Air Hogs RC Fire Wing Instructions

Rudder
Antenna
Tail
Wing
Fuselage
Wing
Experience Radio Controlled flight with the Air Hogs
Just choose the direction you want to fly and squeeze the throttle trigger. The bright LED lights will allow you to easily
maneuver in any lighting! The Fire Wing™ is ultra light and features aerodynamic directional control and damage-
resistant high density foam. The Fire Wing™ also includes an integrated Charger/Flight Controller unit for convenient
portability and easy handling in the field.
BATTERY INSTALLATION
1. Use a Phillips screwdriver to loosen the battery
compartment door on the Charger/Flight Controller.
2. Open the battery door and install 4 AA 1.5-V
alkaline batteries (not included). Be careful to
align the positive (+) and negative (-) polarities with
the corresponding markings inside the battery
compartment as shown.
3. Close the battery compartment door and re-tighten
the hold down screw.
2
Four
AA
1.5-V
Alkaline
Batteries
1
Battery
Door
Charger/Flight
Controller
®
INSTRUCTIONS
Wing
Tail Wing
LED Light
Fire Wing TM Plane
+
– –
+
+
–
TM
Antenna
LED
Light
Propeller
Red
"Charging"
LED
Propeller Guard
Charger/Flight Controller
® RC Fire Wing™. The Fire Wing™ makes flying fun & easy!
TURN YOUR CHARGER-FLIGHT CONTROLLER ON AND SQUEEZE
THE THROTTLE OR MOVE THE DIRECTION TOGGLE TO TEST THE
GREEN LED GLOW. TO ENSURE THAT THE BATTERIES ARE
INSTALLED PROPERLY.
WHEN THE SWITCH IS IN THE MIDDLE
CHARGE POSITION AND CONNECTED TO THE PLANE, THE RED
LED SHOULD BLINK TO PRESENT CHARGING IN PROGRESS.
After each flight, store the plane in the package
REPAIRS
If the wings
on your plane
get damaged
they can be
easily repaired
with clear tape as
shown.
Check to make sure contents are complete:
• 1 Air Hogs ® RC Fire Wing™ Plane
• 1 Charger/Flight Controller
• 1 Instruction Sheet
Left/Right Toggle
Throttle
Trigger
IMPORTANT TIPS:
to prevent damage.
in the plane's
Flight Controller's
they will need
to be replaced
Green
"Power ON"
LED
OFF/CHARGE/ON
Switch
Your
Fire Wing TM
Plane has
pre-installed
rechargeable
batteries
.
fuselage
Because the
AA batteries
are used for
2 functions –
charging and
controlling,
after every
20 to 25
flights.
