SSB200
SHOT BLAST CABINET
OWNER'S MANUAL

FOR YOUR SAFETY

PLEASE READ THESE INSTRUCTIONS CAREFULLY
AND RETAIN THEM FOR FUTURE USE.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SSB200 and is the answer not in the manual?

Questions and answers

Summary of Contents for SGS SSB200

  • Page 1 SSB200 SHOT BLAST CABINET OWNER’S MANUAL FOR YOUR SAFETY PLEASE READ THESE INSTRUCTIONS CAREFULLY AND RETAIN THEM FOR FUTURE USE.
  • Page 2 SPECIFICATION INVENTORY TOOL MODEL SSB200 TYPE FLOOR STANDING VOLTS MIN AIR REQUIREMENT 10 CFM MIN AIR REQUIREMENT 80-100 PSI WARNING A - Cabinet B - Funnel C - Shelf D - Grid Support E - Legs Read and understand instructions before use.
  • Page 3 9. Attach the shelf to the legs using the screws and nuts provided. WWW.SGS-ENGINEERING.COM PAGE 4 PAGE 5...
  • Page 4 Keep the jet facing the object and away from the clear plastic lid. Do not allow the jet to train on the rubber gloves, the air hose within the cabinet or the fluorescent lamp. WWW.SGS-ENGINEERING.COM PAGE 6 PAGE 7...
  • Page 5 NOT to cross thread the fine thread. NOTE: Should it be necessary to change the air nozzle, first remove the abrasive nozzle as described above. A box spanner will be required to unscrew and withdraw the air nozzle. WWW.SGS-ENGINEERING.COM PAGE 8 PAGE 9...
  • Page 6 Air vent filter missing. Replace filter or blank off vacuum extract is hole in rear panel being used. temporarily with masking tape. WWW.SGS-ENGINEERING.COM PAGE 10 PAGE 11...
  • Page 7 903593 Adaptor 903573 Nozzle 903594 Plastic Frame 903574 Clamp 903595 Plexiglass 903575 Air Hose Adaptor 903596 Glass 903576 Clamp 903597 Protective Film 903577 Air Hose 903598 Cotton Sealant 903578 Flat Washer 903599 Swivel Clip 903579 WWW.SGS-ENGINEERING.COM PAGE 12 PAGE 13...
  • Page 8 SGS Engineering (UK) Ltd West Side Park Raynesway Derby, DE21 7AZ EC Declaration of Conformity This is an important document and should be retained MANUFACTURER’S NAME: SGS Engineering (UK) Ltd Shot Blast Cabinet TYPE OF EQUIPMENT: SSB200 PART NUMBER: APPLICATION OF EC COUNCIL DIRECTIVES / STANDARD:...
