- Page 1 Route switch Series Ethernet Switch User Manual UD03706B...
- Page 2 Any and all information, including, among others, wordings, pictures, graphs are the properties of Hangzhou Hikvision Digital Technology Co., Ltd. or its subsidiaries (hereinafter referred to be “Hikvision”). This user manual (hereinafter referred to be “the Manual”) cannot be reproduced, changed, translated, or distributed, partially or wholly, by any means, without the prior written permission of Hikvision.
- Page 3 Regulatory Information FCC Information Please take attention that changes or modification not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. FCC compliance: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules.
- Page 4 Industry Canada ICES-003 Compliance This device meets the CAN ICES-3 (A)/NMB-3(A) standards requirements. Preparing for installation The HIKVISION ROUTE SWITCH Series Ethernet Switch includes the following models: Model Name ROUTE SWITCH Ethernet Switch Symbol Conventions The symbols that may be found in this document are defined as follows.
-
Page 5: Table Of Contents
Table of Contents Chapter 1 ROUTE SWITCH Switch ..........................1 1.1 Appearance Description for Standard Configuration ..................... 1 1.2 ROUTE SWITCH Systematic Characteristic Parameters..................2 Chapter 2 Installation Preparation ..........................5 2.1 Caution of Usage ..............................5 2.2 Safety Advice ................................. 5 2.2.1 Safety Principles .............................. -
Page 6: Chapter 1 Route Switch Switch
Chapter 1 ROUTE SWITCH Switch The section describes the characteristics and parameters of ROUTE SWITCH and gives an overview of ROUTE SWITCH. 1.1 Appearance Description for Standard Configuration The built-in ports of ROUTE SWITCH are: 32/24 gigabit Ethernet RJ45 ports, 24 gigabit SFP ports, 8 10GE SFP+ ports and 1 console port. - Page 7 normally started up. If the indicator flickers, the system works normally. If the switch is powered on, the indicator is Power indicator Figure 1-2 The back template of the ROUTE SWITCH switch Table 1-3 Parts at the back template of the ROUTE SWITCH switch Abbrev.
-
Page 8: Route Switch Systematic Characteristic Parameters
normally started up. If the indicator flickers, the system works normally. If the switch is powered on, the indicator is Power indicator Figure 1-4 The back template of the ROUTE SWITCH switch Table 1-5 Parts at the back template of the ROUTE SWITCH switch Abbrev. - Page 9 RFC 1157 SNMP v1/v2 RFC 1213 MIB II Network management standard RFC 1757 RMON 1,2,3,9 32/24 10/100/1000 Base-T ports; 4/24 SFP ports; Standard configuration 4/8 10GE Ethernet SFP+ ports; 1 Console port 442.5×330×44/442.5×350×44 Dimensions mm (W×D×H) 0 ℃ ～45 ℃ ; 5%～95% non-condensing Operating temperature/humidity -20 ℃...
-
Page 10: Chapter 2 Installation Preparation
Chapter 2 Installation Preparation 2.1 Caution of Usage Similar to other electronic products, the semiconductor chip easily gets damaged if you power on or off abruptly and frequently. To restart up the switch of ROUTE SWITCH, you have to open the power on-off after the power is cut down for three to five seconds. -
Page 11: Safety Principles For Live Working
Read the installation guide carefully before you operate the system. Only professionals are allowed to install or replace the switch. Pull out the AC power socket and close the direct-current power before operating on the machine box or working beside the power source. ... -
Page 12: Electrostatic Discharge Damage Prevention
2.2.4 Electrostatic Discharge Damage Prevention Electrostatic discharge may damage devices and circuits. Improper treatment may cause the switch to malfunction completely or discontinuously. Move or locate the devices according to the measures of electrostatic discharge prevention, ensuring the machine box connects the ground. Another measure is to wear the static-proof hand ring. -
Page 13: Power Requirements
Each device on the cabinet gives off heat when it runs. Therefore, the sealed cabinet must have the heat-discharge outlet and the cooling fan. Do not put the devices too close, avoiding bad ventilation. When you install the machine box at the open cabinet, prevent the frame of the cabinet from blocking the airway of the machine box. - Page 14 Ethernet cable Other Ethernet terminal devices Control terminal - 9 -...
-
Page 15: Chapter 3 Installing The Route Switch Switch
Chapter 3 Installing the ROUTE SWITCH Switch Caution: Only professionals are allowed to install or replace the devices. 3.1 Installation Flow of ROUTE SWITCH 3.2 Installing the Machine Box of the Switch The installation of the machine box has two modes: ... -
Page 16: Installing The Machine Box On The Cabinet
Do not put things weighing 4.5 kg or over 4.5 kg on the top of the switch. 3.2.2 Installing the Machine Box on the Cabinet The machine box of the switch is fixed on the cabinet through the brackets. When you fix the brackets, the front template of the switch faces forward. - Page 17 Figure 3-3 Connecting the console port of ROUTE SWITCH and computer Table 3-1 Pins of the console port Name Remarks Input No connect No connect Output Note: The console port of the ROUTE SWITCH switch does not support traffic control. Therefore, you must set the option data traffic control to none when you configure the switch with the super terminal.
