1 Encode/Decode
SOIP (Serial Over Internet Protocol)
Dual Ethernet Interface for Backup Solution
Supports RS485, CAN Bus, RS232 and TTL
Backwards Compatible with Telex Radio Dispatch Products
Secure Remote Web Browser Programming and Confi guration
Single or Dual Function Tone Generation
Guard Tone User-Selectable for 2100Hz, 2175Hz, 2300Hz, 2325Hz,2400Hz, 2600Hz, 2800Hz, 2850Hz or 2900 Hz
Menu Driven Front Panel Control for TX, RX, Spare Audio, and CTCSS
