ACTOP LSIV3506 User Manual

Intelligent door peephole viewer

Intelligent Door Peephole Viewer User Manual

Contents

1 × Indoor control unit (language: English & Chinese )

1 × Out lens unit

1 × Micro SD card (2GB)

1 × User manual

1 × Warrant card

1 × Fixed sheet steel

1 × STLDF charger (power adapter &USB data line)

4 × Screws (tow pairs , select one according to the door thickness)

Specification:

Indoor control unit 142×88×13.5mm

Screen HD highlighted 5.0''inch LCD

Outdoor lens unit 61×61×14.1mm

View angle 120 degree

Door peephole diameter limits 12mm ~ 60mm

Door thickness limits 30mm~ 100mm

Power source 1400mAh lithium cell(rechargeable)

Working voltage 3.5V~4.5V

Charging Battery charge directly via the Micro USB at

the bottom of the host machine

Table of Contents

Need help?

Do you have a question about the LSIV3506 and is the answer not in the manual?

Page 1 Intelligent Door Peephole Viewer User Manual Contents 1 × Indoor control unit (language: English & Chinese ) 1 × Out lens unit 1 × Micro SD card (2GB) 1 × User manual 1 × Warrant card 1 × Fixed sheet steel 1 ×...
Page 2 Install illustration Install details 2.Fixed lens, connect it to the host machine...
Page 3 Structure illustration 1. Lens Infrared Sensor Outdoor Speaker Security Camera Infrared LED Self-Induced bell button Outdoor MIC 2. Host machine Reset Indoor MIC Phone Dial Camera Power On/Off 3. Function panel...
Page 4 Function explanation Intelligent doorbell function 1. When guests approach the door, the doorbell button lights, tell guests to press it; When guests leave the monitor area, the light goes out. 2. If the guest presses the button, the doorbell rings.， and the panel show the guest and take a photo.
Page 5 Features 1. Support infrared monitoring and infrared night-vision function (within 3m). 2. 5.0’’ HD LCD, touch screen, more convenient. 3. 2 million pixels security wide-angle camera, 4. Double-battery design, never halt. Notice 1. SIM-mode & NO SIM-mode Only put in a effective SIM-card (charge as a cell phone), can it realize the MMS alarm and remote calls function, but if there is no SIM-card, it can also support all the function, except the MMS alarm and remote calls.