-
Page 18: Connecting 10Ge Ethernet Sfp+ Ports
3.3.2 Connecting 10GE Ethernet SFP+ Ports ROUTE SWITCH switch has 8 10G SFP+ ports. Each port has its corresponding indicator: TE1~TE8. You can connect the SFP+ optical module to the SFP+ port and then you can connect other Ethernet terminal devices through the optical cable. Figure 3-5 Connecting the 10GE SFP+ port and other Ethernet terminals Caution: The figure shown above does not represent the material ROUTE SWITCH. - Page 19 Figure 3-7 RJ-45 connector on the console port Because the 24 10/100/1000Base-T ports of ROUTE SWITCH support the MDI/MDIX self-identification of the cable, ROUTE SWITCH can adopt five types of direct-through/cross network cables when it connects other Ethernet terminals. Figure 3-8 Connecting the 1000Base-TX port and other Ethernet terminals Caution: The figure shown above does not represent the material ROUTE SWITCH.
-
Page 20: Connecting Gigabit Sfp Ports
Sending/receiving the paraphase of the data 2 TP2- Sending/receiving the paraphase of the data 1 TP1- Sending/receiving the normal phase of data 3 TP3+ Sending/receiving the paraphase of the data 3 TP3- 3.3.4 Connecting Gigabit SFP Ports ROUTE SWITCH provides 24 gigabit SFP ports. The indicators are on the right of the front plate of the chassis. - Page 21 Check whether the connected power meets the power requirements of the switch. Check whether the grounding line is correctly connected. Check whether the switch is correctly connected to other terminal devices. - 16 -...
-
Page 22: Chapter 4 Maintaining Switch
Chapter 4 Maintaining Switch Caution: Before opening the machine box, make sure that you have released the static you carried and then turn off the power on-off of the switch. Before operating any step in Appendix B, read the section “Safety Advice”. Before performing operations beside the power source or on the machine box, turn off the power on-off and plug out the power cable. -
Page 23: Closing Machine Box
When the cover is opened, put it aside. The mainboard of the system appears. Note: After taking off the cover, put it horizontally and avoid it to be crushed or collided. Otherwise, the machine box is hard to install. 4.2 Closing Machine Box The section mainly describes how to put the cover and close the machine box. -
Page 24: Chapter 5 Hardware Fault Analysis
Chapter 5 Hardware Fault Analysis The part describes how to remove the fault from the switch. 5.1 Fault Separation The key for resolving the systematic faults is to separate the fault from the system. You can compare what the system is doing with what the system should do to detect the fault. You need to check the following subsystems: ... -
Page 25: Indicator Description
5.2 Indicator Description The following table shows the indicators of the ROUTE SWITCH switch and their description: Abbrev. Name Description When the switch is powered on, Power indicator the indicator is on. When the indicator is always on, the system is being started up. System indicator When the indicator flickers, the system works well. -
Page 26: Chapter 6 Specifications
Chapter 6 Specifications Item DS-3E3740 DS-3E3756TF Backplane 224Gbps 256Gbps Forwarding rate 136Mpps 136Mpps 10/100/1000M Base-T ports+24 32 10/100/1000M Base-T ports+8 10G SFP+ Ports 1000Base-X ports ports +8 10G SFP+ ports 442.5 × 350 × 44 Dimensions(W×D×H)(mm) 442.5×315×44 Consumption <50W <55W AC ：... - Page 27 BPDU protection, root protection, and loopback protection It supports speed limit on port direction and direction. Supports 8 priority queues per port. Support mapping from message 802.1p to different queues Support SP, WRR and SP+WRR algorithm Support for message priority and message redirection Support L2 (Layer 2) ~L4 (Layer 4) packet filtering function, provide source MAC address, destination MAC address, source IP address, destination IP address, TCP/UDP protocol source/destination port number, protocol, VLAN packet filtering function...
- Page 28 User level management and password protection Support AAA authentication, support Radius, TACACS+ and many other ways. Support 802.1X authentication, support MAC authentication, and support MAC bypass authentication. Support to prevent DOS, ARP attack function, ICMP anti attack Support binding of IP, MAC, port and VLAN Support MAC address learning limit Support DHCP Snooping Support port isolation, Sticky MAC...
- Page 29 - 24 -...
